SHARKOON Elite Shark CA300T Extended ATX PC Case User Manual

1. Úvod

This manual provides comprehensive instructions for the SHARKOON Elite Shark CA300T Extended ATX PC Case. It covers the product's features, setup procedures, operational guidelines, maintenance tips, troubleshooting solutions, and detailed technical specifications. Please read this manual thoroughly before installation and use to ensure optimal performance and longevity of your PC case.

2. Klíčové vlastnosti

• Futuristický design: The CA300T features an expressive front panel with a geometric pattern, framed by brushed aluminum, giving it a distinctive and modern aesthetic.
• Pokročilé proudění vzduchu: Equipped with three pre-installed 120mm RGB LED fans at the front and one at the rear, ensuring consistent airflow. The front panel includes a mesh grille for optimal ventilation, and the top panel offers a perforated cover for additional fan/radiator mounting.
• Illuminated I/O Panel: The side-mounted I/O panel includes standard audio ports, USB 3.0 ports, and a USB-C port, all featuring their own RGB illumination.
• Panely z tvrzeného skla: Two tempered glass side panels provide a clear view of internal components. The right-side panel is partially tinted to conceal the power supply tunnel while highlighting SSDs or HDDs.
• Prostorný interiér: Designed to accommodate large components, including graphics cards up to 42.5 cm, power supplies up to 24 cm, and CPU coolers up to 16.5 cm.
• Efektivní správa kabelů: Features a spacious, foldable cable compartment and a sliding cable cover to keep wiring organized and out of sight.
• Možnosti úložiště: Supports up to seven 2.5-inch drives or four 3.5-inch drives.

3. Obsah balení

The SHARKOON Elite Shark CA300T PC Case package typically includes:

• SHARKOON Elite Shark CA300T PC Case (White)
• Pre-installed 120mm RGB LED Fans (3x Front, 1x Rear)
• Krabice s příslušenstvím (šrouby, stahovací pásky, distanční sloupky atd.)
• Uživatelská příručka (tento dokument)

Note: Specific contents may vary slightly. Please check the packaging for a complete list.

4. Pokyny k nastavení

Follow these steps to set up your SHARKOON Elite Shark CA300T PC case and install your components.

4.1. Příprava případu

1. Rozbalte pouzdro: Opatrně vyjměte skříň počítače z obalu.
2. Odstraňte boční panely: Unscrew the thumbscrews on the rear of the case for both tempered glass side panels. Gently slide and lift the panels to remove them. Place them on a soft, flat surface to prevent scratches.
3. Krabice s příslušenstvím: Uvnitř pouzdra vyhledejte krabici s příslušenstvím, která obsahuje všechny potřebné šrouby a montážní materiál.

4.2. Instalace základní desky

1. Nainstalujte Standoffs: Ensure the correct standoffs are installed for your motherboard form factor (ATX, SSI EEB). The case typically has pre-installed standoffs for standard ATX.
2. Instalace krytu I/O: If your motherboard requires an external I/O shield, install it into the rear opening of the case before mounting the motherboard.
3. Montáž základní desky: Carefully place your motherboard onto the standoffs, aligning the screw holes. Secure the motherboard with the provided screws.

4.3. Instalace napájecího zdroje (PSU)

1. Pozice zdroje napájení: The PSU mounts at the rear bottom of the case. Slide your PSU into the designated compartment from the rear.
2. Zabezpečený zdroj: Align the PSU with the screw holes and secure it with the provided screws from the rear of the case.
3. Správa kabelů: Route PSU cables through the cutouts to the back of the motherboard tray for organized cable management.

4.4. Instalace úložného disku

The CA300T supports various drive configurations:

• 2.5-inch Drives (SSDs): Mount SSDs to the dedicated brackets behind the motherboard tray or within the PSU shroud.
• 3.5-inch Drives (HDDs): Install HDDs into the drive cages located under the PSU shroud.

4.5. Instalace grafické karty a rozšiřující karty

1. Odstraňte kryty slotů: Odstraňte potřebné kryty rozšiřujících slotů ze zadní strany skříně.
2. Install Card: Insert your graphics card or other expansion cards into the appropriate PCIe slots on the motherboard.
3. Bezpečná karta: Secure the card with the provided screws.

