Návod k obsluze modulu WiFi přepínače LoraTap 4.0

Zavedení

The LoraTap WiFi Switch Module 4.0 is designed to transform your existing light switches into smart switches without needing to replace them. This module allows you to control your lighting and other connected devices remotely via a smartphone application or voice commands, integrating seamlessly into your smart home ecosystem. It offers a cost-effective solution to upgrade your home with smart functionalities while preserving the traditional aesthetic of your switches.

Bezpečnostní upozornění

• Always turn off the electricity supply at the main circuit breaker before installation or any maintenance. Failure to do so can result in electric shock or serious injury.
• Instalaci by měl provádět pouze kvalifikovaný elektrikář nebo osoba s důkladnými znalostmi elektroinstalace.
• A neutral conductor is required for the proper operation of this module. Ensure your electrical box has a neutral wire available.
• This device is designed for indoor use only and must be installed in a dry environment.
• Do not use metal switch covers with this module, as they may interfere with Wi-Fi signals.
• Ensure the module's maximum load capacity (230V / 10A / 2300W) is not exceeded.

Konec produktuview

The LoraTap WiFi Switch Module 4.0 is a compact device designed for easy integration behind your existing wall switches or in electrical boxes. It enables smart control over your lights and other appliances while allowing the continued use of your traditional wall switch.

Image: The LoraTap WiFi Switch Module 4.0, highlighting its compact size and connection points. This module allows for smart control while retaining your traditional wall switch functionality.

Klíčové vlastnosti:

• Duální ovládání: Operate connected devices via both your traditional wall switch and a smartphone app.
• Kompaktní design: Measures 4.6  4.6  1.8 cm, fitting into standard flush-mounted boxes.
• Ovládání aplikace: Manage lights, fans, and other appliances (up to 10A/2300W) using the Smart Life or Tuya app.
• Hlasové ovládání: Kompatibilní s Amazon Alexa a Google Home pro ovládání bez použití rukou.
• Plánování a časovače: Create custom schedules, countdown timers, and anti-theft timers for automated control.
• Není vyžadován žádný rozbočovač: Connects directly to your 2.4 GHz Wi-Fi network.

Nastavení

1. Elektroinstalace

Before proceeding, ensure the main power supply is OFF. This module is designed to be installed behind your existing wall switch or within a suitable electrical box. It requires a neutral wire for operation.

Image: Detailed wiring diagram for the LoraTap WiFi Switch Module 4.0, showing connections for input, output, and switch terminals. This diagram illustrates how to integrate the module with or without an existing wall switch, and with two switches.

Refer to the wiring diagram above for correct connections. The module supports various configurations, including installations with or without a traditional wall switch, and with two switches for multi-way control.

Image: The LoraTap WiFi Switch Module 4.0 discreetly installed behind a standard wall switch, demonstrating how the existing switch remains functional.

The compact size of the module (46mm x 46mm x 18mm) allows it to fit into most standard flush-mounted electrical boxes.

Image: A size comparison illustrating the compact dimensions of the LoraTap WiFi Switch Module 4.0 (46x46x18mm) compared to a larger, generic smart switch module.

2. Párování aplikací

1. Download the 'Smart Life' or 'Tuya' app from your smartphone's app store (available for iOS 8.0+ and Android 4.1+).
2. Zaregistrujte se nebo se přihlaste ke svému účtu.
3. Ensure your smartphone is connected to a 2.4 GHz Wi-Fi network. The module does not support 5 GHz networks.
4. Power on the LoraTap WiFi Switch Module. The indicator light on the module should blink rapidly, indicating it's in pairing mode. If not, refer to the app's instructions for resetting the device to pairing mode.
5. In the app, tap '+' to add a new device. Select 'Electrical Switch' or 'Switch (Wi-Fi)'.
6. Follow the on-screen instructions to connect the module to your Wi-Fi network. You will need to enter your Wi-Fi password.
7. Once successfully paired, you can rename the device for easier identification (e.g., 'Living Room Light').

