TECWARE Phantom+ Elite 87 Key RGB Mechanical Gaming Keyboard User Manual

1. Úvod

This manual provides comprehensive instructions for the setup, operation, and maintenance of your TECWARE Phantom+ Elite 87 Key RGB Mechanical Gaming Keyboard. This keyboard offers versatile connectivity options, customizable RGB lighting, and a durable, user-friendly design.

Image: The TECWARE Phantom+ Elite 87 Key RGB Mechanical Gaming Keyboard, showcasing its compact layout and various features.

2. Obsah balení

Před zahájením instalace se ujistěte, že jsou k dispozici všechny položky:

• TECWARE Phantom+ Elite 87 Key RGB Mechanical Gaming Keyboard
• Špirálový kabel USB-C
• Nástroj na vytahování krytek kláves
• 4x Spare Switches (Wraith Red Switch)
• Wireless Dongle (2.4GHz)
• FN Function Guide Card
• Shroud V2 Cover

Video: An unboxing demonstration of the TECWARE Phantom+ Elite keyboard, showing all included accessories.

3. Nastavení

3.1 Režimy připojení

The Phantom+ Elite keyboard supports three connectivity modes: 2.4GHz Wireless, Bluetooth 5.0, and USB-C Wired. A switch on the back of the keyboard allows you to select between these modes.

Image: Visual representation of the three connectivity options for the keyboard.

3.2 Kabelové připojení USB-C

1. Connect the coiled USB-C cable to the keyboard's USB-C port.
2. Připojte druhý konec kabelu k volnému portu USB na počítači.
3. Ensure the mode switch on the keyboard is set to 'Wired' (usually indicated by a cable icon).
4. Klávesnice bude automaticky rozpoznána vaším operačním systémem.

3.3 Bezdrátové připojení 2.4 GHz

1. Locate the 2.4GHz wireless dongle included in the package.
2. Plug the wireless dongle into an available USB port on your computer.
3. Set the mode switch on the keyboard to '2.4G' (usually indicated by a wireless icon).
4. The keyboard should connect automatically. If not, press and hold the FN key + 4 for 3 seconds to initiate pairing.

3.4 Připojení Bluetooth 5.0

1. Set the mode switch on the keyboard to 'BT' (usually indicated by a Bluetooth icon).
2. V počítači nebo zařízení povolte Bluetooth a vyhledejte nová zařízení.
3. To enter pairing mode, press and hold the FN key + 1, 2, or 3 for 3 seconds. The corresponding key's backlight will flash rapidly, indicating it's ready to pair.
4. Select 'Phantom+ Elite' from the list of available Bluetooth devices on your computer.
5. Once paired, the backlight will stop flashing and remain solid. You can pair up to three Bluetooth devices and switch between them using FN + 1, 2, or 3.

3.5 Informace o baterii

The keyboard features a built-in 2500mAh rechargeable battery, providing up to 250 hours of continuous wireless use. The keyboard can be charged via the USB-C cable while in wired mode or connected to a power source.

4. Návod k obsluze

4.1 Přizpůsobení RGB osvětlení

The Phantom+ Elite keyboard offers 16.8 million colors and 18 preset lighting effects. You can control brightness, animation speed, and patterns directly on the keyboard or through the dedicated software.

Image: A visual guide to the 18 pre-set RGB lighting modes available on the keyboard.

Ovládací prvky na palubě:

• FN + Ins: Cycle through 18 preset lighting effects.
• FN + Del: Change lighting color (for modes that support it).
• FN + šipka nahoru/dolů: Upravte jas.
• FN + šipka vlevo/vpravo: Adjust animation speed.
• FN + Home: Spectrum Selection Mode (quick single-color selection).

4.2 Přepínače vyměnitelné za provozu

The keyboard features universal 5-pin hot-swappable sockets, allowing you to easily change switches without soldering. It is compatible with most MX-style mechanical switches.

Video: A demonstration of the hot-swappable 5-pin sockets, showing how to remove and install switches.

Image: An exploded diagram illustrating the internal components and the hot-swappable switch mechanism.

4.3 Keycaps and Stabilizers

The keyboard comes with durable double-shot PBT keycaps and V3 stabilizers that are factory clipped and lubed for a consistent typing experience.

Obrázek: Podrobný view of the double-shot PBT keycaps, highlighting their construction and durability.

Image: Components such as V3 stabilizers, sound dampening foam, and the dual-layer fiberglass PCB.

4.4 Softwarová podpora

The TECWARE Phantom+ Elite keyboard is supported by dedicated software for advanced customization. This software allows you to:

• Customize per-key RGB lighting.
• Control 18 lighting effects.
• Record and assign macros.
• Create and save up to 3 user profiles.
• Adjust brightness and speed of lighting effects.

Image: The software interface for customizing RGB lighting and other keyboard settings.

4.5 FN Function Guide

The FN key combined with other keys provides access to various functions. Refer to the included FN Function Guide card for a complete list of shortcuts.

Image: Specifications for the pre-lubed Wraith switches, including actuation force and travel distance.

5. Údržba

5.1 Čištění

• Před čištěním odpojte klávesnici od počítače.
• K otření povrchu klávesnice použijte měkký, suchý hadřík.
• For deeper cleaning, use the keycap puller tool to remove keycaps and clean dust or debris with compressed air or a small brush.
• Krytky kláves lze jemně omýt jemným mýdlem a vodou a před opětovným nasazením se ujistěte, že jsou zcela suché.

5.2 Výměna spínače

Thanks to the hot-swappable design, individual switches can be replaced if they become faulty or if you wish to change the typing feel.

1. Carefully remove the keycap using the provided keycap puller tool.
2. Use a switch puller (not included, but often bundled with switches) to gently grip the top and bottom clips of the switch.
3. Vytáhněte spínač přímo nahoru a vyjměte jej z desky plošných spojů.
4. Zarovnejte piny nového spínače s otvory na desce plošných spojů. Ujistěte se, že piny jsou rovné, aby se neohnuly.
5. Nový spínač pevně zatlačte na místo, dokud nezaklapne.
6. Znovu nasaďte krytku kláves.

6. Řešení problémů

• Klávesnice nereaguje: Ensure the keyboard is properly connected (wired, 2.4GHz dongle, or Bluetooth). Check the mode switch. For wireless modes, ensure the battery is charged.
• RGB osvětlení nefunguje: Verify that the lighting is enabled via FN key combinations or software. Check brightness settings.
• Klíče se neregistrují: If specific keys are not working, try replacing the switch for that key using the hot-swap feature. Ensure the switch is fully seated.
• Problémy s bezdrátovým připojením: For 2.4GHz, ensure the dongle is close to the keyboard and there are no obstructions. For Bluetooth, re-pair the device. Avoid interference from other wireless devices.
• Software nerozpoznává klávesnici: Ensure the keyboard is connected via USB-C and the software is up to date. Restart your computer and the software.

7. Specifikace

8. Záruka a podpora

For warranty information and technical support, please refer to the official TECWARE webnebo se obraťte přímo na jejich zákaznický servis. Uschovejte si doklad o koupi pro případ reklamace.

Online zdroje:

• Navštivte Obchod TECWARE na Amazonu pro informace o produktech a aktualizace.
