Uživatelská příručka k bezdrátovému zvonku UCOCARE 4MP FHD X6

1. Úvod

Thank you for choosing the UCOCARE 4MP FHD Wireless Doorbell Camera X6. This manual provides detailed instructions for the installation, operation, and maintenance of your new doorbell camera. Please read this manual thoroughly before use to ensure proper functionality and safety. Keep this manual for future reference.

2. Obsah balení

Verify that all items listed below are included in your package. If any items are missing or damaged, please contact UCOCARE customer service.

• 1 x UCOCARE 4MP FHD Wireless Doorbell Camera X6
• 1 x 32GB Micro SD karta (předinstalovaná)
• 1 x Wireless Indoor Chime (requires 3 AAA batteries, included)
• 1 x nabíjecí kabel
• 1 x Sada šroubů a montážních nástrojů
• 1 x Uživatelská příručka

3. Konec produktuview

The UCOCARE X6 Wireless Doorbell Camera provides advanced security features for your home. It includes a 4MP camera for clear video, two-way audio, AI human detection, and local storage with a pre-installed 32GB SD card.

Obrázek 3.1: UCOCARE X6 Doorbell Camera, Chime, and Key Features.

Komponenty

• Doorbell Camera: Main unit with camera, motion sensor, microphone, speaker, and doorbell button.
• Bezdrátový zvonek: Receives signals from the doorbell and plays a customizable ringtone indoors.
• Micro SD karta: Pro lokální ukládání videa.

4. Nastavení

4.1 Instalace aplikace

1. Download the 'CloudEdge' app from your smartphone's app store (iOS App Store or Google Play Store).
2. Zaregistrujte si nový účet nebo se přihlaste, pokud již nějaký máte.

4.2 Párování zařízení

1. Ujistěte se, že je váš chytrý telefon připojen k Síť Wi-Fi 2.4 GHz. The doorbell camera does not support 5 GHz Wi-Fi.
2. Power on the doorbell camera.
3. Open the CloudEdge app and follow the on-screen instructions to add a new device.
4. Scan the QR code on the doorbell camera or manually select the device type.
5. Follow the prompts to connect the doorbell to your Wi-Fi network.
6. Pair the wireless chime by pressing its pairing button and then pressing the doorbell button on the camera.

Obrázek 4.1: Stable 2.4 GHz Wi-Fi Connection.

4.3 Fyzická instalace

1. Choose a suitable location for the doorbell camera, typically near your front door, ensuring a clear view a dobrý signál Wi-Fi.
2. Use the provided mounting bracket, screws, and tools to securely attach the doorbell camera to the wall.
3. Ensure the doorbell is installed at an appropriate height for optimal viewúhel.

5. Návod k obsluze

5.1 Živě View a kvalita videa

Access the live feed from your doorbell camera through the CloudEdge app. The camera offers 4MP Full HD resolution for clear day and night vision.

Obrázek 5.1: 4MP FHD Day and Night Vision.

The 4:3 aspect ratio provides a wider vertical field of view, allowing you to see visitors from head to toe and monitor packages on the ground without blind spots.

Obrázek 5.2: 4:3 Aspect Ratio for Comprehensive View.

5.2 Obousměrný zvuk a měnič hlasu

Engage in real-time conversations with visitors at your door using the two-way audio feature. The app also includes a voice changer function to protect your identity, offering options like 'Original', 'Clown', and 'Uncle' voices.

Obrázek 5.3: Two-Way Audio and Voice Changer Interface.

5.3 Detekce pohybu a upozornění

The doorbell camera features AI human detection, which intelligently identifies human presence and sends instant alert notifications to your smartphone. This minimizes false alarms from pets or inanimate objects.

Obrázek 5.4: Smart AI Human Detection and Instant Notifications.

You can customize detection zones and sensitivity settings within the app to focus on specific areas and reduce unwanted alerts.

5.4 Nahrávání a ukládání videa

The doorbell comes with a pre-installed 32GB Micro SD card for local storage, eliminating the need for monthly subscription fees. It supports up to 128GB SD cards (not included). Cloud storage options are also available.

Obrázek 5.5: 32GB Memory Card Pre-installed for Local Storage.

5.5 Bezpečnostní funkce

The doorbell camera includes a siren alarm and voice warning capabilities to deter potential intruders. It can also trigger a tamper alarm if someone attempts to remove it.

Obrázek 5.6: Siren and Voice Warning for Enhanced Security.

5.6 Integrace chytrého asistenta

The UCOCARE X6 is compatible with Alexa and Google Assistant. You can use voice commands to view the live feed from your doorbell on compatible smart displays.

Obrázek 5.7: Spolupracuje s Alexou a Google Assistant.

6. Údržba

6.1 Nabíjení baterie

The doorbell camera is equipped with a 10000 mAh rechargeable Lithium-ion battery. When the battery level is low, connect the doorbell to the provided charging cable and a compatible USB power adapter (not included). The app will notify you when charging is required.

6.2 Čištění

To maintain optimal performance, periodically clean the camera lens and the doorbell's exterior with a soft, damp tkanina. Vyhněte se používání agresivních chemikálií nebo abrazivních materiálů.

6.3 Podmínky prostředí

The UCOCARE X6 doorbell camera is IP66 waterproof, designed to withstand various weather conditions, including rain, snow, and dust. It operates effectively in temperatures ranging from -35°C to 60°C (-31°F to 140°F).

Obrázek 6.1: IP66 Waterproof and Weather Resistant.

7. Řešení problémů

• Zařízení se nepřipojuje k Wi-Fi: Ensure your router is broadcasting a 2.4 GHz Wi-Fi signal. Confirm the Wi-Fi password is correct. Move the doorbell closer to the router during setup.
• Žádná oznámení: Check app notification settings on your phone and within the CloudEdge app. Ensure the doorbell has a stable internet connection.
• Špatná kvalita videa: Verify Wi-Fi signal strength. Clean the camera lens. Ensure there are no obstructions.
• Rychlé vybíjení baterie: Reduce motion detection sensitivity or frequency. Adjust detection zones. Ensure the doorbell is not in an area with constant motion.
• Zvonkohra nezvoní: Ensure the chime is powered on and paired with the doorbell. Check chime battery levels (if applicable).

8. Specifikace

9. Informace o záruce

Please refer to your purchase documentation or the UCOCARE official website for detailed warranty information regarding your product. Warranty terms and conditions may vary by region and retailer.

10. Podpora

For technical assistance, product inquiries, or troubleshooting not covered in this manual, please contact UCOCARE customer service through the contact information provided on the official UCOCARE webweb nebo vaše nákupní platforma.
