1. Úvod
The Thinkcar Thinkscan Max2 is a professional-grade wireless OBD2 diagnostic scan tool designed for comprehensive vehicle analysis. It offers all-system diagnosis, over 28 maintenance reset functions, and supports advanced protocols like CAN-FD and FCA AutoAuth. This manual provides detailed instructions for setting up, operating, maintaining, and troubleshooting your device to ensure optimal performance.
Figure 1: Thinkcar Thinkscan Max2 Diagnostic Tool and Carrying Case.
Figure 2: Key features of Thinkscan Max2 including OE-Level All System Diagnosis, 28+ Reset Functions, CANFD Protocol, Wireless Connection, and Android 10.0 System.
2. Průvodce nastavením
2.1 Obsah balení
Before starting, verify all items are present in the package:
- Thinkscan Max2 Diagnostic Tool
- VCI Dongle (Wireless Connector)
- Nabíjecí kabel
- Nabíjecí adaptér
- Konvertibilní zástrčky (x3)
- Úložný vak z EVA
- Vícejazyčný manuál
Figure 3: Complete package contents of the Thinkscan Max2.
2.2 Počáteční nastavení zařízení
Follow these steps for the initial setup of your Thinkscan Max2:
- Zapnutí: Stisknutím a podržením tlačítka napájení zapněte zařízení.
- Výběr jazyka: Vyberte si ze seznamu preferovaný jazyk.
- Wi-Fi připojení: Pro aktualizace a online funkce připojte zařízení ke stabilní síti Wi-Fi.
- Nastavení časového pásma: Vyberte své místní časové pásmo.
- Account Registration & Activation: Create a new account or log in. You will need the serial number and activation code provided with your device to activate it.
2.3 Připojení k vozidlu
The Thinkscan Max2 uses a wireless VCI (Vehicle Communication Interface) dongle for connection:
- Vyhledejte port OBD-II vašeho vozidla, obvykle pod palubní deskou na straně řidiče.
- Plug the VCI dongle into the OBD-II port. Ensure a secure connection.
- The Thinkscan Max2 tablet will automatically connect to the VCI dongle via Bluetooth.
2.4 Aktualizace softwaru
Regular software updates ensure your device has the latest vehicle coverage and diagnostic functions. Connect to Wi-Fi and navigate to the 'Update' section on the main menu to check for and install available updates.
Video 1: Comprehensive guide on setting up, registering, connecting, and updating the Thinkscan Max2. This video demonstrates initial power-on, language and Wi-Fi setup, account activation, VCI dongle connection, system scanning, data stream analysis, report generation, and various maintenance functions.
3. Obsluha zařízení
3.1 Základní navigace
The Thinkscan Max2 operates on Android 10.0 with a 5.99-inch touch screen. Navigate through menus by tapping icons and swiping. The main interface provides quick access to key functions like Scan, OBD, Maintenance & Service, ThinkFile, ThinkStore, Setup, Repair Info, and Update.
3.2 Diagnostika celého systému
This function allows you to scan all available electronic control units (ECUs) in the vehicle, such as Engine, ABS, SRS, Transmission, etc.
- Automatické skenování VIN: The device can automatically identify the vehicle's VIN for quick diagnosis. Tap 'Scan' and select 'AutoSearch'.
- Zdravotní zpráva: After VIN identification, the device performs a comprehensive health report, scanning all systems for diagnostic trouble codes (DTCs).
- Čtení/Vymazání kódů DTC: View detailed descriptions of fault codes and clear them after repairs.
- Živý datový stream: Monitor real-time data parameters from various sensors and modules. You can combine up to 4 data streams for graphical display, aiding in complex diagnostics.
- Informace o ECU: Read control module information such as unit type, version numbers, etc.
Figure 4: Auto-VIN scan feature for automatic vehicle identification.
Obrázek 5: Přesview of OE-Level All System Diagnostic capabilities, including SAS, BMS, EPB, ABS, TPMS, and Transmission.
3.3 Maintenance & Service Functions (28+ Resets)
The Thinkscan Max2 provides lifetime free access to over 28 popular maintenance reset functions. Access these by tapping 'Maintenance & Service' on the main menu.
Figure 6: Visual representation of the 28+ maintenance reset functions available on the device.
Mezi klíčové funkce patří:
- Reset kontrolky oleje: Recalculate engine oil life system after an oil change.
- Steering Angle (SAS) Reset: Reset steering angle to zero.
- Kódování vstřikovačů: Write new injector codes into the car system.
- Krvácení z ABS: Exhaust air from the ABS system to restore braking sensitivity.
- Reset AdBlue: Reset urea after diesel exhaust treatment fluid replacement.
- Přizpůsobení škrticí klapky: Initialize throttle actuators.
- Resetování TPMS: Reset tire pressure after maintenance or sensor replacement.
- Resetování EPB: Replace and reset brake pads.
- Resetování pneumatik: Set size parameters for modified or replaced tires.
