1. Úvod
This manual provides essential information for the safe and efficient operation, assembly, and maintenance of your Hyper Tough 12 Amp Electric Leaf Blower and Vacuum Combo, model HT21-401-002-05. Please read this manual thoroughly before use and retain it for future reference. This versatile outdoor tool combines a high-velocity blower, efficient vacuum, and effective mulcher in one compact design, offering 250 MPH blowing speed and 400 CFM airflow.
2. Důležité bezpečnostní pokyny
When using electric gardening appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and personal injury. Read all instructions before using this product.
- Přečtěte si manuál: Seznamte se s ovládacími prvky a správným používáním spotřebiče.
- Wear Eye and Ear Protection: Always wear safety glasses or goggles and ear protection when operating the unit.
- Udržujte prostor volný: Ensure bystanders, children, and pets are at a safe distance (at least 50 feet/15 meters) from the operating area.
- Před použitím zkontrolujte: Check for loose parts, damaged components, or any condition that may affect safe operation. Do not use if damaged.
- Vyhněte se mokrým podmínkám: Do not operate the appliance in rain or wet conditions.
- Odpojte, když se nepoužívá: Disconnect the appliance from the power supply before cleaning, servicing, or when not in use.
- Použijte správný prodlužovací kabel: Ensure the extension cord is suitable for outdoor use, rated for the appliance's amperage, and in good condition.
- Udržujte pevný úchop: Always hold the appliance firmly with both hands during operation.
- Nepřesahujte: Vždy udržujte správný postoj a rovnováhu.
- Metal Impeller Warning: The unit contains a metal impeller. Exercise caution and ensure no foreign objects are ingested.
3. Komponenty produktu
The Hyper Tough 12 Amp Electric Leaf Blower and Vacuum Combo consists of several key parts that allow for its versatile functionality. Understanding these components is essential for proper assembly and operation.
- Pouzdro motoru: Contains the electric motor and impeller.
- Trubice ventilátoru: Attaches to the motor housing for blowing functionality.
- Elektronka: Larger tube for vacuuming debris.
- Sběrná taška: Attaches to the vacuum port to collect mulched debris.
- Hlavní rukojeť: For gripping and controlling the unit.
- Pomocná rukojeť: Poskytuje dodatečnou přilnavost a kontrolu.
- Napájecí kabel: Integrated cord for connecting to an electrical outlet.
- Spínač regulace rychlosti: Adjusts between two operating speeds.
4. Nastavení a montáž
The Hyper Tough 3-in-1 unit features tool-free conversion between blower and vacuum modes. Follow these steps for proper assembly.
4.1. Blower Mode Assembly
- Ensure the unit is unplugged from the power source.
- Align the blower tube with the outlet on the front of the motor housing.
- Push and twist the blower tube until it locks securely into place.
4.2. Vacuum/Mulcher Mode Assembly
- Ensure the unit is unplugged from the power source.
- Remove the blower tube if it is attached.
- Attach the larger vacuum tube to the intake port of the motor housing. Ensure it clicks into place.
- Connect the collection bag to the exhaust port of the motor housing. Ensure the bag's opening is securely fastened to prevent debris leakage.
5. Návod k obsluze
Always ensure all safety precautions are followed before operating the unit.
5.1. Blower Mode Operation
- Ensure the blower tube is securely attached.
- Connect the power cord to a suitable outdoor-rated extension cord, then plug into a 120V electrical outlet.
- Držte jednotku pevně oběma rukama.
- Press the ON/OFF switch to start the blower. Use the 2-speed control to adjust airflow as needed.
- Direct the airflow towards leaves and debris to clear surfaces such as patios, sidewalks, and driveways.
5.2. Vacuum/Mulcher Mode Operation
- Ujistěte se, že jsou vysavací trubice a sběrný vak bezpečně upevněny.
- Connect the power cord to a suitable outdoor-rated extension cord, then plug into a 120V electrical outlet.
- Držte jednotku pevně oběma rukama.
- Press the ON/OFF switch to start the vacuum. Use the 2-speed control to adjust suction as needed.
- Slowly sweep the vacuum tube over leaves and light debris. The metal impeller will mulch the debris at a 16:1 ratio before it enters the collection bag.
- Monitor the collection bag and empty it when it becomes full to maintain optimal performance.
6. Údržba
Regular maintenance ensures the longevity and optimal performance of your Hyper Tough leaf blower and vacuum combo.
- Vždy odpojte ze zásuvky: Before performing any maintenance, ensure the unit is unplugged from the power source.
- Čistěte po každém použití: Otřete vnější část jednotky reklamouamp cloth. Remove any debris from the air intake vents and the blower/vacuum tubes.
- Empty Collection Bag: Empty the collection bag regularly. Clean the bag if necessary by shaking out debris or rinsing with water and allowing it to dry completely before reattaching.
- Inspect Impeller: Periodically inspect the metal impeller for any damage or debris buildup. Clear any blockages carefully.
- Kontrola kabelu: Check the power cord and extension cord for any cuts, fraying, or damage. Replace damaged cords immediately.
- Skladování: Store the unit in a dry, well-ventilated area, out of reach of children. Disassemble tubes for compact storage if desired.
7. Řešení problémů
Běžné problémy a jejich možná řešení naleznete v tabulce níže.
| Problém | Možná příčina | Řešení |
|---|---|---|
| Jednotka se nespustí | No power supply; Faulty cord; ON/OFF switch issue | Check power outlet and extension cord; Inspect power cord for damage; Ensure switch is fully engaged. |
| Low blowing/suction power | Blocked intake/exhaust; Loose tube/bag connection; Full collection bag | Unplug and clear blockages from tubes/impeller; Ensure all connections are secure; Empty collection bag. |
| Nadměrné vibrace/hluk | Debris in impeller; Damaged impeller | Unplug and clear debris from impeller; If damage is suspected, discontinue use and contact customer support. |
8. Specifikace produktu
| Funkce | Detail |
|---|---|
| Značka | Hyper odolný |
| Název modelu | 12 Amp Electric Leaf Blower and Vacuum Combo |
| Číslo modelu | HT21-401-002-05 |
| Zdroj napájení | Elektrický kabel |
| svtage | 120 voltů |
| Ampvymazat | 12 Amp |
| Rychlost ventilátoru | Až 250 MPH |
| Průtok vzduchu (CFM) | 400 CFM |
| Mulčovací poměr | 16:1 |
| Materiál oběžného kola | Kov |
| Rychlosti | 2-rychlostní ovládání |
| Kapacita sběrného vaku | 1.2 bušl |
| Hmotnost položky | 7.5 lbs (unit only), 9.9 lbs (shipping) |
| Rozměry produktu | 15.7 cm D x 3.9 cm Š x 4.6 cm V |
| Materiál | Kov, Plast |
| Form Factor | Ruční |
| Barva | Červená/Černá |
| Zahrnuté komponenty | 1x Electric Leaf Blower and Vacuum Combo |
9. Záruka a zákaznická podpora
This product is covered by a manufacturer's warranty against defects in materials and workmanship. For specific warranty details, including duration and coverage, please refer to the warranty card included with your product or contact Hyper Tough customer support.
If you encounter any issues or have questions regarding the operation, maintenance, or parts for your Hyper Tough 12 Amp Electric Leaf Blower and Vacuum Combo, please contact the manufacturer's customer support line or visit their official webmísto pro pomoc.
