1. Úvod
This manual provides detailed instructions for the installation, operation, and maintenance of your Vivotek IB9380-H 5MP IR Outdoor Network Bullet Camera. Please read this manual thoroughly before using the product to ensure proper setup and optimal performance. This camera is designed for outdoor security surveillance, offering high-resolution imaging and infrared capabilities for reliable monitoring.
Image 1.1: Vivotek IB9380-H 5MP IR Outdoor Network Bullet Camera overview.
2. Bezpečnostní informace
- Zdroj napájení: Use only the specified AC/DC power adapter. Ensure the power supply is stable and meets the camera's requirements (3.5 watts).
- Instalační prostředí: This camera is rated for outdoor use (IP9380). Avoid installing in locations with extreme temperatures, high humidity, or corrosive substances beyond its operating specifications.
- Zacházení: Do not drop or subject the camera to severe shock. Avoid touching the lens directly.
- Demontáž: Do not attempt to disassemble or modify the camera. This may void the warranty and cause damage.
- Kabeláž: Ensure all cables are properly secured and protected from environmental damage or tampering.
3. Obsah balení
Ověřte, zda jsou v balení přítomny všechny položky:
- Vivotek IB9380-H 5MP IR Outdoor Network Bullet Camera
- Mounting Kit (screws, wall anchors)
- Průvodce rychlou instalací
- Vodotěsný konektor pro ethernetový kabel
4. Nastavení
4.1. Fyzická instalace a montáž
The Vivotek IB9380-H camera is designed for wall mount installation. Choose a suitable location that provides the desired field of view a je v dosahu elektrické energie a síťových přípojek.
- Připravte montážní povrch: Mark the drilling points on the wall using the mounting template (if provided) or by holding the camera's base against the surface.
- Vrtací otvory: Drill pilot holes at the marked positions. Insert wall anchors if mounting on drywall or masonry.
- Zabezpečte kameru: Attach the camera's mounting base to the wall using the provided screws. Ensure it is firmly secured.
- Upravit úhel: Loosen the adjustment screws on the camera body to set the desired viewing angle. Tighten the screws once the angle is satisfactory.
Image 4.1: Camera dimensions and mounting diagram for installation planning.
4.2. Kabelové připojení
Connect the necessary cables to the camera:
- Ethernetový kabel: Connect a standard Ethernet cable (RJ45) to the camera's network port. Use the waterproof connector to protect the connection if exposed to weather.
- Napájecí kabel: Connect the power adapter to the camera's power input. Ensure the connection is secure.
Image 4.2: Close-up of an Ethernet cable connector, similar to what is used for the camera's network connection.
4.3. Počáteční zapnutí
Once all cables are connected, plug the power adapter into an electrical outlet. The camera will power on and initiate its startup sequence. Observe any indicator lights for status.
5. Návod k obsluze
5.1. Network Configuration and Access
The Vivotek IB9380-H supports Wi-Fi connectivity. For initial setup, it is recommended to connect via Ethernet to configure network settings.
- Objevte fotoaparát: Use the Vivotek IP Search utility or your network router's client list to find the camera's assigned IP address.
- Přístup Web Rozhraní: Otevřete a web browser and enter the camera's IP address. Log in using the default credentials (refer to the Quick Installation Guide for details).
- Konfigurace Wi-Fi: Navigate to the network settings within the web interface. Select your Wi-Fi network, enter the password, and save the settings. Once configured, you may disconnect the Ethernet cable if desired.
5.2. Živě View a Nahrávání
After network setup, you can access the camera's live feed and configure recording options.
- Žít View: z web interface or a compatible mobile application, select the camera to view jeho živý přenos.
- Nastavení nahrávání: Configure recording schedules, continuous recording, or event-triggered recording (e.g., motion detection). Recordings can be stored on a network video recorder (NVR) or a local storage device if supported.
Obrázek 5.1: Příkladample of a tablet displaying multiple camera feeds, illustrating remote monitoring capabilities.
5.3. Motion Detection Setup
The camera supports motion-only alerts.
- Access Alert Settings: In the camera's web interface, navigate to the event or alert settings section.
- Configure Motion Detection: Enable motion detection and define the detection zones and sensitivity levels.
- Set Actions: Specify actions to be taken upon motion detection, such as recording, sending email notifications, or triggering alarms.
5.4. Noční vidění
The camera features IR (Infrared) and Night Color low light technology for clear imaging in various lighting conditions. These features typically activate automatically based on ambient light levels.
6. Údržba
- Čištění objektivu: Gently wipe the camera lens with a soft, clean cloth. For stubborn dirt, use a lens cleaning solution designed for optical surfaces. Do not use abrasive cleaners.
- Aktualizace firmwaru: Pravidelně kontrolujte Vivotek website for firmware updates. Keeping the firmware updated ensures optimal performance, security, and access to new features.
- Kontrola prostředí: Regularly inspect the camera and its mounting for any signs of wear, damage, or loose connections, especially after severe weather conditions.
- Cyklus napájení: If the camera experiences minor issues, try power cycling it by disconnecting and reconnecting the power supply.
7. Řešení problémů
| Problém | Možná příčina | Řešení |
|---|---|---|
| Žádná síla | Power adapter unplugged or faulty; power outlet issue. | Check power connections. Test the outlet with another device. Try a different power adapter if available. |
| Žádný kanál videa | Network connection issue; incorrect IP address; camera not configured. | Verify network cable connection or Wi-Fi settings. Confirm camera's IP address. Ensure camera is properly configured in your viewsoftware. |
| Špatná kvalita obrazu | Znečištěný objektiv; špatné světelné podmínky; nesprávné nastavení rozlišení. | Clean the camera lens. Ensure sufficient lighting or verify night vision is active. Check video resolution settings in the camera's interface. |
| Detekce pohybu nefunguje | Motion detection disabled; incorrect sensitivity; detection zones not set. | Enable motion detection in settings. Adjust sensitivity and define detection zones. |
8. Specifikace
| Funkce | Detail |
|---|---|
| Model | IB9380-H |
| Efektivní rozlišení | 5 MP |
| Rozlišení záznamu videa | 1080p |
| Snímková frekvence | 20 snímků za sekundu |
| Technologie nízkého osvětlení | Noční barva |
| Form Factor | Kulka |
| Vnitřní/venkovní použití | Venkovní |
| Typ montáže | Držák na zeď |
| Bezdrátová komunikace | Wi-Fi |
| Protokol připojení | Wi-Fi |
| Zdroj napájení | AC/DC |
| Wattage | 3.5 wattů |
| Typ upozornění | Pouze pohyb |
| Kontrolní metoda | Vzdálený |
| Rozměry (D x Š x V) | 3.59 x 3.59 x 6.96 palce |
| Hodnocení mezinárodní ochrany | IP9380 |
| UPC | 655255870887, 681541834035 |
9. Informace o záruce
This Vivotek product is covered by a manufacturer's limited warranty. Please refer to the warranty card included in your package or visit the official Vivotek website for detailed terms and conditions regarding warranty coverage, duration, and claims procedures. Keep your proof of purchase for warranty service.
10. Zákaznická podpora
For technical assistance, troubleshooting beyond this manual, or warranty inquiries, please contact Vivotek customer support. You can typically find contact information (phone, email, support portal) on the official Vivotek webwebu nebo v dokumentaci dodané s vaším produktem.
Online zdroje: www.vivotek.com
