Imou Cruiser Dual 6MP Surveillance Camera

1. Konec produktuview

The Imou Cruiser Dual 6MP is an innovative PTZ (Pan-Tilt-Zoom) WLAN outdoor surveillance camera designed for comprehensive monitoring. It features two independent lenses, a fixed 3MP lens and a pan-tilt 3MP lens, providing a total 6MP resolution for sharp, detailed images. This camera is equipped with intelligent tracking, advanced night vision modes, two-way audio, and active deterrence features, making it ideal for securing outdoor areas.

Figure 1: Imou Cruiser Dual 6MP Surveillance Camera

2. Co je v krabici

Zkontrolujte prosím obsah balení, abyste se ujistili, že jsou přítomny všechny položky:

• Imou Cruiser Dual 6 MP WLAN Surveillance Camera
• Napájecí adaptér
• Vodotěsný konektor
• Rychlý průvodce
• Balíček šroubů
• Montážní šablona

3. Nastavení a instalace

3.1 Montáž fotoaparátu

The Imou Cruiser Dual is designed for wall mounting. Use the provided mounting template and screws for secure installation. Ensure the mounting surface is stable and can support the camera's weight.

3.2 Připojení napájení

Connect the power adapter to the camera's power input and then plug it into a suitable power outlet. Use the waterproof connector for outdoor installations to protect the power connection from moisture.

3.3 Instalace aplikace a počáteční nastavení

1. Stáhněte si Aplikace Imou Life z App Storu (iOS) nebo z Obchodu Google Play (Android).
2. Register for an Imou account or log in if you already have one.
3. Klepnutím na ikonu „+“ v aplikaci přidáte nové zařízení.
4. Scan the QR code on the camera or its packaging.
5. Follow the on-screen instructions to connect the camera to your Wi-Fi network. Ensure your Wi-Fi signal is strong at the camera's location.

4. Ovládání fotoaparátu

4.1 Dual-Lens Functionality and Angle Adjustment

The camera features two lenses: a fixed 3MP lens and a motorized 3MP PT (Pan-Tilt) lens. The fixed lens allows manual angle adjustments from 0° to 260° horizontally and 0° to 30° vertically. The PT lens offers a wider range of motion, 0° to 355° horizontally and 0° to 90° vertically, controllable via the Imou Life App.

Figure 2: The adjustable dual-lens system provides comprehensive 360° protection.

Figure 3: The dual-lens setup allows simultaneous monitoring of two distinct zones.

4.2 Režimy nočního vidění

The Cruiser Dual offers four night vision modes for optimal visibility in low-light conditions:

• Infračervený režim: Provides clear black-and-white images in complete darkness using infrared LEDs.
• Barevný režim: Integrated spotlights illuminate the area, enabling full-color night vision.
• Inteligentní režim: Automatically switches from infrared to color night vision when motion is detected.
• Režim vypnutí: Disables night vision features.

Figure 4: Different night vision modes for various lighting conditions.

4.3 Smart Tracking and Detection

Activate the Smart Tracking function in the Imou Life App to enable the PT lens to automatically follow moving objects. The IMOU SENSE algorithm enhances detection accuracy for people and vehicles, reducing false alarms.

4.4 Two-Way Audio and Active Deterrence

The built-in microphone and speaker allow for real-time two-way communication. You can speak to visitors or deter unwanted intruders. The camera also features an integrated spotlight and a 110 dB siren, which can be activated automatically upon motion detection to scare off unauthorized persons.

4.5 Možnosti úložiště

The camera supports local storage via a Micro-SD card (up to 256 GB) and cloud storage through the Imou Cloud service (subscription may be required).

5. Údržba

To ensure optimal performance and longevity of your Imou Cruiser Dual camera, follow these maintenance guidelines:

• Čištění: Periodically wipe the camera lenses and body with a soft, damp tkanina. Vyhněte se používání agresivních chemikálií nebo abrazivních materiálů.
• Aktualizace firmwaru: Regularly check for and install firmware updates via the Imou Life App. Updates often include performance improvements, new features, and security enhancements.
• Ochrana proti počasí: While the camera is IP66 certified for dust and water resistance, ensure its mounting location provides some protection from direct, prolonged exposure to extreme weather conditions if possible.

6. Řešení problémů

If you encounter issues with your Imou Cruiser Dual camera, refer to the following common solutions:

• Fotoaparát offline: Check your Wi-Fi connection and ensure the camera is within range of your router. Restart the camera and your router.
• Špatná kvalita obrazu: Ensure the lenses are clean and free from obstructions. Check your internet connection speed.
• Detekce pohybu nefunguje: Verify that motion detection is enabled in the Imou Life App settings. Adjust sensitivity levels if necessary.
• Žádné obousměrné audio: Zkontrolujte nastavení mikrofonu a reproduktorů v aplikaci. Ujistěte se, že je hlasitost nastavena na dostatečnou úroveň.
• SD karta nenahrává: Ensure the SD card is properly inserted and formatted within the app. Check if the card is full or corrupted.

For more detailed troubleshooting or persistent issues, consult the help section within the Imou Life App or visit the official Imou support webmísto.

7. Specifikace

8. Záruka a podpora

Informace o záruce a technickou podporu získáte od oficiálního prodejce Imou. website or contact Imou customer service. Keep your purchase receipt as proof of purchase for warranty claims.
