USKEYVISION Magnetic Mini Selfie Stick MPT-02 Instruction Manual

1. Nastavení

1.1 Obsah balení

Ověřte, zda je v balení obsaženo vše:

• Magnetic Mini Selfie Stick x1
• LED Fill Light x2
• Phone Clip x1
• Kabel USB-C x1
• Magnetický kroužek x2
• Uživatelská příručka x1

1.2 Charging the Remote Control and Fill Lights

The detachable remote control and LED fill lights are rechargeable via the included USB-C cable. Connect the cable to the charging port on each device and a suitable power source. A blue indicator light on the remote signifies charging, turning off when fully charged. The fill lights will also indicate their charging status.

1.3 Párování Bluetooth

1. Turn on the remote control by pressing and holding the button until the indicator light flashes.
2. Na smartphonu přejděte do nastavení Bluetooth.
3. Hledat "VIP" in the list of available devices and select it to pair.
4. The indicator light on the remote will stop flashing, indicating a successful connection.

1.4 Připojení smartphonu

1.4.1 For MagSafe Compatible Phones (iPhone 12 Pro Max and above, or MagSafe cases)

Align your MagSafe-compatible phone or case directly with the magnetic ring on the selfie stick's phone holder. The strong magnets will securely attach your phone.

1.4.2 For Non-MagSafe Phones

For phones without MagSafe or non-MagSafe cases, use the included adhesive magnetic ring. Peel off the protective film and carefully center the magnetic ring on the back of your phone or case. Press firmly for complete adhesion. It is recommended to wait at least 2 hours after applying before use for optimal bond strength. Once the ring is attached, your phone can be magnetically mounted to the selfie stick.

1.5 Attaching the Phone Clip (Optional)

The selfie stick includes a removable phone clip for additional security or for phones that may not be suitable for magnetic rings. Attach the phone clip to the top of the selfie stick's phone holder. Ensure your smartphone fits within the width range of 2.56-3.54 inches. Foldable phones are not recommended for use with the clip.

1.6 Attaching Fill Lights

The two LED fill lights can be attached to the sides of the phone holder. They snap into place securely, providing additional illumination for your photos and videos.

2. Návod k obsluze

2.1 Opening the Tripod Legs

To deploy the tripod legs, press the one-touch open button located at the base of the selfie stick. The legs will automatically extend and lock into position, providing a stable base for hands-free use.

2.2 Režim selfie tyče

Hold the handle firmly. Extend the telescopic pole to your desired length for wider shots or group photos. The pole extends smoothly and locks at various lengths for flexible framing.

2.3 Režim stativu

With the tripod legs extended, place the selfie stick on a flat, stable surface. Adjust the telescopic pole to achieve your desired height for hands-free recording, live streaming, or video calls.

2.4 Phone Hand Grip Mode

Collapse the telescopic pole and fold the tripod legs. The device can then be used as a comfortable hand grip for more stable handheld shooting, similar to a camera grip.

2.5 Adjusting Angles and Orientation

The phone holder offers flexible adjustments:

• Otočení o 225°: Tilt the phone holder up or down to capture high-angle or low-angle shots.
• Otočení o 360°: Rotate your phone horizontally or vertically without removing it from the holder.
• Posuvná kolejnice: Fine-tune your composition quickly with the integrated sliding rail.

2.6 Použití doplňkových světel

Each LED fill light offers three color modes (white, warm, natural) and three brightness levels. Press the power button on each light to cycle through the modes and brightness settings to adapt to different lighting environments.

3. Údržba

• Zařízení čistěte měkkým, suchým hadříkem. Vyhněte se používání agresivních chemikálií nebo abrazivních materiálů.
• Ensure the magnetic surfaces are clean and free of debris for optimal adhesion.
• Selfie tyč skladujte na chladném a suchém místě mimo dosah přímého slunečního záření a extrémních teplot.
• Regularly charge the remote control and fill lights to maintain battery health.

4. Řešení problémů

4.1 Dálkové ovládání se nepřipojuje

• Ujistěte se, že je dálkový ovladač nabitý.
• Ověřte, že je na vašem smartphonu povoleno Bluetooth.
• Try re-pairing the remote control by following the Bluetooth Pairing instructions in Section 1.3.

4.2 Phone Not Securely Attached

• For MagSafe phones, ensure the phone or case is MagSafe compatible and properly aligned.
• For non-MagSafe phones, confirm the adhesive magnetic ring is securely attached to your phone or case and has had sufficient time to bond (at least 2 hours).
• Check for any obstructions or debris between the phone and the magnetic holder.

4.3 Nestabilita stativu

• Ujistěte se, že nohy stativu jsou zcela vysunuté a zajištěné na místě.
• Umístěte stativ na rovný a stabilní povrch.
• Avoid placing heavy objects on the extended pole, especially when fully extended.

5. Specifikace

6. Záruka a podpora

For warranty information or technical support, please refer to the contact details provided with your purchase or visit the official USKEYVISION webUschovejte si doklad o koupi pro případné reklamace.
