Návod k obsluze stanu Outsunny 10' x 20' s výklopnou stříškou (model 84C-117CF)

Důležité bezpečnostní informace

WARNING: This canopy tent is not designed to be left up during adverse or inclement weather conditions, including rain, snow, sleet, and hail. Added weight from precipitation can cause the tent to collapse, leading to potential damage or injury.

Obsah balení

Před zahájením montáže ověřte, zda jsou všechny komponenty přítomny.

• Pop-Up Frame (Pre-assembled)
• Canopy Top Fabric (Silver-coated Oxford fabric)
• 4 Sidewalls (with windows)
• Přepravní taška
• Pozemní sázky
• Guy Ropes

Pokyny pro nastavení

This pop-up canopy tent is designed for quick assembly. It is recommended that 2-4 people assist with the setup process to optimize time and ensure proper installation.

1. Rozbalte rám: Remove the folded frame from the carrying bag. Place it in the desired setup location.
2. Partially Expand the Frame: With two people on opposite sides, gently pull the frame outwards until it is partially expanded.
3. Připevněte vrchní část stříšky: Drape the canopy top fabric over the partially expanded frame. Secure it using the "single touch straps" or Velcro attachments. Ensure the canopy is centered and evenly distributed.
4. Fully Expand and Lock the Frame: Continue expanding the frame until it is fully open. Push up on the central hub or corner mechanisms until they click into place, locking the frame.
5. Prodloužení nohou: Extend each leg to the desired height. Press the red button or lever on each leg to release the locking mechanism, extend, and then re-engage the lock. The tent features a three-level height adjustment.
6. Připevnění bočních stěn (volitelné): If desired, attach the four sidewalls using the provided Velcro or hook-and-loop fasteners. The sidewalls feature windows for visibility.
7. Zajistěte stan: For outdoor use, always secure the tent using the provided ground stakes and guy ropes. Insert stakes into soft ground surfaces and attach ropes to the tent frame, pulling taut and securing to the stakes. For hard surfaces like concrete, use alternative weights (not included) on each leg.

Figure 1: Pop-Up Design Overview. This image illustrates the sequential steps of setting up the canopy tent, starting from the folded frame, adding the canopy, opening the frame, and finally attaching the sidewalls.

Figure 2: Three-Level Height Adjustment. A hand is shown pressing a red button on one of the tent's legs, indicating the mechanism for raising or lowering the canopy's height.

Figure 3: Stable Standing and Anchoring. This diagram illustrates different methods for securing the tent, including the use of guy ropes, spiral ground stakes, and standard ground stakes to ensure stability.

Návod k obsluze

• Nastavení výšky: To adjust the height, press the red button on each leg and slide the inner leg section up or down to the desired position. Ensure all legs are set to the same height for stability.
• Konfigurace bočnice: Sidewalls can be attached or removed as needed. They can also be rolled up and secured to allow for airflow while maintaining overhead shade.
• UV ochrana: The silver-coated Oxford fabric canopy blocks 90% of UV rays, providing shade for outdoor activities.

Údržba

• Čištění: Clean the canopy fabric and sidewalls with mild soap and water. Do not use harsh chemicals or abrasive cleaners. Allow all parts to dry completely before storage to prevent mildew.
• Péče o rám: The powder-coated steel frame is water-safe. Wipe down the frame with a damp cloth as needed. Inspect for any signs of rust or damage before each use.
• Skladování: When not in use, disassemble the tent and store all components in the provided carrying bag in a cool, dry place.

Odstraňování problémů

Specifikace

Kontakt a podpora

Pro další pomoc nebo dotazy se prosím obraťte na oficiálního zástupce výrobce webwebu nebo kontaktujte zákaznickou podporu.
