Zavedení
This manual provides detailed instructions for the setup, operation, and maintenance of your Keychron M3 Mini 4K Wireless Optical Mouse. Designed for precision and performance, the M3 Mini features a lightweight magnesium alloy body, a high-performance PixArt 3395 sensor, and versatile connectivity options.
Image: The Keychron M3 Mini 4K Wireless Optical Mouse, showcasing its ergonomic design and perforated magnesium alloy shell, alongside its compact 4K wireless receiver.
Nastavení
Obsah balení
Ověřte, zda jsou v balení přítomny všechny položky:
- 1x Keychron M3 Mini Mouse
- 1x kabel Type-C to Type-C
- 1x adaptér typu A na typ C
- 1x bezdrátový 4K přijímač
Image: Diagram illustrating the contents of the Keychron M3 Mini package, including the mouse, cables, adapter, and 4K wireless receiver.
Počáteční nabíjení
Before first use, connect the mouse to a USB power source using the provided Type-C cable. The mouse features a 600 mAh battery. A full charge ensures optimal performance and battery life.
Připojení myši
The Keychron M3 Mini supports three connection modes: 2.4 GHz wireless, Bluetooth 5.1, and USB wired.
- 2.4 GHz Wireless Mode:
- Vložte bezdrátový 4K přijímač do volného USB portu v počítači.
- Switch the mode selector on the bottom of the mouse to the 2.4 GHz position.
- Myš by se měla automaticky připojit.
Image: The Keychron M3 Mini mouse positioned next to its 4K wireless receiver, illustrating the 2.4 GHz wireless connection method.
- Režim Bluetooth 5.1:
- Switch the mode selector on the bottom of the mouse to the Bluetooth position.
- V počítači přejděte do nastavení Bluetooth a vyhledejte nová zařízení.
- Select "Keychron M3 Mini" from the list to pair.
- Kabelový režim USB:
- Connect the mouse directly to your computer using the provided Type-C to Type-C cable or the Type-C to Type-A adapter.
- The mouse will function as a wired device and charge simultaneously.
Image: An illustration showing the Keychron M3 Mini mouse connected via USB cable and wirelessly via 2.4 GHz and Bluetooth 5.1, highlighting its stable and ultra-low latency response.
Software Installation (Keychron Engine)
For advanced customization, including button remapping, macro creation, and precise DPI/LOD adjustments, download and install the Keychron Engine software from the official Keychron website. This software is compatible with Windows, Mac, and Linux operating systems.
Image: Screenshot of the Keychron Engine software interface, displaying customization options for the M3 Mini mouse.
Provozní
Úprava DPI
The M3 Mini features a PixArt 3395 sensor, offering up to 26,000 DPI. You can adjust the DPI settings directly on the mouse using the dedicated DPI button on the underside, or through the Keychron Engine software for finer control.
Image: The Keychron M3 Mini mouse highlighting its PixArt 3395 sensor, capable of up to 26,000 DPI and 650 IPS for precise tracking.
Úprava rychlosti dotazování
The mouse supports polling rates up to 4000 Hz, providing highly responsive cursor movements. Adjust the polling rate using the dedicated button on the underside of the mouse or via the Keychron Engine software. The LED indicator on the mouse will change color to reflect the current polling rate setting.
Image: The Keychron M3 Mini mouse with text indicating its 4000 Hz Polling Rate capability.
| Report Rate Light Indicator | Polling Rate / Hz | Dostupné režimy |
|---|---|---|
| Bílý | 125 | 2.4G / BT / Wired |
| Modrý | 500 | 2.4G / Wired |
| Červený | 1000 | 2.4G / Wired |
| Modrá + Červená | 2000 | 2.4G |
| Bílá + červená | 4000 | 2.4G |
Table: Polling rate light indicator guide for the Keychron M3 Mini mouse.
Programovatelná tlačítka
Utilize the Keychron Engine software to customize the mouse buttons, assign macros, and create shortcuts for enhanced productivity and gaming.
Údržba
Čištění
To clean the mouse, use a soft, dry, lint-free cloth. For stubborn dirt, a slightly damp cloth with mild soap can be used, ensuring no moisture enters the internal components. Avoid harsh chemicals or abrasive materials.
Informace o baterii
The M3 Mini is equipped with a 600 mAh rechargeable battery. Expected battery life is up to 135 hours in 1K Polling Rate mode and approximately 40 hours in 4K Polling Rate mode. To preserve battery health, avoid extreme temperatures and prolonged periods of full discharge or charge.
Image: An illustration detailing the Keychron M3 Mini's internal components, including the 600 mAh battery, Huano 80M micro switches, and external DPI/polling rate adjustment buttons.
Skladování
When not in use for extended periods, store the mouse in a cool, dry place. It is recommended to charge the battery to about 50% before long-term storage.
Odstraňování problémů
- Myš nereaguje: Ensure the mouse is charged and the correct connection mode (2.4 GHz, Bluetooth, or Wired) is selected. For wireless modes, verify the receiver is properly connected or Bluetooth is paired.
- Zpoždění nebo zasekávání: Check for interference in 2.4 GHz mode. Ensure the receiver is close to the mouse. For Bluetooth, ensure no other devices are causing interference. Lowering the polling rate might also help in some scenarios.
- Problémy se softwarem: If experiencing problems with the Keychron Engine software, ensure you have the latest version installed from the official Keychron website. Try reinstalling the software if issues persist.
- DPI/Polling rate not changing: Confirm you are pressing the correct buttons on the underside of the mouse. If using software, ensure settings are applied and saved.
Specifikace
| Funkce | Detail |
|---|---|
| Model | M3Mini |
| Materiál těla | Slitina hořčíku |
| Hmotnost | 64 g (ultra lehký) |
| Senzor | Optický senzor PixArt 3395 |
| DPI | Až 26,000 XNUMX DPI |
| IPS | Až 650 IPS |
| Míra hlasování | Až 4000 Hz |
| Konektivita | 2.4 GHz Wireless, Bluetooth 5.1, USB Wired (Type-C) |
| Spínače | Huano 80M Micro Switches (80 million clicks lifespan) |
| Baterie | Dobíjecí 600 mAh |
| Výdrž baterie (přibližně) | 135 hours (1K Polling Rate), 40 hours (4K Polling Rate) |
| Rozměry | 121.50 mm (Length) x 66.70 mm (Width) x 40-60 mm (Height) |
| Operační systémy | Windows, Mac, Linux |
Table: Detailed technical specifications for the Keychron M3 Mini 4K Wireless Optical Mouse.
Image: The Keychron M3 Mini mouse from a top-down perspective, emphasizing its super lightweight design at only 64g.
Obrázek: Detailní záběr view of the Keychron M3 Mini mouse, highlighting its magnesium alloy body construction.
Záruka a podpora
Keychron products are covered by a limited warranty. For specific warranty terms, technical support, or service inquiries, please visit the official Keychron webwebové stránky nebo se obraťte přímo na jejich zákaznickou podporu. Uschovejte si doklad o koupi pro případ reklamace.
Oficiální Keychron Webmísto: www.keychron.com
