Cooler Depot CD-R2-24G Commercial Range and Oven

1. Úvod

This manual provides essential information for the safe and efficient installation, operation, and maintenance of your Cooler Depot CD-R2-24G Commercial Range and Oven. This unit is designed for heavy-duty restaurant use, featuring a 36-inch width, two open burners, and a 24-inch griddle, along with a spacious oven. Please read this manual thoroughly before installation and use, and retain it for future reference.

Klíčové vlastnosti:

• 36-inch wide commercial range with 2 open burners and a 24-inch griddle.
• Total BTU output of 211,000 BTU.
• Spacious oven with a 31,000 BTU/hr U-shape burner and thermostat control (250-550°F).
• Constructed with 304 and 430 stainless steel front and galvanized sides for durability.
• Equipped for both Natural Gas and Liquid Propane, with a 3/4" NPT rear gas connection.
• NSF/ETL Certified for commercial use.

2. Nastavení a instalace

The Cooler Depot CD-R2-24G is a freestanding commercial range and oven. Proper installation is crucial for safety and optimal performance. Installation must be performed by a qualified technician in accordance with all local codes and regulations.

2.1 Vybalení a kontrola

Upon receipt, carefully inspect the unit for any shipping damage. Report any damage immediately to the carrier and your dealer. Do not discard packaging materials until the unit has been inspected and installed.

2.2 Požadavky na umístění

• Zajistěte dostatečné větrání.
• Maintain proper clearances from combustible surfaces as per local codes.
• Place the unit on a level, stable, non-combustible surface. The unit features adjustable heavy-duty legs for leveling.

2.3 Připojení plynu

This unit is designed to operate with either Natural Gas or Liquid Propane. It comes with connectors for both fuel types. The gas connection is a 3/4" NPT rear connection.

• Ensure the gas supply matches the unit's configuration (Natural Gas or Propane).
• A gas pressure regulator must be installed.
• Všechny plynové přípojky musí být po instalaci zkontrolovány na těsnost.

3. Návod k obsluze

Familiarize yourself with the controls and functions before operating the unit.

3.1 Ovládací prvky Overview

The unit features five control knobs on the front panel:

• Two knobs for the open burners.
• Two knobs for the 24-inch griddle.
• One central knob for the oven thermostat control.

A standby stainless steel pilot system is integrated for easy ignition of burners and griddle.

3.2 Otevřete hořáky

The unit features two 12"x12" heavy-duty cast iron grates, each with an open burner providing 30,000 BTU/hr. These are suitable for boiling, sautéing, and simmering.

• To ignite, turn the corresponding burner knob to the "ON" position while simultaneously pushing it in to engage the pilot.
• Adjust flame intensity using the knob.
• An anti-clogging pilot cover is located under the grate for consistent ignition.

3.3 Griddle Operation

The 24-inch griddle plate, 3/4" thick, is ideal for frying, grilling, and other flat-top cooking. It includes a splash guard for convenience.

• Turn the griddle knobs to the "ON" position and push in to ignite the pilot.
• Allow the griddle to preheat thoroughly before cooking.
• Adjust temperature as needed using the dedicated griddle knobs.

3.4 Provoz trouby

The oven features a 31,000 BTU/hr U-shape burner and a thermostat control ranging from 250°F to 550°F. It is suitable for warming, baking, and roasting.

• To ignite the oven, turn the central oven knob to the desired temperature and push it in to engage the pilot.
• The oven is equipped with a thermal coupling safety valve for protection.
• Two chrome-plated racks can be positioned in four different versatile positions within the oven cavity.

4. Údržba a čištění

Regular cleaning and maintenance will extend the life and ensure the efficient operation of your commercial range and oven.

4.1 Denní čištění

• Vnější: Otřete povrchy z nerezové oceli čističemamp hadříkem a jemným čisticím prostředkem. Vyhněte se abrazivním čisticím prostředkům.
• Rošty: Remove cast iron grates and clean with a wire brush or scraper. Wash with warm, soapy water.
• Mřížka: Scrape off food residue. Clean the griddle surface with a griddle brick or pad. Season as needed.
• Zásobník na drobky: The pull-out crumb tray with an angled handle should be emptied and cleaned daily.
• Interiér trouby: The porcelanized bottom makes cleaning easy. Wipe down with a damp cloth after each use once cooled.

4.2 Pravidelná údržba

• Inspect gas connections and hoses for leaks or damage regularly.
• Pro optimální výkon plamene se ujistěte, že jsou otvory hořáku čisté a bez nečistot.
• Check oven door gasket for wear and tear to maintain heat efficiency.
• Professional inspection and servicing are recommended annually.

5. Řešení problémů

This section addresses common issues that may arise during the operation of your commercial range and oven. For problems not listed here, or if solutions do not resolve the issue, contact qualified service personnel.

5.1 Burner/Griddle Not Igniting

• Zkontrolujte přívod plynu: Ensure the main gas valve is open and there is gas pressure.
• Kontrolka: Verify the pilot light is lit. If not, re-ignite according to operating instructions.
• Clogged Pilot: Clean the anti-clogging pilot cover and burner ports if obstructed.

5.2 Oven Not Heating

• Nastavení termostatu: Ensure the oven thermostat knob is set to the desired temperature.
• Kontrolka: Confirm the oven pilot light is lit.
• Thermal Coupling: A faulty thermal coupling safety valve may prevent gas flow. This requires professional service.

5.3 Nerovnoměrné vytápění

• Vyrovnání: Ensure the unit is level using the adjustable legs.
• Porty hořáku: Clean any clogged burner ports on the open burners or oven burner.
• Griddle Seasoning: For griddles, proper seasoning helps with even heat distribution.

6. Specifikace

7. Záruka a podpora

7.1 Informace o záruce

This Cooler Depot commercial range and oven comes with a 1letá záruka na díly a a 1-year labor warranty from the date of purchase. This warranty covers defects in material and workmanship under normal use and service.

For functional failures within 1 month of purchase, you may be eligible for a free return. Please retain the original pallet and packaging material, as these will be required for any return shipments.

7.2 Zákaznická podpora

For technical assistance, warranty claims, or to inquire about service, please contact Cooler Depot customer support. Have your model number and purchase date ready when contacting support.

Kontaktní informace (např. telefonní číslo, e-mail, webstránky) by zde obvykle poskytoval výrobce.
