1. Úvod
The Longer Laser B1 30W Laser Engraver Cutter is a versatile tool designed for precision engraving and cutting across various materials. This manual provides essential information for safe operation, setup, and maintenance to ensure optimal performance and longevity of your device.
Key features include a powerful 36W laser output capable of cutting through 25mm basswood and 50mm acrylic, a high working speed of up to 36,000 mm/min, and a large working area of 450 x 440 mm. It supports colorful engraving on mirrored stainless steel and integrates an automatic air-assist pump for enhanced precision and quality.
2. Bezpečnostní informace
WARNING: Laser radiation can cause eye damage and skin burns. Always wear appropriate eye protection and ensure proper ventilation during operation.
The Laser B1 is equipped with eight major safety features to protect users and prevent accidents:
- Move Detection: Stops operation if the machine is moved unexpectedly.
- Flame Detector: Triggers an alarm and stops the laser if a flame is detected.
- Offline Protection: Halts operation if connection is lost.
- Motionless Protection: Automatically stops if the laser module remains stationary for too long while active.
- Bezpečnostní zámek: Zabraňuje neoprávněnému použití.
- Ochrana očí: The laser module features panoramic light filtering glass to block blue light and filter 97% of ultraviolet light.
- Tlačítko nouzového zastavení: V případě nouze okamžitě vypne napájení laseru.
- Nulový reset: Ensures safe homing of the laser module.
Image: Longer Laser B1 with visual indicators for flame detection and position movement protection.
3. Konec produktuview
The Longer Laser B1 is designed for precision and efficiency. Understanding its components and capabilities is key to effective use.
3.1 Klíčové vlastnosti
- Powerful Laser Output: 36W output power, capable of cutting 25mm basswood and 50mm acrylic.
- Vysokorychlostní výkon: Engraving speed up to 36,000 mm/min.
- Velká pracovní plocha: 450 x 440 mm (17.72 x 17.32 inches).
- Automatický vzduchový asistent: Controlled via Lightburn software for cleaner cuts and engravings.
- Colorful Engraving: Direct engraving of colorful patterns on mirrored stainless steel.
- Konektivita: Supports USB, TF card, Wi-Fi, and APP control.
- Kompatibilita softwaru: Works with LaserGRBL (Windows XP/7/8/10) and Lightburn (Windows, macOS, Linux).
3.2 Komponenty
The main components of the Longer Laser B1 include the laser module, frame, control unit, and various accessories. Refer to the packaging for a complete list of included items.
Image: The Longer Laser B1 30W Laser Engraver Cutter.
4. Nastavení
Follow these general steps for assembling and preparing your Longer Laser B1 for operation. Detailed assembly instructions are typically provided in a separate guide included with your product.
- Rozbalení: Opatrně vyjměte všechny součásti z obalu. Zkontrolujte, zda jsou všechny součásti přítomny dle dodacího listu.
- Sestava rámu: Assemble the main frame of the laser engraver. Ensure all screws are tightened securely.
- Instalace laserového modulu: Mount the laser module onto the gantry. Connect the necessary cables.
- Air Assist Connection (if applicable): If your model includes an automatic air assist pump, connect it to the laser module and the control unit as per the specific instructions.
- Připojení napájení: Connect the power adapter to the control unit and then to a suitable power outlet.
- Instalace softwaru: Install the recommended software (Lightburn or LaserGRBL) on your computer. Drivers may be required for USB connection.
- Připojení APP: For mobile control, download the dedicated LaserBurn APP and follow the in-app instructions for Wi-Fi network distribution and connection.
Image: Initial setup of the laser engraver.
5. Návod k obsluze
Operating the Longer Laser B1 involves preparing your design, setting parameters, and executing the engraving or cutting process.
5.1 Software a konektivita
The Laser B1 supports multiple connection methods and software:
- Software: Lightburn (recommended for advanced users, compatible with Windows, macOS, Linux) and LaserGRBL (free, compatible with Windows XP/7/8/10).
- Způsoby připojení: USB cable, TF card, Wi-Fi, and dedicated mobile APP.
Image: Software and connectivity options for the Laser B1.
