YI Smart Security Camera 360° PTZ Dome Camera User Manual

1. Úvod

Thank you for choosing the YI Smart Security Camera 360° PTZ Dome Camera. This camera provides comprehensive surveillance with its 360° pan and tilt capabilities, delivering crystal-clear 1080p Full HD video. Designed for indoor use, it features advanced motion detection, smart auto-tracking, enhanced night vision, and two-way audio communication. This manual will guide you through the setup, operation, and maintenance of your new security camera.

Klíčové vlastnosti:

• 360° pokrytí: 355° horizontal and 90° vertical rotation for zero blind spots.
• 1080p Full HD: High-definition video for clear monitoring.
• Detekce pohybu a automatické sledování: Alerts and tracks moving objects automatically.
• Vylepšené noční vidění: Multiple modes including full-color night vision.
• Obousměrný zvuk: Vestavěný mikrofon a reproduktor pro komunikaci v reálném čase.
• Flexibilní úložiště: Supports Cloud storage and local storage via microSD card (up to 128GB).

2. Obsah balení

Zkontrolujte prosím balení, zda neobsahuje následující položky:

• YI Smart Security Camera x1
• USB kabel x1
• User Manual x1 (This document)

3. Konec produktuview

Familiarize yourself with the components of your YI Smart Security Camera.

Obrázek 3.1: Přední strana view of the YI Smart Security Camera, showing the lens, LED lights, and two antennas.

Figure 3.2: Dimensions of the YI Smart Security Camera, indicating a height of 180mm (7.08in), width of 102mm (4.0in), and depth of 85mm (3.34in).

4. Nastavení a instalace

4.1 Počáteční zapnutí

1. Connect the provided USB cable to the camera's power port and plug the other end into a compatible USB power adapter (not included).
2. The camera will power on and initiate its self-test sequence. Wait for the indicator light to flash, indicating it's ready for setup.

4.2 Stažení aplikace a vytvoření účtu

1. Stáhněte si YI IOT App z App Storu (iOS) nebo z Obchodu Google Play (Android).
2. Otevřete aplikaci a postupujte podle pokynů na obrazovce a vytvořte si nový účet, nebo se přihlaste, pokud již nějaký máte.

4.3 Adding Your Camera to the App

1. In the YI IOT App, tap the "+" icon to add a new device.
2. Select your camera model from the list.
3. Follow the app's instructions to connect the camera to your 2.4GHz Wi-Fi network. This typically involves scanning a QR code generated by the app with the camera's lens.
4. Po připojení můžete kameru pojmenovat a spustit živý přenos viewIng.

4.4 Montáž fotoaparátu

The camera is designed for indoor use and can be placed on a flat surface or wall-mounted. For wall mounting, use the included mounting accessories (if applicable) and ensure the camera is securely fastened.

Obrázek 4.1: Přamples of multi-scene applications, including wall and ceiling mounting, and placement in living rooms, bedrooms, and studies.

5. Ovládání fotoaparátu

5.1 Ovládání otáčení a naklápění

The YI Smart Security Camera offers extensive pan and tilt capabilities, allowing you to monitor a wide area.

• Horizontální rotace: 355°
• Vertikální rotace: 90°

In the YI IOT App, use the directional controls on the live view screen to remotely adjust the camera's viewúhel.

Figure 5.1: Illustration of the camera's 355° horizontal pan and 90° vertical tilt capabilities, providing a wide field of view.

5.2 Motion Detection & Smart Auto Tracking

The camera can detect movement and automatically track objects, sending alerts to your smartphone.

• Detekce pohybu: When motion is detected, the camera will send an instant push notification with a 6-second video clip to your phone via the YI IOT App.
• Smart Auto Tracking: If enabled, the camera will automatically follow moving objects for up to 10 seconds after detection, ensuring continuous monitoring of the activity.

Adjust sensitivity settings and notification preferences within the app.

Figure 5.2: Real-time alarm notification on the YI IOT app, showing an intruder detected by the camera.

Figure 5.3: The camera's motion tracking feature focusing on a moving pet.

Figure 5.4: Visual representation of a motion detection alert, showing the camera capturing movement and sending notifications.

5.3 Vylepšené noční vidění

The camera is equipped with ultra-long-distance infrared LEDs and floodlight LEDs, offering multiple night vision modes for clear visibility in low-light conditions.

• Normální noční vidění: Standard black and white infrared view.
• Inteligentní noční vidění: Automatically switches between infrared and full-color based on detected activity.
• Plně barevné noční vidění: Provides a color image even in low light, utilizing the built-in floodlight.

You can switch between these modes directly from the YI IOT App.

Figure 5.5: Comparison illustrating the difference between standard infrared night vision (monochrome) and 1080p full-color night vision.

5.4 Obousměrný zvuk

Communicate through the camera using its built-in microphone and high-power speaker.

• Režim interkomu: Press and hold the microphone icon in the app to speak, and release to listen. Ideal for giving commands to pets or deterring unwanted visitors.
• Režim hands-free: Allows for a continuous two-way conversation, similar to a phone call.

Figure 5.6: Demonstration of real-time two-way talk, allowing communication between the camera's location and the app user.

5.5 Cloud & Local Storage

Your camera offers flexible storage options for your video footage.

• YI Cloud Storage: Securely store 6-second video clips triggered by motion or sound detection. This ensures your footage is safe from loss, theft, or damage to local storage. Available for both iOS and Android.
• Místní úložiště: The camera supports microSD cards up to 128GB (not included) for continuous recording or event-triggered recordings.

6. Údržba

Pro zajištění optimálního výkonu a dlouhé životnosti fotoaparátu dodržujte tyto pokyny pro údržbu:

• Čištění: Jemně otřete objektiv a tělo fotoaparátu měkkým, suchým hadříkem. Nepoužívejte agresivní chemikálie ani abrazivní materiály.
• Aktualizace firmwaru: Regularly check for and install firmware updates via the YI IOT App. Updates often include performance improvements, new features, and security enhancements.
• Cyklus napájení: If the camera becomes unresponsive, unplug it from the power source for 10 seconds, then plug it back in to restart it.

7. Řešení problémů

Pokud narazíte na problémy s fotoaparátem, podívejte se na následující běžné problémy a jejich řešení:

If the problem persists, please contact YI customer support.

8. Specifikace

Detailed technical specifications for the YI Smart Security Camera.

9. Záruka a podpora

For warranty information and technical support, please refer to the official YI website or contact their customer service directly. Details can typically be found on the product packaging or within the YI IOT App's 'About' or 'Support' section.

Online podpora: Visit the official YI webweb s nejčastějšími dotazy, průvodci řešením problémů a možnostmi kontaktování.

Podpora aplikace: Access support resources directly within the YI IOT App.