Návod k obsluze

1. Ovládání aplikací

After successful pairing, you can control your connected devices from anywhere using the Smart Life or Tuya app on your smartphone.

• Open the app and select the device you wish to control.
• Tap the on/off button to toggle the power state of the connected appliance.
• The app allows you to control multiple devices and group them for simultaneous control.

Image: A smartphone displaying the Smart Life app interface, showing how to control multiple LoraTap WiFi Switch Modules. This demonstrates the ability to manage various lights and devices from a single application.

2. Hlasové ovládání

The LoraTap WiFi Switch Module 4.0 is compatible with Amazon Alexa and Google Home, allowing for convenient voice control.

1. Ensure your Amazon Alexa or Google Home device is set up and linked to your Smart Life/Tuya account.
2. Používejte hlasové příkazy, jako například:
   • „Alexo, zapni [Název zařízení]“
   • „Hej Google, vypni [název zařízení]“
   • "Alexa, set [Device Name] to 50%" (if dimming is supported by the connected device and module configuration)

Image: A visual representation of using voice commands with Amazon Alexa and Google Home devices to control the LoraTap WiFi Switch Module 4.0, demonstrating hands-free operation.

3. Plánování a časovače

Automate your devices by setting schedules and timers within the Smart Life or Tuya app.

• jízdní řády: Set specific times for devices to turn on or off daily, on certain days, or based on sunrise/sunset.
• Odpočítávadlo: Set a timer for a device to turn off after a specified duration (e.g., turn off the light after 15 minutes).
• Anti-theft Timer: Simulate occupancy by randomly turning lights on and off when you are away.

Image: Screenshots from the Smart Life app showing options for setting schedules (e.g., 7:30 PM ON) and countdown timers (e.g., 15 minutes OFF), illustrating automation capabilities.

Údržba

The LoraTap WiFi Switch Module 4.0 requires minimal maintenance. To ensure optimal performance and longevity:

• Keep the module and surrounding electrical components clean and free from dust.
• Nevystavujte modul vlhkosti nebo extrémním teplotám.
• Periodically check for firmware updates through the Smart Life/Tuya app to ensure you have the latest features and security enhancements.
• If you need to access the module for any reason, always disconnect the power supply first.

Odstraňování problémů

If you encounter issues with your LoraTap WiFi Switch Module 4.0, try the following troubleshooting steps:

• Zařízení nereaguje:
  • Check if the main power supply to the module is on.
  • Verify your Wi-Fi router is working and the module is within range.
  • Ujistěte se, že je váš chytrý telefon připojen k internetu.
  • Restart the module by turning off and on the power supply at the circuit breaker.
• Nelze spárovat zařízení:
  • Confirm your Wi-Fi network is 2.4 GHz. The module does not support 5 GHz Wi-Fi.
  • Ensure the module's indicator light is blinking rapidly, indicating pairing mode. If not, reset the device (refer to app instructions for reset procedure).
  • Check your Wi-Fi password for accuracy during pairing.
  • Move the module closer to your Wi-Fi router during the pairing process.
• Problémy s hlasovým ovládáním:
  • Ověřte, zda je váš účet Smart Life/Tuya správně propojen s Amazon Alexa nebo Google Home.
  • Ensure the device name in the app matches the name you are using in your voice commands.
  • Zkontrolujte internetové připojení vašeho zařízení s hlasovým asistentem.
• Traditional Switch Not Working:
  • Double-check the wiring connections according to the installation diagram.
  • Ensure the switch itself is functional.

If problems persist, please contact LoraTap customer support for further assistance.

Specifikace

Záruka a podpora

LoraTap provides a premium lifetime warranty for all its products, demonstrating commitment to quality and customer satisfaction. For any technical assistance, troubleshooting, or warranty claims, please contact LoraTap customer support through their official webnebo kontaktní informace poskytnuté při nákupu.

You can find more information and various types of wireless/WiFi switches on the official LoraTap webmísto.
