Zavedení
This manual provides essential information for the safe and efficient operation of your AVOID Radiator Fan. Please read these instructions carefully before installation and use, and retain them for future reference.
The AVOID Radiator Fan is designed to improve heat distribution from your radiators, leading to increased comfort and potential energy savings by optimizing your heating system's efficiency.
Bezpečnostní pokyny
- Ensure the power adapter and cable are not damaged before use.
- Nevystavujte zařízení vodě ani nadměrné vlhkosti.
- Uchovávejte mimo dosah dětí a domácích zvířat.
- Nepokoušejte se zařízení sami otevírat ani opravovat. Pro servis se obraťte na kvalifikovaný personál.
- Ensure proper ventilation around the radiator and fan units.
- Používejte pouze dodaný napájecí adaptér.
Obsah balení
Ověřte, zda jsou v balení přítomny všechny položky:
- AVOID Radiator Fan Unit(s) (Quantity may vary based on set purchased)
- Napájecí adaptér
- Connection Cable with Integrated Temperature Sensor
Image: The AVOID Radiator Fan set, showing multiple fan units, a power adapter, and a cable with an integrated temperature sensor.
Nastavení
- Umístění: Identify the underside of your radiator or convector where the fan units will be placed. Ensure there is sufficient space for the units.
- příloha: The AVOID Radiator Fan units feature integrated magnets for easy attachment. Simply place the fan unit(s) directly onto the metal underside of your radiator. The magnets will secure them in place.
- Bezešvý střih: The fan units are designed to fit discreetly under most radiators and convectors, optimizing air circulation without being obtrusive.
- Connecting Multiple Units (if applicable): If you have purchased a set with multiple fan units for a longer radiator, connect them in series using the provided connectors. This ensures full coverage and optimal heat distribution.
- Připojení napájení: Connect the cable with the integrated temperature sensor to the fan unit(s). Then, plug the power adapter into a standard electrical outlet.
Image: A user installing the AVOID Radiator Fan by magnetically attaching it to the underside of a radiator.
Obrázek: Podrobný view showing the AVOID Radiator Fan units neatly installed beneath a radiator, demonstrating their compact and integrated design.
Image: Several AVOID Radiator Fan units are shown connected together and installed beneath a long radiator, illustrating how to achieve full coverage.
Image: A single AVOID Radiator Fan unit is displayed alongside its power adapter and the connection cable featuring an integrated temperature sensor.
Návod k obsluze
The AVOID Radiator Fan operates automatically based on the ambient temperature detected by its integrated sensor.
- Automatická aktivace: The fan will automatically switch on when the temperature around the sensor reaches approximately 33°C.
- Automatická deaktivace: The fan will automatically switch off when the temperature drops to approximately 25°C.
- This automatic operation ensures that the fan only runs when heat distribution is beneficial, optimizing energy usage.
Image: A visual representation of the AVOID Radiator Fan's benefits, showing improved heating efficiency, elimination of cold spots, and overall energy savings within a home environment.
Benefits of Operation:
- Faster Heat Distribution: The fans actively circulate warm air, distributing heat throughout the room up to 50% faster than convection alone.
- Energetická účinnost: By enhancing heat distribution, the system can help reduce gas consumption by up to 22%, contributing to lower heating costs.
- Konzistentní pohodlí: The improved air circulation helps to minimize temperature fluctuations, creating a more uniformly heated and comfortable living space.
- Tichý provoz: The fans are designed for quiet operation, ensuring they do not disrupt your home environment.
Image: A family is shown in a comfortable room, with graphics indicating the enhanced and faster heat distribution provided by the radiator fan.
Image: A person is shown relaxing in a room, indicating the enhanced comfort and stable temperatures achieved with the AVOID Radiator Fan.
Image: A person is shown in a quiet setting, emphasizing the low noise level of the AVOID Radiator Fan during operation.
Údržba
- Čištění: Periodically clean the fan units to prevent dust buildup, which can affect performance. Disconnect the power before cleaning. Use a soft, dry cloth or a small brush to gently remove dust from the fan blades and housing. Do not use liquid cleaners.
- Inspekce: Regularly inspect the power cable and adapter for any signs of damage. If damage is found, discontinue use and contact customer support.
Odstraňování problémů
| Problém | Možná příčina | Řešení |
|---|---|---|
| Ventilátor se nezapne. | No power, temperature below activation threshold, or faulty connection. |
|
| Fan runs continuously or turns off too quickly. | Temperature sensor issue or incorrect placement. |
|
| Reduced airflow or noise. | Dust buildup on fan blades. |
|
Specifikace
| Značka | VYHNĚTE SE |
| Číslo modelu | Radiatorventilator |
| Výrobce | Verbo |
| Barva | Bílý |
| Materiál | Plast, kov |
| svtage | 12 V stejnosměrného proudu (VDC) |
| Wattage | 7 wattů |
| Typ napájecího konektoru | 2pinový |
| Způsob chlazení | Nucená konvekce |
| Kompatibilní zařízení | Radiators, Convectors |
Záruka a podpora
Informace o záruce a zákaznické podpoře naleznete v dokumentaci dodané s vaším nákupem nebo se obraťte přímo na prodejce. Uschovejte si doklad o koupi pro případné reklamace.
For further assistance, please visit the AVOID brand webnebo kontaktujte jejich oddělení zákaznických služeb.
