1. Úvod
This manual provides essential information for the safe operation, maintenance, and troubleshooting of your X-PRO Orion 200 Gas Moped. Please read this manual thoroughly before operating the moped to ensure proper use and to prevent injury or damage.
The X-PRO Orion 200 is an adult gas street moped featuring a 168.9cc 4-stroke engine, 14-inch wheels, and LED headlights, designed for reliable urban and street commuting.
2. Bezpečnostní informace
Your safety and the safety of others are very important. Operating this moped requires careful attention to safety procedures. Always wear a helmet and appropriate protective gear. Observe all local traffic laws and regulations.
- Always wear a DOT-approved helmet and other protective gear (gloves, eye protection, sturdy footwear).
- Never operate the moped under the influence of alcohol or drugs.
- Perform pre-ride inspections before each use.
- Be aware of your surroundings and other vehicles.
- Nepřekračujte maximální nosnost 265 liber.
- Ensure the Manufacturer Statement of Origin (MSO) and Bill of Sale paperwork are received and processed for registration.
3. Komponenty přesview
Familiarize yourself with the main components of your X-PRO Orion 200 Gas Moped.
Figure 3.1: Front Three-Quarter View. This image displays the overall design of the X-PRO Orion 200 Gas Moped from the front-right side, highlighting its sleek black finish, prominent LED headlight, and the 14-inch front alloy wheel with disc brake.
Obrázek 3.2: Side Profile. A complete side view of the moped, illustrating its compact frame, the location of the 168.9cc engine, exhaust system, and the 14-inch alloy wheels. The seat and footrest area are also clearly visible.
Obrázek 3.3: Čelní View. Tento obrázek poskytuje přímý pohled zepředu view, emphasizing the distinctive LED headlight design, front fender, and the dual suspension system. The handlebars and mirrors are also visible from this angle.
Figure 3.4: Rear Three-Quarter View. A view from the rear-left side, showcasing the taillight, rear turn signal indicators, the rear 14-inch alloy wheel with drum brake, and the exhaust muffler.
4. Nastavení a počáteční příprava
Your X-PRO Orion 200 Gas Moped arrives 99% assembled. The following steps outline the final preparations before first use.
Figure 4.1: Product Packaging for Fully Assembled Version. This image shows how the fully assembled moped is securely wrapped in black material and placed on a pallet for transport, ensuring its protection during delivery.
4.1 Vybalení a kontrola
- Opatrně odstraňte veškerý obalový materiál.
- Inspect the moped for any signs of shipping damage. Report any damage immediately to your dealer.
- Ujistěte se, že jsou přítomny všechny součásti.
4.2 Kontroly provozních kapalin
- Motorový olej: Zkontrolujte hladinu motorového oleje pomocí měrky. V případě potřeby doplňte doporučený olej.
- Brzdová kapalina: Verify brake fluid levels for both front (disc) and rear (drum) brakes.
- Palivo: Fill the 6.4L fuel tank with appropriate gasoline. Refer to local regulations for fuel type.
4.3 Tlak v pneumatikách
Check and adjust tire pressure for both front (80/90-14) and rear (90/90-14) tires to the recommended PSI levels specified on the tire sidewall or in the moped's quick reference guide.
4.4 Připojení baterie
Ensure the 12V/7Ah battery is securely connected. If disconnected for shipping, connect the positive (+) and negative (-) terminals.
5. Návod k obsluze
5.1 Startování motoru
- Elektrický start: Ensure the engine kill switch is in the "RUN" position. Insert the key and turn to "ON". Squeeze the brake lever (either front or rear) and press the electric start button.
- Rychlý start: If the electric start fails or for cold starts, use the kick start lever located on the side of the engine.
5.2 Ovládací prvky a funkce
- Škrticí klapka: Located on the right handlebar. Gently twist to accelerate.
- brzdy: Front brake (disc) on the right handlebar, rear brake (drum) on the left handlebar. Apply smoothly and evenly.
- Světlomet: LED headlight for improved visibility. Use the switch on the handlebar to turn on/off.
