TOPUTURE 2-in-1 Smart Treadmill User Manual

1. Úvod

Thank you for choosing the TOPUTURE 2-in-1 Smart Treadmill. This manual provides essential information for the safe and effective use of your new fitness equipment. Please read it thoroughly before operation and keep it for future reference.

2. Bezpečnostní pokyny

VAROVÁNÍ: Abyste snížili riziko vážného zranění, přečtěte si před použitím běžeckého pásu všechna důležitá bezpečnostní opatření a pokyny v této příručce.

• Před zahájením jakéhokoli nového cvičebního programu se vždy poraďte se zdravotníkem.
• Place the treadmill on a flat, stable surface with at least 2 meters of clear space behind it and 0.6 meters on each side.
• Ensure the safety key is properly attached to your clothing before starting the treadmill. In case of emergency, the safety key will detach, stopping the machine.
• Nedovolte dětem ani domácím zvířatům vstupovat do blízkosti běžeckého pásu, když je v provozu.
• Wear appropriate athletic footwear and clothing. Avoid loose clothing that could get caught in the machine.
• Nestupujte na běžecký pás ani z něj nesstupujte, pokud se pás pohybuje.
• Maximální nosnost tohoto běžeckého pásu je 130 kg (286 liber). Nepřekračujte tento limit.
• Odpojte běžecký pás ze zásuvky, pokud jej nepoužíváte, nebo před čištěním a údržbou.
• Pokud pocítíte závratě, nevolnost, bolest na hrudi nebo jakékoli jiné abnormální příznaky, okamžitě přerušte cvičení a poraďte se s lékařem.

3. Konec produktuview

The TOPUTURE 2-in-1 Smart Treadmill offers versatile exercise options, functioning as both a walking pad and a traditional treadmill. Its compact design and advanced features make it ideal for home or office use.

This image illustrates the TOPUTURE 2-in-1 Smart Treadmill in both its running configuration with the handle upright and its under-desk walking pad configuration, highlighting its versatility for various exercise needs.

The treadmill supports two primary modes: a walking mode (1-6 km/h) and a running mode (6-12 km/h), catering to different fitness intensities.

Equipped with a powerful 2.5 HP motor, the treadmill operates quietly (below 45dB) and supports a maximum load of 130 kg, ensuring smooth and stable performance.

The 7-layer anti-slip running belt features internal silicone columns for powerful shock absorption, reducing impact on knees, muscles, and joints while minimizing noise.

4. Nastavení

The TOPUTURE 2-in-1 Smart Treadmill features a no-setup design, meaning it comes largely pre-assembled for your convenience.

4.1 Rozbalení a umístění

• Carefully remove the treadmill from its packaging. It weighs approximately 23 kg, so it is recommended to have two people for lifting.
• Place the treadmill on a firm, level surface. Ensure there is adequate clear space around the unit for safe operation.

4.2 Počáteční konfigurace

• Nastavení řídítek: If using in running mode, simply lift the handlebar into the upright position until it locks securely.
• Nastavení sklonu: The treadmill comes with a default incline of 2°. For an increased challenge, you can manually adjust the incline to 4.7° (equivalent to 7% incline) by inserting the provided screws into the designated holes at the rear of the treadmill. If no incline is desired, use it as is.
• Připojení napájení: Zapojte napájecí kabel do uzemněné elektrické zásuvky.

The treadmill offers a manual incline adjustment up to 7%, allowing users to increase workout intensity and calorie burn.

Weighing 23 kg and equipped with transport wheels, the treadmill is designed for easy movement and convenient storage under beds or sofas when not in use.

5. Návod k obsluze

Your TOPUTURE treadmill can be controlled via its integrated LED display, the remote control, or a smart application.

5.1 Zapnutí/vypnutí

• To power on, press the main power switch located near the base of the treadmill. The LED display will illuminate.
• To power off, press the main power switch again.

