Lorelli Matrix Neo Convertible Baby Crib

1. Konec produktuview

The Lorelli Matrix Neo Convertible Baby Crib is a versatile piece of nursery furniture designed to adapt as your child grows. It features a sturdy construction with two integrated drawers for storage and a two-level adjustable mattress base. This crib can be converted from a baby crib to a toddler bed or a sofa for a child's room by removing the side bars.

Image 1.1: The Lorelli Matrix Neo Convertible Baby Crib in its standard crib configuration, featuring white bars, pink accents, and two grey drawers at the base.

2. Bezpečnostní informace

Please read and understand all safety warnings and instructions before assembling and using the Lorelli Matrix Neo Convertible Baby Crib. Failure to follow these instructions could result in serious injury or death.

• Maximální hmotnost: Do not exceed the recommended maximum weight of 56 kg for this crib.
• Rozměr matrace: Use only a mattress that is 1.20m x 60cm with a maximum thickness of 12cm. The mattress is not included with this product.
• Shromáždění: Ensure all parts are correctly assembled and tightened before use. Regularly check all screws and fittings to ensure they remain secure.
• Netoxické materiály: This product is made with non-toxic paints and high-quality 18mm melamine boards, complying with European safety standards EN 716 1-2-: 08.
• Nebezpečí: Uchovávejte malé díly, plastové sáčky a obalové materiály mimo dosah dětí, abyste předešli nebezpečí udušení.
• Umístění: Do not place the crib near windows where cords from blinds or drapes could strangle a child. Do not place near heaters or open flames.
• Dozor: Never leave a child unattended in the crib.

3. Obsah balení

Před zahájením montáže ověřte, zda jsou všechny níže uvedené komponenty přítomny a nepoškozené. Pokud některé díly chybí nebo jsou poškozené, nepokračujte v montáži a kontaktujte zákaznickou podporu.

• Crib side panels (2)
• Crib end panels (2)
• Mattress base (1)
• Komponenty zásuvek (2 sady)
• Hardware pack (screws, bolts, nuts, dowels, etc.)
• Návod k montáži

Note: A mattress is NOT included with this product and must be purchased separately. Ensure the mattress dimensions are 1.20m x 60cm with a maximum thickness of 12cm.

4. Nastavení a montáž

Assembly of the Lorelli Matrix Neo Convertible Baby Crib requires two adults. Follow the detailed step-by-step instructions provided in the included manual for easy and quick installation. Ensure you have a clear, flat workspace.

4.1 Initial Crib Assembly

1. Vybalte všechny součásti a rozložte je na měkký, čistý povrch, abyste zabránili poškrábání.
2. Attach the side panels to the end panels using the provided hardware. Do not overtighten.
3. Install the mattress base. The base has two adjustable levels. For newborns, position the base at the higher level for easier access. For older infants who can sit up or pull themselves to a standing position, lower the mattress base to the lowest level to prevent them from climbing out.
4. Assemble the two drawers according to the separate drawer assembly instructions.
5. Slide the assembled drawers into the designated slots at the base of the crib. Ensure they operate smoothly and the locking mechanism functions correctly.
6. Once fully assembled, check all connections and tighten all screws securely.

Obrázek 4.1: Zavírací mechanismus view of the Lorelli Matrix Neo crib, highlighting the two spacious drawers at the bottom and the adjustable mattress base.

4.2 Converting to Toddler Bed / Sofa

The crib can be converted into a toddler bed or a sofa for a child's room. This transformation typically involves removing one or both of the side rail panels.

1. Ensure the mattress base is set to the lowest position for safety.
2. Carefully remove the screws and hardware securing one or both of the long side rail panels.
3. Store the removed panels and hardware in a safe place for future use, if you wish to convert it back to a crib.
4. For a toddler bed, one side rail is typically removed. For a sofa, both side rails are removed, leaving the headboard and footboard.

Image 4.2: The Lorelli Matrix Neo converted into a sofa configuration, showing the removal of the side rails while retaining the base drawers.

5. Návod k obsluze

5.1 Adjusting the Mattress Base Height

The mattress base can be adjusted to two different heights to accommodate your child's developmental stages:

• Horní úroveň: Ideal for newborns and infants who cannot yet sit up or push themselves up on their hands and knees. This position reduces strain on your back when lifting the baby.
• Lower Level: Essential for older infants who can sit up, crawl, or pull themselves to a standing position. This prevents them from climbing out of the crib.

To adjust the height, remove the mattress and carefully detach the mattress base from its current position. Reattach it to the desired height using the designated hardware and ensure it is securely fastened at all four corners.

5.2 Používání zásuvek

The two large drawers at the base of the crib provide convenient storage. They are equipped with a locking mechanism to keep them securely closed. To open, unlock the drawer (if locked) and pull the handle. To close, push the drawer fully in until it clicks into place, then engage the lock if desired.

6. Údržba

Proper maintenance will ensure the longevity and safety of your Lorelli Matrix Neo Convertible Baby Crib.

• Čištění: Wipe the crib surfaces with a dry, soft cloth. For stubborn marks, a slightly damp Lze použít hadřík s jemným mýdlem a ihned osušit. Nepoužívejte abrazivní čisticí prostředky ani agresivní chemikálie.
• Kontrola hardwaru: Periodically check all screws, bolts, and other hardware to ensure they are tight and secure. Loose hardware can compromise the crib's stability and safety.
• Kontrola poškození: Regularly inspect the crib for any signs of damage, such as cracks, splinters, or broken parts. Discontinue use immediately if any damage is found and contact customer support for replacement parts.
• Skladování: If storing the crib, disassemble it carefully and store all parts and hardware in a dry, safe place.

7. Řešení problémů

This section addresses common issues you might encounter with your Lorelli Matrix Neo Convertible Baby Crib.

8. Specifikace

9. Informace o záruce

Lorelli products are manufactured to high-quality standards. For specific warranty terms and conditions, please refer to the warranty card included with your purchase or visit the official Lorelli webUschovejte si doklad o koupi pro případné reklamace.

10. Zákaznická podpora

If you have any questions, require assistance with assembly, or need replacement parts, please contact Lorelli customer support. Refer to the contact information provided in your product packaging or on the official Lorelli webmísto.

When contacting support, please have your product model number (10150490032A) and purchase date readily available.
