HOMPOW Mini Projector Instruction Manual

Zavedení

This manual provides detailed instructions for the setup, operation, maintenance, and troubleshooting of your HOMPOW Mini Projector. Please read this manual thoroughly before using the product to ensure optimal performance and longevity.

Co je v krabici

• Dálkové ovládání
• Uživatelská příručka
• Napájecí adaptér
• HDMI kabel
• Záruční list

Vlastnosti produktu

• Rozlišení ve vysokém rozlišení: Supports 1080P Full HD with a native resolution of 720P (1280x720) for clear and vibrant images.
• Eye-Protective Technology: Features low-blue-light technology and reflected imaging to reduce eye strain.
• Zrcadlení obrazovky: Easy screen mirroring from Android phones (Micro USB/Type-C to HDMI adapter required, sold separately) and iPhones/iPads (Lightning to HDMI adapter required, sold separately). Supports TV sticks (sold separately) for HDCP-compliant streaming.
• Two-Way Bluetooth: Bidirectional Bluetooth 5.1 allows connection to external Bluetooth speakers for enhanced sound or using the projector as a Bluetooth speaker.
• Kompaktní a přenosné: Weighs just 0.7 kg, offering a projection size of 40 to 120 inches for indoor and outdoor use.
• Low Noise & Kid-Friendly: Whisper-quiet operation and an auto-off timer for screen time management.
• Efektivní připojení: Includes USB 2.0 and HDMI 2.0 ports for seamless connections with smartphones, TV sticks, PS4, PS5, tablets, and laptops.
• Vestavěné stereo reproduktory: Features built-in 5W high-powered speakers for rich, clear sound.
• Kids’ Bedtime Stories: Ideal for creating an engaging atmosphere for bedtime stories.

Nastavení

Follow these steps to set up your HOMPOW Mini Projector for the first time.

1. Rozbalení: Opatrně vyjměte všechny součásti z obalu. Zkontrolujte, zda jsou přítomny všechny položky uvedené v části „Co je v krabici“.
2. Připojení napájení: Připojte napájecí adaptér ke vstupnímu portu stejnosměrného proudu projektoru a poté jej zapojte do elektrické zásuvky.
3. Umístění: Place the projector on a stable, flat surface. Ensure there are no obstructions in front of the lens. The optimal projection distance will vary based on desired screen size (40 to 120 inches).
4. Zapnutí: Stisknutím tlačítka napájení na projektoru nebo na dálkovém ovladači zapněte zařízení.
5. Nastavení zaostření: Rotate the focus ring around the lens until the projected image is clear and sharp.

Image: The HOMPOW Mini Projector, showcasing its compact and portable design, measuring approximately 4.9 x 4.9 x 2.1 inches.

Návod k obsluze

Připojovací zařízení

Projektor nabízí několik možností připojení pro různá zařízení:

• Připojení HDMI: Use the provided HDMI cable to connect your laptop, TV stick, gaming console (PS4, PS5), or other HDMI-enabled devices to the projector's HDMI port. Select 'HDMI' as the input source using the remote control.
• USB připojení: Vložte USB disk do portu USB 2.0 pro přehrávání médií files directly. Navigate through the 'Movie', 'Music', or 'Photo' menus to select your content.
• Bluetooth Connection (Two-Way):
  1. To connect external Bluetooth speakers: Go to 'Settings' -> 'BT Setting' and select 'Send'. The projector will search for available Bluetooth speakers. Pair with your desired speaker.
  2. To use the projector as a Bluetooth speaker: Go to 'Settings' -> 'BT Setting' and select 'Receive'. On your smartphone or tablet, search for 'Project_BT' in your Bluetooth settings and connect.
• Screen Mirroring (Wired): For Android phones, use a Micro USB/Type-C to HDMI adapter (sold separately). For iPhones/iPads, use a Lightning to HDMI adapter (sold separately). Connect the adapter to your phone and then to the projector's HDMI port. Select 'HDMI' as the input source.

Image: The HOMPOW Mini Projector connected to various devices including a laptop, smartphone, gaming controller, and headphones, illustrating its versatile input options.

Image: A diagram showing how to connect smartphones and tablets to the projector using Micro USB/Type-C to HDMI or Lightning to HDMI adapters.

Image: An illustration of the projector's bidirectional Bluetooth capability, connecting to external headphones and a Bluetooth speaker.

Nastavení promítání

Adjust the projection to suit your viewprostředí a preference.

• Velikost obrazovky: The projector supports a projection size from 40 to 120 inches. Adjust the distance of the projector from the wall or screen to achieve your desired size.
• Režim obrazu: Access the 'Settings' menu to adjust picture parameters such as Contrast, Brightness, Sharpness, and Color Temperature.
• Ochrana očí: The projector incorporates eye-protective technology. For optimal eye comfort, especially during extended viewing, ensure the room lighting is appropriate and avoid direct viewing of the lens.

Image: Visual representation of the projector's capability to display screen sizes from 40 to 120 inches, suitable for various room conditions.

Image: A split image demonstrating the 1080P supported quality picture of the HOMPOW projector compared to a standard projector.

Údržba

Správná údržba zajistí dlouhou životnost a výkon vašeho projektoru.

• Čištění objektivu: Use a soft, lint-free cloth or the provided cleaning tool to gently wipe the projector lens. Avoid using abrasive cleaners or excessive force.
• Odstranění prachu: Regularly clean the ventilation openings to prevent dust buildup, which can affect cooling and performance.
• Skladování: When not in use, store the projector in a cool, dry place, away from direct sunlight and extreme temperatures. Use the lens cap to protect the lens from dust and scratches.

Odstraňování problémů

Pokud se s projektorem setkáte s problémy, podívejte se na následující běžné problémy a jejich řešení:

• Rozmazaný obrázek: Adjust the focus ring on the projector lens. Ensure the projector is placed at an appropriate distance from the screen.
• Bez obrázku: Check all cable connections (HDMI, USB). Ensure the correct input source is selected on the projector. Verify the power adapter is securely connected.
• Žádný zvuk: Check the volume settings on both the projector and the connected device. If using external speakers via Bluetooth, ensure they are properly paired and powered on.
• Problémy s připojením Bluetooth: Ensure both the projector and the external device are in Bluetooth pairing mode. Try restarting both devices.

Pro další pomoc se prosím obraťte na zákaznickou podporu.

Specifikace

Záruka a podpora

HOMPOW is committed to providing excellent customer service and product support.

• 30-Day Replacement Window: Enjoy a 30-day replacement period for any product defects or issues.
• 2letá záruka na opravy: Your projector is covered by a 2-year repair warranty.
• Doživotní technická podpora: Benefit from 24/7 technical assistance for any questions or optimization needs.

For support, please refer to the contact information provided on your Warranty Card or visit the official HOMPOW webmísto.