- Směrová světla: LED turn signal indicators. Use the switch to signal turns.
- Roh: Button located on the handlebar.
- USB nabíječka: Located conveniently for charging mobile devices.
5.3 Riding the Moped
Start slowly and practice in a safe, open area. Maintain a safe distance from other vehicles. The moped has an automatic transmission, simplifying operation. Top speed is 55+ Mph, depending on rider weight and road conditions.
6. Údržba
Regular maintenance is crucial for the longevity and safe operation of your moped.
6.1 Pravidelné kontroly
- pneumatiky: Check pressure and tread wear weekly.
- brzdy: Inspect brake levers for proper feel and brake pads/shoes for wear.
- Světla a klakson: Verify all lights (headlight, taillight, turn signals) and the horn are functional.
- Hladiny kapalin: Regularly check engine oil and brake fluid.
- Řetěz: Inspect the final drive chain for proper tension and lubrication.
6.2 Plánovaná údržba
Refer to a more detailed service manual (if available) for specific service intervals for oil changes, spark plug replacement, air filter cleaning, and valve adjustments.
7. Řešení problémů
Tato část se zabývá běžnými problémy, se kterými se můžete setkat.
| Problém | Možná příčina | Řešení |
|---|---|---|
| Motor nenastartuje | No fuel; Engine kill switch off; Weak battery; Spark plug issue | Check fuel level; Ensure kill switch is ON; Charge/replace battery; Inspect/replace spark plug |
| Špatné zrychlení | Low tire pressure; Clogged air filter; Fuel quality | Check tire pressure; Clean/replace air filter; Use fresh, recommended fuel |
| Brzdy se zdají být měkké | Low brake fluid; Air in brake lines; Worn brake pads | Check fluid level and add; Bleed brake lines; Replace brake pads/shoes |
| Světla nefungují | Blown fuse; Faulty bulb/LED; Wiring issue | Check fuses; Replace bulb/LED; Inspect wiring connections |
For issues not listed or if solutions do not resolve the problem, contact qualified service personnel or your dealer.
8. Specifikace
Detailed technical specifications for the X-PRO Orion 200 Gas Moped.
| Typ motoru | 168.9cc, 4-stroke, Air cooled |
| Cylinder Arrangement | Singl |
| Přenos | Automatický |
| Kompresní poměr | 9.2:1 |
| Maximální výkon | 8.3KW/8000 r/min |
| Maximální točivý moment | 11.0 N·m/6000 r/min |
| Spusťte systém | Electric/Kick |
| Závěrečná jízda | Řetěz |
| Zapalování | CDI |
| Nejvyšší rychlost | 55+ Mph (Depending on Riders Weight and Road Conditions) |
| Baterie | 12V/7Ah |
| Přední brzda | Disk |
| Zadní brzda | Buben |
| Přední pneumatika | 80/90-14 Alloy |
| Zadní pneumatika | 90/90-14 Alloy |
| Hmotnostní kapacita | 265 liber |
| Čistá hmotnost | 238 liber |
| Celková délka | 74.8" |
| Celková šířka | 28.7" |
| Celková výška | 44" |
| Rozvor kol | 50.8" |
| Výška sedu | 30.3" |
| Minimální světlá výška | 5.5" |
| Kapacita paliva | 6.4 l |
| Světlomet | Ano, LED |
| Zadní světlo | Ano |
| Ukazatele směrových světel | Ano, LED |
| Roh | Ano |
| USB nabíječka | Ano |
9. Záruka a podpora
The X-PRO Orion 200 Gas Moped comes with a Záruka 1 měsíců od data nákupu. Tato záruka se vztahuje na výrobní vady vzniklé běžným používáním. Pro případné reklamace si prosím uschovejte doklad o koupi.
For technical support, parts, or warranty inquiries, please contact your authorized X-PRO dealer or visit the official X-PRO webstránky pro kontaktní informace.
Note: The Manufacturer Statement of Origin (MSO) and Bill of Sale paperwork will be sent to you by separate mail and are essential for vehicle registration.
