Uživatelská příručka k bezdrátovému teploměru do mrazničky ThermoPro TP210B

1. Úvod

The ThermoPro TP210B is a wireless thermometer system designed to monitor temperatures in refrigerators and freezers. It provides real-time temperature readings from up to two remote sensors to a central receiver unit. This system features a 500 ft (150 m) wireless range, high accuracy, and customizable temperature alerts to help maintain optimal storage conditions for food and other temperature-sensitive items.

Mezi klíčové vlastnosti patří:

• Rozšířený bezdrátový dosah: Up to 500 ft (150 m) using updated RF technology for stable connection.
• Pre-Paired for Immediate Use: No complex setup required; units are ready to operate upon powering on.
• Široký rozsah měření: Accurate readings from -40°F to 158°F (-40°C to 70°C).
• Smart Temperature Alerts: Customizable high/low temperature alarms on the receiver.
• Podsvícený LCD displej: Clear display of current, maximum, and minimum temperatures, visible day or night.
• Rechargeable Transmitter: Transmitter uses a rechargeable lithium battery, suitable for low-temperature environments.
• Flexibilní umístění: Multiple mounting options for both receiver and transmitters.

2. Obsah balení

• 1 x Přijímací jednotka
• 2 x Transmitter Units
• 2 x AAA baterie (pro přijímač)
• 1 x USB Charging Cable (for Transmitters)
• 1 x Uživatelská příručka

3. Schéma produktu

Familiarize yourself with the components of your ThermoPro TP210B system:

Image: The main receiver unit with its large display and control buttons (MODE, UP, DOWN, HISTORY/CLEAR, LIGHT °F/°C), alongside two smaller transmitter units.

Přijímací jednotka:

• LCD displej: Shows temperatures for both channels, Max/Min records, and battery status.
• Tlačítko MODE: Cycles through settings and alarm modes.
• Tlačítka NAHORU/DOLŮ: Adjust values in settings or alarm modes.
• HISTORY/CLEAR Button: Views and clears Max/Min temperature records.
• LIGHT °F/°C Button: Activates backlight and switches temperature units.
• Přihrádka na baterie: Located on the back, for 2x AAA batteries.

Transmitter Units:

• Teplotní senzor: Měří okolní teplotu.
• LED indikátor: Flashes to indicate data transmission.
• Vypínač: Zapíná/vypíná vysílač.
• Nabíjecí port: USB-C port for recharging the internal lithium battery.

4. Nastavení

The ThermoPro TP210B units are pre-paired at the factory. Follow these steps for initial setup:

1. Instalace baterií přijímače: Open the battery compartment on the back of the receiver unit. Insert 2 AAA batteries, ensuring correct polarity (+/-). Close the compartment.
2. Vysílače náboje: Connect the provided USB charging cable to the charging port on each transmitter unit and to a standard USB power source (e.g., phone charger, computer USB port). The LED indicator will show charging status. Charge fully before first use.
3. Power On Transmitters: Press and hold the power button on each transmitter unit until the LED indicator flashes.
4. Ověřit připojení: The receiver unit should automatically display temperature readings from both transmitters. If not, refer to the Troubleshooting section for re-pairing instructions.

Obrázek: Detailní záběr view illustrating the battery installation for the receiver unit and the USB charging process for a transmitter unit.

5. Návod k obsluze

5.1 Zobrazení nadview

The receiver's LCD displays the following information:

Image: The receiver's digital display, highlighting the current temperature readings for two channels, along with their respective maximum and minimum recorded temperatures and low battery indicators.

• Channel 1 Temperature: Typically for the refrigerator.
• Channel 2 Temperature: Typically for the freezer.
• Max/Min Records: Highest and lowest temperatures recorded since the last reset.
• Indikátor slabé baterie: Appears when receiver or transmitter batteries are low.
• Indikátor síly signálu: Shows connection status to transmitters.

5.2 Temperature Unit Selection (°F/°C)

To switch between Fahrenheit (°F) and Celsius (°C), press the LIGHT °F/°C button on the receiver unit.

5.3 Nastavení teplotních výstrah

The system allows you to set custom high and low temperature limits for each channel. An audible and visual alarm will activate if the temperature exceeds these limits.

Image: The receiver unit showing an active alarm, with a visual representation of a refrigerator door left open and a transmitter inside, illustrating a scenario where a temperature alert would be triggered.

