Uživatelská příručka k nabíječce VENTION 65W GaN se 3 porty USB (model FEDW0)

1. Úvod

This manual provides essential information for the safe and efficient use of your VENTION 65W GaN 3-Port USB Wall Charger. Please read it thoroughly before using the product and retain it for future reference.

2. Bezpečnostní pokyny

• Nevystavujte nabíječku kapalinám, vlhkosti ani extrémním teplotám.
• Nabíječku nerozebírejte, neupravujte ani se ji nepokoušejte opravovat.
• Zabraňte pádu na zem nebo vystavení nabíječky silným nárazům.
• Ujistěte se, že je nabíječka zapojena do řádně uzemněné zásuvky.
• Disconnect the charger from the power outlet when not in use or during electrical storms.
• Uchovávejte mimo dosah dětí.
• Používejte pouze s kompatibilními zařízeními a kabely.
• The charger may become warm during operation; this is normal. If it becomes excessively hot, disconnect it immediately.

Image: Charging Protections. This diagram highlights the built-in safety mechanisms of the charger, including protection against over-temperature, over-current, over-power, short circuits, over-voltage, and lightning.

3. Obsah balení

Ověřte, zda jsou v balení přítomny všechny položky:

• 1 x VENTION 65W GaN 3-Port USB Wall Charger (Model FEDW0)
• 1 x USB kabel
• 1 x Uživatelská příručka (tento dokument)

4. Konec produktuview

The VENTION 65W GaN 3-Port USB Wall Charger utilizes Gallium Nitride (GaN) technology for efficient power delivery in a compact form factor. It features two USB-C ports and one USB-A port, allowing for simultaneous charging of multiple devices.

Image: VENTION 65W GaN Charger. This image displays the front of the charger, highlighting its two USB-C ports and one USB-A port.

4.1 Klíčové vlastnosti

• 65W napájení: Capable of delivering up to 65W for fast charging compatible laptops and devices.
• Technologie GaN: Enables a smaller, lighter, and more efficient charger.
• 3portové provedení: Includes two USB-C ports and one USB-A port for versatile charging.
• Více protokolů rychlého nabíjení: Supports PPS, PD3.0, QC4+, SCP, FCP, AFC, MTK PE, BC1.2, and Apple 2.4A.
• Komplexní ochrana: Built-in safeguards against over-temperature, over-current, over-power, short circuit, over-voltage, and lightning.

Image: Gallium Nitride Technology. This image illustrates the GaN chip, emphasizing its benefits: high efficiency, effective heat dissipation, and enhanced safety.

5. Nastavení

1. Rozbalit: Carefully remove the charger and any included accessories from the packaging.
2. Kontrolovat: Check the charger for any visible damage. Do not use if damaged.
3. Připojit: Insert the charger's prongs into a standard wall outlet. Ensure it is securely seated.
4. Připojit zařízení: Use a compatible USB charging cable to connect your device to one of the charger's ports (USB-C1, USB-C2, or USB-A).
5. Ověřte nabíjení: Confirm that your device indicates it is charging.

Image: Charger in Use. The charger is shown plugged into a wall socket, providing power to a laptop via a USB-C cable, demonstrating its high-efficiency 65W GaN charging capability.

6. Návod k obsluze

6.1 Port Specifications and Power Output

The charger features three ports with varying maximum power outputs depending on single or simultaneous use.

• Port USB-C1: Supports PPS/PD3.0/QC4+/SCP/FCP/AFC/MTK PE/BC1.2/Apple 2.4A. Maximum 65W output.
• Port USB-C2: Supports PPS/PD3.0/QC4+/SCP/FCP/AFC/MTK PE/BC1.2/Apple 2.4A. Maximum 30W output.
• Port USB-A: Supports QC3.0/SCP/FCP/AFC/BC1.2/Apple 2.4A. Maximum 30W output.

Image: Port Specifications. This graphic provides a detailed breakdown of the maximum power output and supported fast-charging protocols for each of the charger's three ports.

6.2 Charging Guide (Simultaneous Use)

When multiple ports are used simultaneously, the total power output is distributed. Refer to the following guide for power distribution:

Image: Charging Guide. This visual guide illustrates the power output distribution when using one, two, or all three ports simultaneously. For example, using USB-C1 and USB-C2 simultaneously results in 45W from USB-C1 and 18W from USB-C2.

• Použití jednoho portu:
  • USB-C1: Up to 65W
  • USB-C2: Up to 30W
  • USB-A: Up to 30W
• Použití dvou portů:
  • USB-C1 + USB-C2: 45W + 18W
  • USB-C1 + USB-A: 45W + 18W
  • USB-C2 + USB-A: 15W + 15W
• Triple Port Use:
  • USB-C1 + USB-C2 + USB-A: 45 W + 15 W + 15 W

Image: Simultaneous Charging. This image shows the charger connected to a power strip, actively charging a laptop, a tablet, and a smartphone at the same time, demonstrating its multi-device capability.

7. Univerzální kompatibilita

The VENTION 65W GaN charger is designed to be compatible with a wide range of devices, including but not limited to:

• Laptops/Tablets: MacBook Pro/Air, Surface Pro/Book, iPad Pro/Air, Dell XPS, etc.
• telefony: iPhone 14/13/12 series, Galaxy S22/S20/Note 20 series, Google Pixel, etc.
• Další zařízení: AirPods/Pro, Nintendo Switch, and other USB-powered gadgets.

Image: Universal Compatibility. This graphic illustrates the broad compatibility of the charger with various devices, including laptops, tablets, smartphones, and gaming consoles.

8. Specifikace

9. Řešení problémů

• Zařízení se nenabíjí:
  • Ujistěte se, že je nabíječka bezpečně zapojena do zásuvky pod napětím.
  • Verify that the charging cable is properly connected to both the charger and your device.
  • Zkuste jiný nabíjecí kabel.
  • Try a different port on the charger.
  • Ensure your device is compatible with the charger's power output.
• Pomalé nabíjení:
  • Check the charging guide (Section 6.2) for power distribution when multiple devices are connected. Disconnecting other devices may increase speed for a single device.
  • Ensure your cable supports fast charging protocols.
  • Verify your device supports the fast charging protocols offered by the charger (e.g., PD, QC).
• Nabíječka se zahřívá:
  • Je normální, že se nabíječka během provozu zahřívá, zejména při nabíjení více zařízení nebo zařízení s vysokým výkonem.
  • If it becomes excessively hot or emits smoke/unusual odors, disconnect it immediately and cease use.

10. Údržba

• Čištění: Před čištěním odpojte nabíječku ze zásuvky. K otření povrchu použijte měkký, suchý hadřík. Nepoužívejte tekuté čisticí prostředky ani aerosoly.
• Skladování: Nabíječku skladujte na chladném a suchém místě mimo dosah přímého slunečního záření a extrémních teplot.
• Zacházení: Avoid bending or stressing the charging prongs.

Image: Portable Size. This image shows the charger being held, emphasizing its compact dimensions for easy portability.

11. Záruka a podpora

For warranty information or technical support, please refer to the documentation provided with your purchase or contact VENTION customer service through their official website or the retailer where the product was purchased. Please have your model number (FEDW0) and purchase date available when contacting support.

Poznámka: Konkrétní záruční podmínky se mohou lišit v závislosti na regionu a prodejci.