4.6. Připojení kabelů předního panelu

Connect the front panel cables (USB 3.0, USB-C, HD Audio, Power Switch, Reset Switch, Power LED, HDD LED) to their corresponding headers on your motherboard. Refer to your motherboard manual for exact pin layouts.

4.7. Závěrečná montáž

1. Správa kabelů: Use the cable ties and routing channels to organize all internal cables behind the motherboard tray.
2. Znovu připevněte boční panely: Carefully reattach both tempered glass side panels and secure them with the thumbscrews.

Obrázek 1: Interiér view of the CA300T, highlighting component space.

5. Návod k obsluze

5.1. Zapnutí systému

After all components are installed and cables are connected, plug your power supply into a wall outlet and flip the PSU's power switch to the 'ON' position. Press the power button on the case's front I/O panel to start your computer.

5.2. Ovládání RGB osvětlení

The pre-installed RGB fans and illuminated I/O panel can be controlled via your motherboard's RGB software (if compatible) or a dedicated RGB controller if included with your motherboard or purchased separately. Refer to your motherboard manual for specific RGB header locations and software instructions.

Figure 2: The CA300T with its illuminated RGB fans and distinctive front panel.

6. Údržba

Pravidelná údržba pomáhá zajistit optimální výkon a prodlužuje životnost komponent vašeho počítače.

6.1. Čištění prachového filtru

The CA300T includes magnetic dust filters. It is recommended to clean these filters every 1-3 months, depending on your environment, to maintain optimal airflow and prevent dust buildup inside the case.

1. Vyhledejte filtry: Identify the dust filters on the top, front, and bottom of the case.
2. Odebrat filtry: Gently pull or slide out the magnetic dust filters.
3. Čisté filtry: Use a soft brush, vacuum cleaner, or rinse with water (ensure completely dry before reinstallation) to remove accumulated dust.
4. Znovu nainstalujte filtry: Place the clean filters back into their respective positions.

6.2. Generální úklid

For external surfaces, use a soft, damp cloth to wipe down the case. Avoid abrasive cleaners or solvents that could damage the finish or tempered glass.

Obrázek 3: Nahoře view of the CA300T, showing the perforated top panel.

7. Řešení problémů

Tato část se zabývá běžnými problémy, se kterými se můžete setkat během nastavení nebo provozu.

7.1. Systém se nezapne

• Check PSU: Ensure the power supply unit is properly connected to the wall outlet and the PSU's power switch is in the 'ON' position.
• Připojení předního panelu: Verify that the power switch cable from the case's front panel is correctly connected to the motherboard's power header.
• Internal Power Cables: Confirm that all necessary power cables (24-pin ATX, CPU 8-pin, GPU PCIe) are securely connected to the motherboard and components.

7.2. Fans Not Spinning / RGB Not Lighting Up

• Připojení ventilátoru: Ensure all fan power cables are securely connected to the motherboard's fan headers or a fan controller.
• RGB Connections: Verify that RGB cables are correctly connected to the motherboard's RGB headers or a dedicated RGB controller.
• Software/Řadič: Check your motherboard's BIOS/UEFI settings or RGB software to ensure fans and RGB lighting are enabled and configured correctly.

7.3. Nefunkční USB porty

• Internal USB Headers: Confirm that the internal USB 3.0 and USB-C cables from the case's front panel are securely connected to the corresponding headers on your motherboard.
• Ovladače základní desky: Ensure all necessary motherboard chipset and USB drivers are installed.

8. Technické specifikace

9. Záruka a podpora

9.1. Záruka na produkt

The SHARKOON Elite Shark CA300T PC Case comes with a 2-letá záruka on spare parts. This warranty covers defects in materials and workmanship under normal use. Please retain your proof of purchase for warranty claims.

9.2. Aktualizace softwaru

Software updates, if applicable for any integrated components or controllers, are guaranteed until 13. dubna 2030.

9.3. Zákaznická podpora

For technical assistance, warranty claims, or further inquiries, please contact Sharkoon customer support through their official website or the retailer where the product was purchased. Have your product model and proof of purchase ready when contacting support.
