Návod k obsluze pro ofsetový držák Nightstick LGL-ML1 M-Lok

Zavedení

The Nightstick LGL-ML1 M-Lok Offset Mount is designed to provide a secure and optimized mounting solution for specific Nightstick weapon lights on M-LOK compatible forearms. This mount eliminates the need for additional Picatinny rail sections, offering a streamlined and low-profile installation. It positions the attached weapon light at a 45-degree angle, facilitating ergonomic operation, particularly for support hand thumb activation of tail cap or remote pressure switches.

Image: The Nightstick LGL-ML1 M-Lok Offset Mount, a black, angled aluminum bracket with two M-LOK T-nuts and screws visible.

Klíčové vlastnosti

• Direct M-LOK Attachment: Mounts directly to any M-LOK forearm, removing the need for extra rail adapters.
• 45-Degree Offset Positioning: Positions the weapon light at a 45-degree angle for a nearly flush and ergonomic installation.
• Oboustranný design: Can be configured for either right or left side mounting to suit user preference and firearm setup.
• Odolná konstrukce: Manufactured from 6061-T6 aluminum with a hard anodized black finish for strength and corrosion resistance.
• Kompatibilita: Specifically designed for Nightstick LGL-150, LGL-160, and LGL-170 weapon lights.

Image: A graphic illustrating the M-LOK attachment mechanism and the 45-degree offset design of the mount, showing how it integrates with a firearm forearm.

Image: A graphic demonstrating the mount's configurability on either side of the rail and its compatibility with Nightstick LGL-150, LGL-160, and LGL-170 weapon lights.

Obsah balení

Ověřte, zda jsou v balení obsaženy všechny níže uvedené položky:

• 1 x LGL-ML1 M-LOK Offset Mount
• 1 x 1.5mm Allen Wrench
• 1 x 2mm Allen Wrench
• 2 x Weapon Light Mounting Screws with Lock Washers

Image: The Nightstick LGL-ML1 mount shown alongside the included Allen wrenches and mounting screws with lock washers.

Nastavení a instalace

Follow these steps to properly install your Nightstick LGL-ML1 M-Lok Offset Mount and attach a compatible weapon light:

1. Identify M-LOK Slots: Locate the desired M-LOK slots on your firearm's forearm where you intend to mount the light.
2. Umístění držáku: Place the LGL-ML1 offset mount against the M-LOK slots. Ensure the T-nuts on the back of the mount align with the M-LOK slots. The mount is reversible, allowing for left or right side mounting based on your preference.
3. Zajistěte držák: Using the appropriate Allen wrench (typically 2mm for the M-LOK hardware), tighten the screws that pass through the mount and engage the T-nuts. Ensure the T-nuts rotate into position and are securely fastened within the M-LOK slot. Do not overtighten.
4. Attach Weapon Light: Align your Nightstick LGL-150, LGL-160, or LGL-170 weapon light with the two mounting holes on the LGL-ML1 offset mount.
5. Fasten Light to Mount: Insert the two provided weapon light mounting screws with lock washers through the light's mounting points and into the threaded holes on the LGL-ML1 mount. Use the 1.5mm Allen wrench to tighten these screws. The lock washers help prevent loosening from recoil.
6. Ověření zabezpečení: Gently attempt to move the mounted light and mount assembly to ensure it is firmly attached to the forearm and the light is secure on the mount.

Image: A Nightstick weapon light securely mounted to a firearm's M-LOK forearm using the LGL-ML1 offset mount, demonstrating its low-profile and angled positioning.

Operace

The LGL-ML1 offset mount is designed to optimize the placement of your Nightstick weapon light for ease of use. Once installed, the 45-degree angle positions the light closer to the firearm's centerline while allowing for convenient activation.

• Thumb Activation: The angled position is ideal for users who prefer to activate their weapon light using their support hand thumb on the light's tail cap switch.
• Remote Pressure Switch Integration: If using a remote pressure switch, the mount's position can help route the cable cleanly and place the switch in an accessible location.
• Ergonomie: Experiment with the mount's reversible orientation to find the most comfortable and efficient setup for your shooting style and firearm configuration.

Péče a údržba

To ensure the longevity and reliable performance of your Nightstick LGL-ML1 M-Lok Offset Mount, follow these simple maintenance guidelines:

• Čištění: Wipe the mount with a clean, dry cloth to remove dirt, dust, or debris. For stubborn grime, a lightly dampened cloth with mild soap and water can be used, followed by thorough drying. Avoid harsh chemicals or abrasive cleaners.
• Inspekce: Periodically inspect the mount for any signs of wear, damage, or loose fasteners. Ensure all screws remain tight, especially after periods of heavy use or recoil.
• Skladování: Store the mount in a dry environment when not in use.

Specifikace

Image: A diagram illustrating the dimensions of the Nightstick LGL-ML1 M-Lok Offset Mount.

Odstraňování problémů

If you encounter issues with your LGL-ML1 M-Lok Offset Mount, consider the following:

• Mount Not Securing: Ensure the M-LOK T-nuts are correctly aligned and rotated within the M-LOK slots. Verify that the screws are fully engaging the T-nuts and are tightened sufficiently, but not over-tightened.
• Light Not Attaching: Confirm that your weapon light is one of the compatible Nightstick LGL-150, LGL-160, or LGL-170 models. Check that the mounting screws are correctly aligned with the light's mounting holes and are not cross-threaded.
• Volná montáž: Regularly check all mounting screws for tightness, especially after firing the firearm. Recoil can sometimes cause fasteners to loosen over time.

Informace o záruce

The Nightstick LGL-ML1 M-Lok Offset Mount is covered by a Omezená doživotní záruka. For detailed information regarding warranty terms, conditions, and claims, please refer to the official Nightstick webwebu nebo kontaktujte zákaznickou podporu.

Zákaznická podpora

For further assistance, technical support, or inquiries regarding your Nightstick LGL-ML1 M-Lok Offset Mount, please visit the official Nightstick webnebo kontaktujte jejich oddělení zákaznických služeb. Můžete také navštívit Nightstick Brand Store on Amazon.
