1. Úvod
This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your Scheppach MS173-51 Petrol Lawn Mower. Please read this manual thoroughly before operating the machine to ensure proper use and to prevent injury or damage.

Figure 1: Scheppach MS173-51 Petrol Lawn Mower
2. Bezpečnostní pokyny
Při provozu elektrických zařízení vždy upřednostňujte bezpečnost. Nedodržení bezpečnostních pokynů může vést k vážnému zranění nebo poškození majetku.
- Přečtěte si manuál: Familiarize yourself with all controls and proper use before starting the engine.
- Osobní ochranné prostředky (OOP): Always wear appropriate eye protection, hearing protection, and sturdy footwear. Long pants are recommended.
- Vyčistěte oblast: Before mowing, remove all objects such as rocks, sticks, wires, or other debris that could be thrown by the blade.
- Manipulace s palivem: Handle petrol with extreme care. It is highly flammable. Refuel outdoors in a well-ventilated area, away from sparks or open flames. Do not smoke while refueling.
- Vypnutý motor: Always turn off the engine and disconnect the spark plug wire before performing any maintenance, cleaning, or clearing blockages.
- Provoz na svahu: Při práci na svazích buďte mimořádně opatrní. Sekejte napříč svahy, nikdy ne nahoru a dolů. Vyhýbejte se příliš strmým svahům.
- Děti a přihlížející: Keep children and bystanders away from the mowing area.
- Bezpečnost čepele: The blade continues to rotate for a few seconds after the engine is switched off. Do not touch the blade until it has come to a complete stop.
3. Konec produktuview a funkce
The Scheppach MS173-51 is a versatile petrol lawn mower designed for efficient lawn care. It offers multiple functions to suit various mowing needs.
- Powerful 4-Stroke Petrol Engine: Provides reliable performance for various grass conditions.
- Šířka sečení 51 cm: Ideal for medium to large-sized lawns.
- Professional Gearbox: Ensures high torque, strong performance, and long service life.
- Integrated Cleaning Function: Features a water connection for easy deck cleaning.
- Robust 65 L Grass Catcher: Collects clippings efficiently, reducing emptying frequency.
- Skládací rukojeť: Allows for easy and space-saving storage or transport.
- Vysoký točivý moment: Facilitates comfortable operation even in tall grass.
- Wheel Drive: Simplifies mowing, especially on larger areas or slopes.
- Centrální nastavení výšky sečení: 7 stages from 25 mm to 75 mm for precise control.

Figure 2: The mower offers 6-in-1 functionality including mowing, catching, mulching, side discharge, cleaning function, and wheel drive.

Obrázek 3: Vizuální examples of mowing, catching, and mulching operations.

Obrázek 4: Přesview of recommended lawn area (up to 1600 m²), cutting height range (25-75 mm), 65L grass box capacity, and Easy Clean feature.
4. Nastavení a montáž
The Scheppach MS173-51 is designed for straightforward assembly. Follow these steps for initial setup:
- Rozbalení: Opatrně vyjměte všechny součásti z obalu. Ujistěte se, že jsou přítomny všechny součásti dle dodacího listu.
- Sestava rukojeti: Unfold the handle and secure it in the operating position. The foldable handle design allows for quick setup and compact storage.
- Sestava sběrného koše na trávu: Assemble the grass catcher according to the instructions and attach it securely to the mower.
- Hladiny kapalin: Before first use, fill the engine with the appropriate engine oil and petrol. Refer to the engine manual for specific oil type and capacity.
- Side Discharge Chute (Optional): If using the side discharge function, easily mount the side discharge chute as needed.

Figure 5: The side discharge chute can be easily mounted or dismounted as required.

Obrázek 6: Skládací rukojeť umožňuje úsporu místa při skladování a snadnou přepravu sekačky.
5. Návod k obsluze
Pro bezpečný a efektivní provoz sekačky na trávu dodržujte tyto kroky.
5.1 Startování motoru
- Ensure the fuel tank is filled with fresh petrol and the oil level is correct.
- Set the choke lever (if applicable) to the 'START' position.
- Pevně zatáhněte za startovací šňůru, dokud motor nenaskočí.
- Once started, gradually move the choke lever to the 'RUN' position.