- AFS Headlamp Resetovat: Initialize adaptive headlamp systém.
- Inicializace střešního okna: Initialize sunroof when locked off or closed.
- Reset baterie: Register battery after replacement.
- Kalibrace sedadla: Calibrate memory in replaced or repaired seats.
- Airbag (SRS) Reset: Reset airbag data and turn off warning light after replacement.
- Resetování vzduchového filtru: Nastavení nebo naučení parametrů poměru vzduch/palivo.
- Reset převodovky: Complete gearbox self-learning.
- Způsob dopravy: Deactivate transport mode.
- Kalibrace systému Windows: Perform door window matching.
- Změna jazyka: Change vehicle central control system language.
- GEAR Reset: Re-correct gear position information communication.
- Reset ODO: Copy, write, or correct kilometer value (cannot decrease).
- Reset senzoru NOx: Reset catalytic converter learned value.
- Resetování zastavení/startování: Set up automatic start-stop function.
- Odvzdušnění chladicí kapaliny: Activate electronic water pump.
- Resetování pozastavení: Adjust vehicle body height sensor for level calibration.
3.4 CAN-FD Protocol Support
The Thinkscan Max2 is compatible with the CAN-FD protocol, supporting GM vehicles manufactured after 2020. This allows for faster communication and reduces the risk of undetected errors.
Figure 7: CAN-FD protocol support for GM vehicles (2020-2025).
3.5 Podpora automatického ověřování FCA
The device supports AutoAuth, enabling you to unlock the protected FCA vehicle SGW (Security Gateway) module on Chrysler, Dodge, Jeep, Alfa Romeo, and Fiat vehicles. Note: This requires purchasing a registration number on the AutoAuth webstránky samostatně.
3.6 Diagnostická zpráva a sdílení
After a diagnosis, the device automatically generates a diagnostic report. This report can be shared via email or by scanning a QR code with your phone.
Figure 8: Diagnostic report generation and sharing options via QR code or email.
3.7 Vestavěný Google Chrome
The device includes a built-in Google Chrome browser, allowing for quick online troubleshooting and access to repair information directly from the tool.
4. Údržba
To ensure the longevity and optimal performance of your Thinkscan Max2, adhere to the following maintenance guidelines:
- Aktualizace softwaru: Regularly check for and install software updates as described in Section 2.4. These updates provide new features, bug fixes, and expanded vehicle compatibility.
- Čištění: Use a soft, dry cloth to clean the device's screen and body. Avoid abrasive cleaners or solvents.
- Péče o baterie: To prolong battery life, avoid extreme temperatures and do not leave the device fully discharged for extended periods. Charge the device regularly.
- Skladování: Pokud zařízení nepoužíváte, uložte ho do úložného sáčku z EVA, abyste jej ochránili před prachem a fyzickým poškozením.
5. Řešení problémů
If you encounter issues with your Thinkscan Max2, consider the following:
- Problémy s připojením: Ensure the VCI dongle is securely plugged into the OBD-II port and that Bluetooth is enabled on the Thinkscan Max2. Verify Wi-Fi connection for online features.
- Poruchy softwaru: If an application crashes or behaves unexpectedly, try restarting the device. Ensure all software is up-to-date.
- Funkce zpětné vazby: The device includes an online feedback function. If you encounter a persistent issue or a function that doesn't work as expected, you can submit a detailed report directly from the device. This helps the manufacturer address problems efficiently.
- Vzdálená technická podpora: Utilize the built-in TeamViewer feature for 1-to-1 professional remote assistance from technicians.
6. Specifikace
| Funkce | Specifikace |
|---|---|
| Značka | Thinkcar |
| Číslo modelu | XKB05 |
| Operační systém | Android 10.0 |
| Zobrazit | 5.99palcová dotyková obrazovka (rozlišení 720x1440) |
| Kapacita baterie | 3100mAh lithium-iontová baterie (součástí balení) |
| Interní úložiště | 32 GB |
| Konektivita | Wi-Fi, Bluetooth (VCI Dongle supports up to 33 feet) |
| Hmotnost položky | 3.35 libry |
| Rozměry produktu | 8 x 4 x 2 palce |
| Podporované protokoly | OBDII (10 modes), CAN-FD, FCA AutoAuth |
| Podporované značky automobilů | 93+ American, Asian, and European vehicle makes |
Figure 9: High-end hardware configuration of the Thinkscan Max2, including Android 10.0, 5.99-inch touch screen, 3150mAh battery, 32GB storage, Wi-Fi & Bluetooth, and built-in Google Browser.
7. Záruka a podpora
Thinkcar provides comprehensive support for the Thinkscan Max2:
- Lifetime Free Upgrades: Enjoy free lifetime software upgrades for basic diagnostic functions and 28+ reset functions, saving on annual subscription fees.
- Služba 7/24: For any questions or issues, contact Thinkcar's customer service.
- Vzdálená technická podpora: Utilize the built-in TeamViewer feature for 1-to-1 professional remote assistance from technicians.
