Zavedení
This manual provides detailed instructions for the assembly, operation, maintenance, and troubleshooting of your tectake 401488 Aluminium Cafe Table. Please read this manual carefully before assembly and use to ensure safe and efficient operation. Keep this manual for future reference.
Bezpečnostní pokyny
Always follow basic safety precautions when assembling and using the table to reduce the risk of injury or damage.
- Před montáží se ujistěte, že jsou všechny díly přítomné a nepoškozené.
- Stůl sestavte na měkkém a čistém povrchu, abyste zabránili poškrábání.
- Nepřekračujte maximální nosnost 60 kg.
- Stůl postavte na stabilní, rovný povrch, aby se nepřevrátil.
- Během montáže držte děti a domácí zvířata mimo dosah.
- Regularly check all screws and connections for tightness.
- Nestůjte ani nesedejte na stole.
Obsah balení
Ověřte, zda jsou v balení obsaženy všechny níže uvedené komponenty:
- 1 x Tabletop (MDF with brushed stainless steel coating)
- 1 x Main Pole (Aluminium)
- 1 x Base (Aluminium with plastic feet)
- Montážní materiál (šrouby, podložky atd.)
- 1 x Návod k montáži (tato příručka)
Nastavení a montáž
Follow these steps for proper assembly of your tectake Aluminium Cafe Table. It can be assembled to two different heights: 70 cm (dining table height) or 110 cm (standing table height).
Krok 1: Připravte základnu
Unpack all components and lay them out on a clean, soft surface to prevent scratching. Attach the main pole to the base using the provided screws. Ensure the plastic feet are securely attached to the base for stability and floor protection.
Figure 1: Illustration of the table's stable base and adjustable feet. The base is made of aluminum, ensuring stability even under higher loads. The non-slip plastic feet are designed for height adjustment and stability on various surfaces.
Krok 2: Připevnění desky stolu
Carefully place the tabletop onto the main pole. Secure it using the appropriate hardware. Ensure the tabletop is centered and firmly attached to prevent wobbling.
Figure 2: The tabletop, made of MDF with a polished stainless steel surface, is being attached to the main pole. This surface enhances resistance and provides a gleaming, weather-resistant finish.
Step 3: Adjust Height (if applicable for your model)
This model (401488-SE) is not foldable and has a fixed tube diameter of 5.8 cm. However, it is designed to be assembled at two different heights: 70 cm (for dining) or 110 cm (for standing). The assembly process will determine the final height. Refer to the specific assembly instructions provided in the package for details on how to achieve your desired height during initial setup.
Figure 3: The tectake cafe table can be configured for two heights: 70 cm (left, suitable for dining) and 110 cm (right, suitable for standing). This versatility allows it to function as both a dining table and a bar table.
Figure 4: Detailed dimensions of the table. The tabletop has a diameter of approximately 60 cm and a thickness of 2 cm. The table can be assembled to a height of 70 cm or 110 cm, with a tube diameter of approximately 5.8 cm. The maximum load capacity is 60 kg.
Návod k obsluze
Your tectake Aluminium Cafe Table is designed for versatile use in various settings, including gardens, patios, balconies, or indoor spaces like cafes and offices.
- Umístění: Ensure the table is placed on a flat, stable surface. The plastic feet help in leveling on uneven ground.
- Kapacita zatížení: Do not exceed the maximum load capacity of 60 kg. Distribute weight evenly on the tabletop.
- Odolnost vůči počasí: The table features a weatherproof tabletop and stainless steel coating, making it suitable for outdoor use. However, for prolonged life, it is recommended to store it indoors during extreme weather conditions.
Figure 5: The table is shown outdoors with water droplets, highlighting its weather-resistant properties. It is perfect for outdoor use and is resistant to rain, with a robust construction that can support up to 60 kg.
Figure 6: The table in a cafe setting, demonstrating its versatility as a dining or bar table. Its adaptable design makes it suitable for various situations and environments, thanks to its two-step height adjustment and compact size.
Údržba a péče
Proper maintenance will extend the life and preserve the appearance of your table.
- Čištění: Wipe the tabletop and frame with a soft, damp cloth. For stubborn stains, use a mild soap solution. Avoid abrasive cleaners or harsh chemicals that could damage the finish.
- Povrch z nerezové oceli: The tabletop is coated with brushed stainless steel, which is easy to clean and resistant to rust.
- Pravidelné kontroly: Pravidelně kontrolujte všechny šrouby a spoje, zda jsou pevně utažené. V případě potřeby je dotáhněte.
- Skladování: While weather-resistant, storing the table indoors or covering it during prolonged periods of non-use or harsh weather will help maintain its condition.
Figure 7: A hand cleaning the stainless steel tabletop with a cloth, demonstrating its ease of cleaning. The stainless steel surface is designed for simple maintenance.
Odstraňování problémů
| Problém | Možná příčina | Řešení |
|---|---|---|
| Stůl se kymácí | Uvolněné šrouby nebo nerovný povrch. | Tighten all assembly screws. Adjust the plastic feet on the base to level the table on uneven ground. |
| Škrábance na desce stolu | Abrazivní čisticí materiály nebo ostré předměty. | Use only soft cloths and mild cleaners. Avoid dragging sharp objects across the surface. Minor scratches on stainless steel may be buffed with specialized products. |
| Obtížnost sestavení | Incorrect part orientation or missing hardware. | Review the assembly instructions carefully. Ensure all parts are oriented correctly. Contact customer support if hardware is missing. |
Specifikace
- Model: 401488-SE
- Tabletop Diameter: 60 cm
- Tloušťka desky stolu: 2 cm
- Průměr trubky: 5.8 cm
- Nastavitelná výška: 70 cm / 110 cm (fixed height upon assembly)
- Hmotnost: Přibližně 7.6 kg
- Maximální nosnost: 60 kg
- Materiály: MDF (tabletop), Stainless Steel (tabletop coating), Aluminium (pole and base), Plastic (feet)
- Barva: Silver / All Grey
Záruka a podpora
For warranty information or technical support, please contact tectake customer service. Keep your purchase receipt as proof of purchase.
Kontaktní údaje: Please refer to the tectake official webNejnovější kontaktní údaje naleznete na webových stránkách nebo na obalu.
Online zdroje: For additional information and FAQs, visit the official tectake webmísto: www.tectake.se