5.2 Spuštění a nastavení rychlosti

• Start: Press the 'Start' button on the LED display or the remote control. The treadmill will begin at a low speed.
• Nastavení rychlosti: Use the '+' and '-' buttons on the display or remote to increase or decrease the speed. The speed range is 1-12 km/h.
• Pauza: Press the 'Pause' button to temporarily stop your workout without losing your data. Press 'Start' to resume.
• Stop: Stiskněte tlačítko „Stop“ pro ukončení tréninku.

5.3 Výběr programu

The treadmill features 12 preset programs to vary your workout intensity. Refer to the detailed program descriptions in the full manual for specific speed and duration profiles.

5.4 LED Display and Remote Control

The multi-functional LED display shows real-time data including speed, distance, time, and calories burned. The remote control provides convenient access to speed and mode adjustments. The remote features a magnetic attachment, allowing it to be easily stored on the treadmill's armrest when not in use.

The integrated LED display provides real-time feedback on speed, time, distance, and calories. The remote control allows for convenient speed and mode adjustments, and can be magnetically attached to the armrest.

The treadmill includes a phone/tablet holder, a magnetic remote for easy storage, a safety lock for emergency stops, and quick-release mechanisms for folding.

5.5 Připojení APP

Enhance your training experience by connecting your treadmill to smart applications via Bluetooth (Bluetooth name: TP3). Compatible apps like 'FITSHOW' allow you to access various training courses and track your progress from your home or gym.

• Download the 'FITSHOW' app from your device's app store (App Store or Google Play).
• Povolte Bluetooth na svém smartphonu nebo tabletu.
• Open the 'FITSHOW' app and follow the on-screen instructions to connect to the treadmill (look for 'TP3').
• Once connected, you can control the treadmill, select programs, and monitor your workout data directly from the app.

Connect your treadmill to fitness apps like FitShow or Zwift via Bluetooth to access guided workouts and enhance your exercise routine.

6. Údržba

Pravidelná údržba zajistí dlouhou životnost a optimální výkon vašeho běžeckého pásu.

6.1 Mazání

The running belt requires periodic lubrication to reduce friction and wear. Your treadmill features a convenient lubrication point for easy application.

• Use only 100% silicone treadmill lubricant.
• Refer to the full manual for specific lubrication frequency based on usage. Generally, lubricate every 3-6 months or after 50-100 hours of use.
• Apply a small amount of lubricant directly into the lubrication port.

6.2 Čištění

• Před čištěním vždy odpojte běžecký pás ze zásuvky.
• Vnější povrchy otřete měkkým, damp hadříkem. Nepoužívejte abrazivní čisticí prostředky ani rozpouštědla.
• Periodically vacuum under the treadmill to remove dust and debris.

6.3 Skladování

Když se běžecký pás nepoužívá, lze jej složit a uskladnit, aby se ušetřilo místo.

• Ujistěte se, že je běžecký pás vypnutý a odpojený od sítě.
• Sklopte řídítka.
• Utilize the transport wheels at the base to easily move the treadmill for storage under a bed, sofa, or upright against a wall.

7. Řešení problémů

If you encounter any issues with your treadmill, please refer to the following common solutions. For problems not listed here, contact customer support.

• Běžecký pás se nespouští: Ensure the power cord is securely plugged in and the main power switch is on. Check if the safety key is properly placed.
• Prokluzování pásu: The running belt may need tension adjustment or lubrication. Refer to the full manual for instructions on adjusting belt tension.
• Neobvyklý hluk: Check for loose parts or foreign objects under the belt. Ensure the treadmill is on a level surface. Lubrication may also be required.
• Displej nefunguje: Check power connection. If the display is still unresponsive, contact customer support.
• Problémy s připojením aplikace: Ujistěte se, že je na vašem zařízení povoleno Bluetooth a běžecký pás je zapnutý. Zkuste restartovat aplikaci i běžecký pás.

8. Specifikace

9. Záruka a podpora

For warranty information, technical support, or any inquiries regarding your TOPUTURE 2-in-1 Smart Treadmill, please refer to the warranty card included with your product or contact the seller/manufacturer directly. Keep your purchase receipt as proof of purchase.