Image: The LaserBurn mobile application for controlling the engraver.
5.2 Příprava materiálu a gravírování/řezání
- Umístění materiálu: Place your material securely on the working area. Ensure it is flat and stable.
- Nastavení zaostření: Upravte zaostření laseru podle tloušťky materiálu.
- Design Import and Parameter Settings: Import your design into the software. Set appropriate parameters for engraving or cutting, including speed, power, and passes, based on the material type and desired outcome.
- Air Assist Activation: If using the automatic air assist, ensure it is enabled in your software settings for optimal results, especially when cutting.
- Zahájení provozu: Initiate the engraving or cutting process. Monitor the machine during operation.
Image: The automatic air assist pump improves engraving and cutting quality by removing smoke and debris.
5.3 Možnosti gravírování a řezání
The Longer Laser B1 excels in various applications:
- Wood Engraving: Achieve detailed and precise designs on wood.
- Metal Engraving: Create intricate patterns on metal surfaces, including colorful engraving on mirrored stainless steel.
- Acrylic Cutting: Capable of cutting thick acrylic sheets with clean edges.
- Další materiály: Suitable for paper, glass, leather, and more.
Video: Demonstration of color acrylic engraving and cutting with the Longer Laser B1.
Video: Creating a jewelry box using the Longer Laser B1 engraver.
6. Údržba
Pravidelná údržba zajišťuje dlouhou životnost a optimální výkon vašeho laserového gravírovacího stroje.
- Čištění objektivu: Pravidelně čistěte laserovou čočku měkkým hadříkem, který nepouští vlákna, a roztokem na čištění čoček, abyste zachovali kvalitu gravírování.
- Čištění pracovního prostoru: Remove debris and dust from the honeycomb working area after each use.
- Mazání: Apply a small amount of lubricant to the guide rails and lead screws as recommended in the detailed product manual to ensure smooth movement.
- Kontrola kabelů: Regularly check all cables for wear or damage. Replace any damaged cables immediately.
- Aktualizace firmwaru: Keep the device firmware and software updated to benefit from performance improvements and new features.
7. Řešení problémů
This section addresses common issues you might encounter. For more complex problems, refer to the official Longer support resources.
| Problém | Možná příčina | Řešení |
|---|---|---|
| Laser nefunguje nebo má slabý výkon. | Loose cable connection, dirty lens, incorrect power settings, laser module malfunction. | Check all cable connections. Clean the laser lens. Verify power settings in software. Contact support if issue persists. |
| Engraving/cutting is inaccurate or distorted. | Loose belts, incorrect focus, material not flat, machine movement during operation. | Ensure belts are properly tensioned. Adjust laser focus. Secure material firmly. Check for any obstructions preventing smooth movement. |
| Machine not connecting to computer/APP. | Incorrect drivers, Wi-Fi issues, faulty USB cable, software conflict. | Install/update drivers. Check Wi-Fi connection and network settings. Try a different USB port/cable. Restart software and machine. |
| Smoke/fumes excessive during operation. | Insufficient ventilation, air assist not active, incorrect power settings. | Ensure adequate ventilation. Activate air assist in software. Reduce laser power if possible for the material. |
8. Specifikace
| Funkce | Detail |
|---|---|
| Značka | Delší |
| Číslo modelu | B1 |
| Výstupní výkon laseru | 36W |
| Pracovní rychlost | Až 36 000 mm/min |
| Pracovní oblast | 450 x 440 mm (17.72 x 17.32 palců) |
| Rozměry produktu | 17.31 x 4.9 x 17.72 palce |
| Hmotnost položky | 21.5 libry |
| Provozní režim | Automatický |
| Materiálová kompatibilita | Wood, Metal, Paper, Acrylic, Glass, Leather |
9. Záruka a podpora
The Longer Laser B1 comes with a standard warranty. Please refer to the warranty card included in your product packaging for specific terms and conditions. For technical assistance, troubleshooting, or warranty claims, please contact Longer3d Official Store customer support.
Kontaktní údaje:
- prodejce: Longer3d Official Store
- Odkaz na obchod na Amazonu: Longer Official Store on Amazon
