Zavedení
Thank you for choosing the Codnida Baby Monitor with Camera. This device is designed to provide reliable and intelligent monitoring of your baby, ensuring their safety and your peace of mind. This manual will guide you through the setup, operation, and maintenance of your new baby monitor.
Image: The Codnida Baby Monitor system, showing the camera unit and the 5.5-inch LCD display unit.
Bezpečnostní informace
- Keep the camera unit and monitor unit out of reach of children.
- Ensure all cables are securely placed and not accessible to the baby to prevent strangulation hazards.
- Do not place the camera or monitor near water or heat sources.
- Používejte pouze dodané napájecí adaptéry.
- Nepokoušejte se zařízení sami otevírat ani opravovat. Požádejte o pomoc zákaznickou podporu.
- Tento výrobek je určen pouze pro vnitřní použití.
Obsah balení
Po vybalení zkontrolujte obsah balení:
- 1x kamerová jednotka
- 1x Display Unit (5.5" LCD)
- 2x Charging Adapters
- 2x nabíjecí kabely
- 1x Screw Bag (for mounting)
- 1x Reset Pin
- 1x Uživatelská příručka
Image: All components included in the Codnida Baby Monitor package, neatly arranged.
Konec produktuview
The Codnida Baby Monitor system consists of two main components: the Camera Unit and the Display Unit.
Jednotka kamery
The camera unit captures video and audio from your baby's room. It features a 3MP 2K HD sensor, infrared LEDs for night vision, and a microphone for two-way audio communication. The camera also supports Pan, Tilt, and Zoom (PTZ) functions for comprehensive room coverage.
Displejová jednotka
The display unit features a 5.5-inch LCD screen for clear video monitoring. It includes controls for camera movement, volume, VOX mode, lullabies, and access to settings. The display unit has a built-in 4000mAH battery for portable use.
Obrázek: Detailní záběr view of the Codnida Baby Monitor camera and display units, highlighting their design.
Průvodce nastavením
1. Nabíjení jednotek
Before first use, fully charge both the camera and display units using the provided charging adapters and cables. The display unit has a 4000mAH battery, offering up to 14 hours of live view or 28 hours in VOX mode on a full charge.
Image: The display unit connected to its charging cable, illustrating the charging process and battery life indicators.
2. Umístění kamerové jednotky
Place the camera unit on a flat, stable surface such as a dresser or shelf, or mount it to a wall using the included screw bag. Ensure the camera has a clear, unobstructed view of the baby's crib or play area. Keep the camera at least 3 feet (1 meter) away from the baby to prevent entanglement with cables.
3. Zapnutí
Connect both the camera and display units to power outlets. Press and hold the power button on each unit until the indicator lights turn on. The units should automatically pair. If they do not pair, refer to the troubleshooting section.
4. Connecting to the Tuya App (Optional)
For remote monitoring and additional features, download the "Tuya" app on your smartphone. Follow the in-app instructions to connect your camera unit to your home Wi-Fi network. This allows you to view the live feed and control the camera from your smartphone, whether you are at home or away.
Image: Illustrates the flexibility of monitoring, showing both the dedicated display unit and a smartphone running the companion app.
Návod k obsluze
Žít View a displej
Once powered on and paired, the 5.5-inch LCD display unit will show a live 2K HD video feed from the camera. The display provides clear images with remarkable detail.
Image: Demonstrates the 2K HD video quality and the 4X digital zoom capability of the baby monitor.
Pan, Tilt, and Zoom (PTZ) Control
Use the directional buttons on the display unit to remotely control the camera's pan (horizontal), tilt (vertical), and 4X digital zoom functions. This allows you to adjust the viewing angle and zoom in on your baby without entering the room.
Image: Illustrates the camera's ability to pan 350 degrees horizontally and tilt 90 degrees vertically, providing wide coverage.
Infračervené noční vidění
The camera automatically switches to infrared night vision in low-light conditions, providing a clear black-and-white view of your baby without disturbing their sleep. The invisible infrared LEDs ensure discreet monitoring.
Image: Shows a side-by-side comparison of the camera's view in daylight and its clear infrared night vision in darkness.
Obousměrný zvuk
Press and hold the microphone button on the display unit to speak to your baby through the camera's speaker. This feature allows you to soothe your baby with your voice from another room.
Image: Illustrates the two-way audio feature, showing a parent speaking into their phone (app) and the baby hearing it through the camera.