Figure 7: The mower features a 173 cm³ engine with 4.1 PS power and a reliable pull-cord start system.
5.2 Nastavení výšky sečení
The central cutting height adjustment allows you to easily select one of 7 positions.
- Ensure the engine is off before adjusting the cutting height.
- Vyhledejte centrální páku pro nastavení výšky, obvykle poblíž jednoho ze zadních kol.
- Pull the lever outwards and move it to the desired height setting (25 mm to 75 mm).
- Release the lever to lock it into position. Ensure all wheels are set to the same height.

Figure 8: The central cutting height adjustment is performed in 7 stages from 25-75 mm.
5.3 Techniky sečení
The MS173-51 supports various mowing modes:
- Sbírání: Attach the 65L grass catcher for collecting clippings. Empty the bag regularly to maintain optimal performance.
- Mulčování: The mulching function finely chops grass clippings and returns them to the lawn as natural fertilizer. Ensure the mulching plug is inserted.
- Boční výboj: For areas where collecting or mulching is not desired, attach the side discharge chute to eject clippings to the side.
6. Údržba
Pravidelná údržba zajistí dlouhou životnost a optimální výkon vaší sekačky na trávu.
- Čištění: After each use, clean the mower deck to prevent grass buildup. The integrated cleaning function with water connection makes this easy.
- Kontrola čepele: Regularly inspect the blade for sharpness and damage. A dull or damaged blade can affect cutting quality and mower performance.
- Výměna oleje: Dodržujte doporučení výrobce motoru ohledně intervalů výměny oleje.
- Vzduchový filtr: Pravidelně kontrolujte a čistěte vzduchový filtr, zejména v prašném prostředí. Pokud je poškozený, vyměňte jej.
- Zapalovací svíčka: Pravidelně kontrolujte a čistěte zapalovací svíčku. V případě opotřebení ji vyměňte.
- Skladování: When storing the mower for extended periods, ensure the fuel tank is empty or treated with a fuel stabilizer. Clean the mower thoroughly and store in a dry, protected area.

Figure 9: The Easy Clean function allows for quick and convenient cleaning of the mower deck using a standard water hose connection.
7. Řešení problémů
Tato část se zabývá běžnými problémy, se kterými se můžete setkat. V případě složitějších problémů se obraťte na kvalifikovaného servisního technika.
| Problém | Možná příčina | Řešení |
|---|---|---|
| Motor nestartuje | No fuel; old fuel; spark plug issue; air filter clogged | Check fuel level; use fresh fuel; inspect/clean/replace spark plug; clean/replace air filter |
| Sekačka seká nerovnoměrně | Tupý nebo ohnutý nůž; nesprávné nastavení výšky sečení; nerovný terén | Sharpen or replace blade; ensure all wheels are at same height; adjust mowing pattern for terrain |
| Nadměrné vibrace | Ohnutá čepel; uvolněné součásti; nevyváženost motoru | Inspect and replace blade if bent; check all fasteners; consult service technician |
| Motor ztrácí výkon | Clogged air filter; dirty spark plug; low oil level; old fuel | Clean/replace air filter; clean/replace spark plug; check oil level; use fresh fuel |
8. Specifikace
Technical data for the Scheppach MS173-51 Petrol Lawn Mower.
| Atribut | Hodnota |
|---|---|
| Číslo modelu | MS173-51 |
| Výrobce | Scheppach |
| Zdroj napájení | Benzínový pohon |
| Materiál | Legovaná ocel |
| Hmotnost položky | 36.45 kg |
| Šířka řezu | 51 centimetrů |
| Počet řezných pozic | 7 |
| Rozsah výšky sečení | 25 - 75 mm |
| Kapacita lapače trávy | 65 litrů |
| Rozměry produktu (D x Š x V) | 164 x 56 x 113 cm |
| GTIN | 04046664081890 |
9. Záruka a podpora
Výrobky Scheppach jsou vyráběny z vysoce kvalitních materiálů a procházejí přísnou kontrolou kvality. Informace o záruce naleznete v záručním listu, který je součástí vašeho produktu, nebo navštivte oficiální stránky společnosti Scheppach. website. For technical support or spare parts, please contact Scheppach customer service or an authorized service center.
Více informací a kontaktní údaje naleznete na oficiálních stránkách Scheppach webmísto: www.scheppach.com