1. Stiskněte tlačítko MODE button once to enter the alarm setting mode for Channel 1 (refrigerator). The high limit will flash.
2. Použijte UP or DOLŮ buttons to adjust the desired high temperature limit.
3. Stiskněte MODE again to set the low limit for Channel 1. Adjust with UP or DOLŮ.
4. Stiskněte MODE a third time to enter the alarm setting mode for Channel 2 (freezer). Repeat steps 2 and 3 for Channel 2.
5. Stiskněte MODE again to exit alarm setting mode. The alarm icon will appear next to the channel if an alarm is active.

5.4 Viewing and Clearing Max/Min Records

The receiver automatically records the maximum and minimum temperatures for each channel since the last reset.

• Stiskněte tlačítko HISTORIE/VYMAZAT jedním stisknutím tlačítka view the maximum recorded temperatures for both channels.
• Stiskněte HISTORIE/VYMAZAT znovu k view the minimum recorded temperatures for both channels.
• To clear the Max/Min records, press and hold the HISTORIE/VYMAZAT tlačítko na 3 sekundy viewing the records. The display will reset to current temperatures.

5.5 Pokyny pro umístění

Optimal placement ensures accurate readings and reliable wireless communication.

Image: A visual guide demonstrating the versatility of the ThermoPro TP210B, showing the receiver magnetically attached to a fridge, standing on a table, and hanging from a hook, while transmitters are shown standing on a shelf and clipped to a rack inside a fridge.

• Umístění přijímače: The receiver can be placed on a countertop using its integrated stand, mounted magnetically to a metal surface (e.g., refrigerator exterior), or hung on a wall using the hanging hole. Position it within 500 ft (150 m) of the transmitters, minimizing obstructions.
• Umístění vysílače: Place transmitters inside the refrigerator and freezer compartments. They can stand on a shelf or clip onto a rack. Ensure they are not directly exposed to cold air vents or heating elements, which could affect accuracy.

Image: A diagram showing the wireless signal path from transmitters inside a refrigerator and freezer to a receiver unit located in another room, emphasizing the 500-foot range.

6. Údržba

• Čištění: Wipe the units with a damp tkanina. Neponořujte do vody ani nepoužívejte abrazivní čisticí prostředky.
• Battery Replacement (Receiver): When the low battery indicator appears for the receiver, replace the 2 AAA batteries.
• Nabíjení vysílače: When the low battery indicator appears for a transmitter, recharge it using the provided USB cable. A full charge ensures reliable operation, especially in low-temperature environments.
• Skladování: If storing the device for an extended period, remove the AAA batteries from the receiver and ensure transmitters are fully charged before storage. Store in a dry, cool place.

7. Řešení problémů

• No Temperature Readings / Lost Connection:
  • Ensure both the receiver and transmitters are powered on.
  • Check battery levels for both units. Recharge or replace as needed.
  • Move the receiver closer to the transmitters. Walls, metal appliances, and electronic devices can interfere with the wireless signal.
  • Opětovné spárování: If connection is lost, try re-pairing. Power off all units. Power on the receiver. Then, power on each transmitter one by one. They should automatically reconnect.
• Nepřesná čtení:
  • Ensure transmitters are not placed directly in front of cold air vents or near heat sources.
  • Allow units to stabilize for 30 minutes after placement to get accurate readings.
  • Compare readings with another known accurate thermometer if possible.
• Alarm nezní:
  • Verify that the high/low temperature limits are set correctly for each channel.
  • Ensure the alarm function is enabled (check for the alarm icon on the display).

8. Specifikace

9. Informace o záruce

ThermoPro products are manufactured with high-quality materials and craftsmanship. This product is covered by a limited warranty against defects in materials and workmanship from the date of purchase. Please refer to the official ThermoPro webnebo kontaktujte zákaznickou podporu ohledně konkrétních záručních podmínek.

10. Podpora

For any questions, assistance, or troubleshooting not covered in this manual, please contact ThermoPro Customer Service:

• Webmísto: Visit the official ThermoPro webweb s častými dotazy, registrací produktů a kontaktními informacemi.
• E-mail: Refer to your product packaging or the ThermoPro webweb s e-mailovou adresou zákaznické podpory.
• Telefon: Contact the customer support hotline if available in your region.

Please have your model number (TP210B) and purchase date ready when contacting support.