VOX Mode (Voice Operated Exchange)
Activate VOX mode to conserve battery life. In this mode, the display unit's screen will turn off, but the audio monitoring remains active. The screen will automatically light up and display the video feed when the camera detects sound above a certain threshold (e.g., baby crying).
Image: Compares the display unit in VOX mode (screen off) and when activated by sound (screen on, showing crying baby).
Monitorování teploty a vlhkosti
The display unit shows the real-time temperature and humidity of the baby's room, detected by the camera unit. This helps ensure a comfortable environment for your baby. Alarms can be set for out-of-range temperatures.
Image: The display unit showing the current room temperature and humidity, with a baby in the background.
Ukolébavky
Select from a variety of pre-programmed lullabies to help soothe your baby to sleep. This feature can be activated from the display unit.
Image: A baby sleeping peacefully in a crib, with musical notes indicating lullabies playing from the baby monitor.
Připomenutí krmení
Set feeding reminders on the display unit to help maintain a consistent feeding schedule for your baby. An alarm will sound at the set intervals.
Image: A mother feeding her baby, with an overlay showing the feeding reminder icon on the baby monitor display.
Úložiště SD karty
The Codnida Baby Monitor supports FAT32 Micro SD cards up to 256GB (not included) for video recording. You can record videos directly from the LCD screen or through the "Tuya" app.
Dosah převodovky
The monitor offers a transmission range of up to 700 feet (approximately 213 meters) in open areas, providing stable video transmission with low latency.
Image: A diagram showing a house layout with the baby monitor camera and display, illustrating the effective wireless transmission range.
Údržba
Čištění
Wipe the camera and display units with a soft, dry cloth. Do not use abrasive cleaners or solvents. Ensure the devices are unplugged before cleaning.
Skladování
When not in use for extended periods, store the baby monitor in a cool, dry place, away from direct sunlight and extreme temperatures. Ensure the battery is partially charged before storage to prolong its lifespan.
Odstraňování problémů
| Problém | Možná příčina | Řešení |
|---|---|---|
| No image on display unit. | Camera or display unit not powered on; out of range; not paired. | Ensure both units are powered on and charged. Move units closer. Re-pair units (refer to manual for pairing steps if needed, usually a button on camera and menu option on display). |
| Špatná kvalita obrazu. | Low light conditions (night vision active); camera lens dirty; interference. | Ensure adequate lighting if not using night vision. Clean camera lens gently. Move away from other electronic devices. |
| Žádný zvuk nebo zkreslený zvuk. | Volume too low; microphone blocked; out of range. | Increase volume on display unit. Ensure camera microphone is not covered. Move units closer. |
| Režim VOX se neaktivuje. | Sensitivity setting too low. | Adjust VOX sensitivity in the display unit's settings. |
| Problémy s připojením k aplikaci. | Incorrect Wi-Fi password; weak Wi-Fi signal; camera not in pairing mode. | Verify Wi-Fi password. Ensure camera is within Wi-Fi range. Follow app's pairing instructions carefully, including resetting the camera if necessary. |
Specifikace
| Funkce | Detail |
|---|---|
| Číslo modelu | YM-MWM553+MWZ553C-New |
| Velikost displeje | 5.5palcový LCD |
| Rozlišení videa | 2K (3MP, 1296p/1440 effective) |
| Digitální zoom | 4X |
| Rozsah nočního vidění | Až 5 metrů |
| Battery Capacity (Display) | 4000 mAH |
| Battery Life (Live View) | Až 14 hodin |
| Battery Life (VOX Mode) | Až 28 hodin |
| Dosah převodovky | Up to 700 feet (approx. 213 meters) in open areas |
| Konektivita | Bezdrátové připojení (Wi-Fi pro aplikaci) |
| Skladování | Supports FAT32 Micro SD card up to 256GB |
| Materiál | Plast |
| Rozměry (D x Š x V) | 10 x 5 x 10 cm |
| Hmotnost | 850 gramů |
| Zdroj napájení | Wired (5V, 3.8W) |
| Typ alarmu | Zvuk a pohyb |
Záruka a podpora
Codnida offers a 1-letá záruka a a 30denní zásada vrácení for this product. If you have any questions or encounter issues with your baby monitor, please contact Codnida customer service.
To contact customer support, navigate to 'Your Account - Your Order - Ask a Question' on the Amazon platform where you purchased the product.
