1. Bezpečnostní informace
Read and understand all safety precautions before operating this welding machine. Failure to follow these instructions can result in serious injury or death.
1.1 Obecná bezpečnostní upozornění
- Elektrický šok: Welding current can kill. Do not touch live electrical parts. Wear dry, insulating gloves and clothing. Ensure the work area is dry.
- Výpary a plyny: Welding produces fumes and gases hazardous to health. Work in a well-ventilated area. Use an exhaust fan or fume extractor.
- Obloukové paprsky: Obloukové paprsky mohou popálit oči a kůži. Používejte svářečskou kuklu s vhodným ochranným filtrem a ochranný oděv.
- Požár a výbuch: Welding sparks and hot metal can cause fires. Keep flammable materials away from the work area. Have a fire extinguisher readily available.
- Popáleniny: Horký kov a zařízení mohou způsobit těžké popáleniny. Používejte ochranné rukavice a oděv.
1.2 Osobní ochranné prostředky (OOP)
- Welding helmet with appropriate shade.
- Oděvy odolné proti ohni (s dlouhými rukávy a kalhotami).
- Leather welding gloves.
- Ochranné brýle nebo ochranné brýle.
- Ochrana sluchu.
2. Konec produktuview
The ARCCAPTAIN TIG205A (Model TIG200PACDC) is a versatile multi-process welding machine designed for both professional and hobbyist use. It supports TIG (Tungsten Inert Gas) welding in both AC (Alternating Current) and DC (Direct Current) modes, as well as MMA (Manual Metal Arc) or Stick welding. Featuring advanced MCU technology and an IGBT inverter, this machine offers precise control and stable arc performance.
The front panel of the ARCCAPTAIN TIG205A welder, highlighting the easy-to-read digital display and intuitive control buttons for selecting welding parameters.
The ARCCAPTAIN TIG205A welding machine shown with its standard accessories, including the TIG torch, ground clamp, and power cables, ready for setup.
3. Nastavení
3.1 Vybalení a kontrola
- Opatrně vyjměte svářečku a veškeré příslušenství z obalu.
- Inspect the machine for any signs of damage during shipping. Contact your supplier immediately if any damage is found.
- Ověřte, zda jsou přítomny všechny součásti uvedené v dodacím listu.
3.2 Připojení napájení
The TIG205A supports dual voltage input (110V/220V). Ensure the correct power cord is used and connected to a suitable power outlet with proper grounding.
- Connect the power plug to a dedicated circuit with adequate ampvymazat.
- Zajistěte zvtage selector (if present) is set correctly for your power supply.
3.3 Připojení plynu (pro svařování TIG)
For TIG welding, an inert shielding gas (typically Argon) is required.
- Connect the gas hose from the machine's gas inlet to your Argon gas cylinder's regulator.
- Ujistěte se, že všechna spojení jsou těsná, aby nedošlo k úniku plynu.
- Set the gas flow rate according to your welding application (typically 10-15 L/min).
3.4 Hořák a uzemnění Clamp Spojení
- Connect the TIG torch cable to the appropriate connector on the front panel.
- Připojte zem třamp kabel k určené zemnící svorce.
- Připojte zem třamp bezpečně upevnit k obrobku a zajistit tak dobrý elektrický kontakt.
3.5 Připojení držáku elektrody (pro svařování MMA)
- For MMA welding, connect the electrode holder cable to the positive (+) terminal.
- Připojte zem třamp kabel k zápornému (-) pólu.
This image illustrates the advanced LED control panel of the ARCCAPTAIN TIG205A, featuring detailed parameter adjustments like DownSlope and PostGas for improved weld quality, contrasted with a simpler, less functional panel found on other machines.
An internal diagram of the ARCCAPTAIN TIG205A welding machine, revealing its advanced MCU technology, IGBT inverter, and efficient cooling system, which contribute to its performance and reliability.
4. Návod k obsluze
4.1 Ovládací panel Overview
The ARCCAPTAIN TIG205A features a large LED display for easy parameter adjustment and monitoring.
A close-up of the ARCCAPTAIN TIG205A's comprehensive LED display, illustrating the detailed settings for AC TIG, DC TIG, MMA, and SPOT welding modes, including parameters like amperage, AC balance, frequency, and waveform selection (Square and Triangle waves).
4.2 Welding Modes and Parameter Adjustment
Use the 'Welding Mode' and 'Control Mode' buttons to navigate and adjust settings.
4.2.1 TIG Welding (AC TIG, DC TIG, Pulse TIG)
- Výběr režimu: Select AC TIG for aluminum and magnesium alloys, DC TIG for stainless steel, carbon steel, copper, and titanium. Pulse TIG offers enhanced control for thin materials and out-of-position welding.
- Proud (A): Adjust the welding amphodnota v závislosti na tloušťce a typu materiálu.
- DownSlope (S): Controls the time it takes for the welding current to decrease from the peak current to the crater current, preventing crater cracking.
