Vivotek ND9426P 16-Channel 2 Bay Embedded PoE AI Network Video Recorder User Manual

1. Úvod

This manual provides comprehensive instructions for the installation, operation, and maintenance of your Vivotek ND9426P Network Video Recorder (NVR). The ND9426P is a 16-channel, 2-bay embedded NVR with Power over Ethernet (PoE) capabilities and integrated Artificial Intelligence (AI) features, designed for robust surveillance applications. Please read this manual thoroughly before using the device to ensure proper setup and functionality.

2. Bezpečnostní informace

• Ensure the NVR is installed in a well-ventilated area to prevent overheating.
• Používejte pouze napájecí adaptér dodaný se zařízením.
• Do not expose the NVR to water, moisture, or extreme temperatures.
• Avoid placing heavy objects on top of the NVR.
• Před prováděním jakékoli údržby nebo instalace odpojte napájení.
• Veškerý servis svěřte kvalifikovanému personálu.

3. Obsah balení

Verify that all items listed below are included in your package. If any items are missing or damaged, contact your vendor immediately.

• Vivotek ND9426P NVR Unit
• Napájecí adaptér
• USB myš
• Průvodce rychlou instalací
• HDD Mounting Screws

4. Fyzický overview

Familiarize yourself with the front and rear panels of the Vivotek ND9426P NVR.

Figure 1: Front Panel of Vivotek ND9426P NVR. This image displays the front of the NVR unit, featuring the VIVOTEK brand logo on the left, two small indicator LEDs labeled "NET1" and "STATUS" in the center, and a blue USB 3.0 port on the right. The overall casing is a dark gray metallic finish.

4.1 Přední panel

• VIVOTEK Logo: Označuje značku.
• NET1 LED: Network activity indicator for LAN port 1.
• STAVOVÁ LED: Indikátor stavu systému.
• Port USB 3.0: For connecting a USB mouse, keyboard, or external storage devices.

4.2 Zadní panel (typická konfigurace)

While not pictured, the rear panel typically includes the following ports:

• PoE Ports (x16): RJ-45 ports for connecting IP cameras and providing power.
• LAN port: RJ-45 port for connecting the NVR to your local network.
• HDMI výstup: Pro připojení k monitoru nebo displeji.
• VGA výstup: Pro připojení k monitoru nebo displeji.
• Zvukový vstup/výstup: Pro připojení externích audio zařízení.
• USB porty: 2.0 Další USB porty pro periferie.
• Příkon: Pro připojení napájecího adaptéru.
• Uzemňovací terminál: Pro bezpečnostní uzemnění.

5. Nastavení

5.1 Instalace hardwaru

1. Instalace pevného disku:

   Odšroubujte kryt NVR casing to access the internal bays. Mount up to two 3.5-inch SATA hard drives using the provided screws. Reattach the casinbezpečně.
2. Připojení IP kamer:

   Connect your PoE-enabled IP cameras to the NVR's PoE ports using Ethernet cables. The NVR will provide power and data connectivity.

3. Connect Display and Mouse:

   Connect a monitor to the NVR's HDMI or VGA output port. Connect the USB mouse to one of the NVR's USB ports.

4. Internetové připojení:

   Connect the NVR's LAN port to your network router or switch using an Ethernet cable.
5. Zapnutí:

   Připojte napájecí adaptér k napájecímu vstupu NVR a poté jej zapojte do elektrické zásuvky. NVR se automaticky zapne.

5.2 Počáteční konfigurace

1. Upon first boot, the NVR will guide you through a setup wizard. Follow the on-screen instructions.
2. Set a strong password for the administrator account. This is crucial for security.
3. Configure network settings (DHCP or static IP).
4. Scan for and add connected IP cameras.
5. Nastavte datum, čas a časové pásmo.

6. Obsluha NVR

6.1 Navigace v uživatelském rozhraní

• Žít View: Access real-time video feeds from all connected cameras. Use the mouse to select camera views and layouts.
• Přehrávání: Review zaznamenané footage. Navigate through timelines, search by date/time, and export video clips.
• Nastavení nahrávání: Configure recording schedules (continuous, motion-triggered, event-based) and video quality for each camera.
• Správa akcí: Set up alerts for motion detection, tampering, or AI-triggered events. Configure notification methods (e.g., email, push notifications).
• Nastavení systému: Manage user accounts, network configurations, storage, and system logs.

6.2 Funkce umělé inteligence

The Vivotek ND9426P integrates advanced AI capabilities to enhance surveillance efficiency. These features may include:

• Inteligentní detekce pohybu: Differentiates between human/vehicle movement and environmental factors to reduce false alarms.
• Detekce narušení: Defines specific areas for monitoring and triggers alerts upon unauthorized entry.
• Line Crossing Detection: Detects when an object crosses a predefined virtual line.
• Refer to the NVR's on-screen interface or the detailed software manual for specific AI feature configuration.

7. Údržba

• Aktualizace firmwaru: Regularly check the VIVOTEK webPro zajištění optimálního výkonu a zabezpečení navštivte stránky s aktualizacemi firmwaru. Pro aktualizaci pečlivě dodržujte uvedené pokyny.
• Záloha dat: Periodically back up important recorded footage to external storage devices (e.g., USB drive, network storage) to prevent data loss.
• Systémové protokoly: Review system logs regularly for any error messages or unusual activity that may indicate a problem.
• Čištění: Keep the NVR unit clean and free from dust. Use a soft, dry cloth. Do not use liquid cleaners or aerosols. Ensure ventilation openings are not obstructed.

8. Řešení problémů

9. Specifikace

Note: Specifications are subject to change without notice. For the most current information, please refer to the official VIVOTEK product page.

10. Záruka a podpora

VIVOTEK products are covered by a limited warranty. For detailed warranty terms and conditions, please refer to the warranty card included with your product or visit the official VIVOTEK webmísto.

For technical support, product inquiries, or service requests, please contact your local VIVOTEK dealer or visit the VIVOTEK support portal online. Have your product model and serial number ready when contacting support.

• Oficiální VIVOTEK Webmísto: www.vivotek.com
• Portál podpory: Viz website for regional support contacts.