- PostGas (S): Sets the duration for shielding gas flow after the arc is extinguished, protecting the hot weld puddle and tungsten electrode from atmospheric contamination.
- AC Balance (%): (For AC TIG) Adjusts the balance between electrode negative and electrode positive, controlling cleaning action and penetration.
- Frekvence (Hz): (For AC TIG) Adjusts the AC waveform frequency, influencing arc focus and bead width.
- HF Start: The High-Frequency Start feature ensures easy arc initiation without touching the workpiece, preserving tungsten integrity and preventing contamination.
A welder demonstrating the High-Frequency (HF) Start feature of the ARCCAPTAIN TIG205A, which ensures super easy arc initiation without contact, resulting in clean and precise weld beads on various metals.
4.2.2 MMA (obalené) svařování
- Proud (A): Nastavte amperage according to the electrode type and diameter.
- Arc Force: Helps prevent the electrode from sticking to the workpiece by temporarily increasing the current when the arc length becomes too short.
- Horký start: Provides an initial surge of current to make arc ignition easier, especially with difficult-to-start electrodes.
4.3 Kompatibilita materiálů
The ARCCAPTAIN TIG205A is capable of welding a wide range of materials:
- Hliník
- Slitina hořčíku
- Nerez
- Uhlíková ocel
- Měď
- Titan
This visual guide displays the diverse range of materials that can be welded using the ARCCAPTAIN TIG205A, including Aluminum, Magnesium Alloy, Stainless Steel, Carbon Steel, Copper, and Titanium, highlighting its versatility.
5. Údržba
Pravidelná údržba zajišťuje dlouhou životnost a optimální výkon vašeho svářecího stroje.
5.1 Čištění
- Periodically clean the machine's exterior with a dry, soft cloth.
- Use compressed air to blow out dust and debris from the ventilation openings. Ensure the machine is unplugged before cleaning.
- Clean the TIG torch collet body, collet, and gas lens regularly to ensure proper gas flow and arc stability.
5.2 Kontrola
- Zkontrolujte všechny kabely (napájecí, uzemňovací, hořák), zda nemají proříznutí, praskliny nebo roztřepenou izolaci. Poškozené kabely ihned vyměňte.
- Check all connections for tightness. Loose connections can cause overheating and poor performance.
- Ensure the cooling fan is free from obstructions and operating correctly.
5.3 Skladování
When not in use, store the welding machine in a clean, dry environment, away from excessive dust, moisture, and extreme temperatures.
6. Řešení problémů
Tato část obsahuje řešení běžných problémů, se kterými se můžete setkat.
| Problém | Možná příčina | Řešení |
|---|---|---|
| Stroj se nezapne | Žádné napájení; Vypnutý vypínač; Spálená vnitřní pojistka | Check power cord and outlet; Turn on power switch; Contact service for fuse replacement. |
| Žádný oblouk / Slabý oblouk | Poor ground connection; Incorrect current setting; Contaminated tungsten (TIG); Incorrect electrode (MMA) | Zajistěte uzemněníamp is secure; Adjust current; Clean/replace tungsten; Use correct electrode. |
| Špatná kvalita svaru (porovitost, kontaminace) | Insufficient shielding gas; Gas leak; Dirty workpiece; Incorrect PostGas setting | Check gas cylinder and flow rate; Inspect gas hose for leaks; Clean workpiece thoroughly; Adjust PostGas time. |
| Aktivována ochrana proti přehřátí | Překročení pracovního cyklu; Zablokované větrání; Vysoká okolní teplota | Nechte stroj vychladnout; Vyčistěte větrací otvory; Používejte v chladnějším prostředí. |
| Zobrazí se kód chyby | Specifická vnitřní chyba | Refer to the detailed error code list in the full manual (if available) or contact ARCCAPTAIN support. |
An infographic detailing the safety features integrated into the ARCCAPTAIN TIG205A welder, including Voltage Reduction Device (VRD), overvoltage protection, overload protection, overheating protection, and overcurrent protection, ensuring safe operation.
7. Specifikace
Technical specifications for the ARCCAPTAIN TIG205A (Model TIG200PACDC) welding machine.
| Funkce | Detail |
|---|---|
| Výrobce | ARCCAPTAIN |
| Číslo dílu | TIG200PACDC |
| Číslo modelu položky | TIG200PACDC |
| Rozměry balíku | 54.1 x 43.94 x 34.04 cm |
| Hmotnost položky | 16.5 kg |
| Jsou vyžadovány baterie? | Žádný |
| ASIN | B0C49XLTWP |
| Datum první dostupnosti | Listopad 27 2024 |
8. Záruka a podpora
ARCCAPTAIN products are manufactured to high-quality standards. For warranty information, technical support, or service inquiries, please refer to the official ARCCAPTAIN webnebo se obraťte přímo na jejich zákaznický servis. Uschovejte si účtenku jako doklad o koupi pro případ reklamace.
