YABER Y61 WiFi Mini Projector Instruction Manual

Zavedení

This manual provides detailed instructions for setting up, operating, maintaining, and troubleshooting your YABER Y61 WiFi Mini Projector. Please read thoroughly before use.

Klíčové vlastnosti

• Wireless Connection (iOS/Android) & ZOOM Function: Seamlessly mirror content from your smartphone or other Miracast-enabled devices. Adjust image size from 100% to 75% remotely.
• Native 1280*720P (1080P Supported) & Innovative Display Tech: Experience bright, clear images with 5500L brightness and a 6000:1 contrast ratio, offering outstanding color accuracy.
• Small Size & Wide Compatibility: Portable design with multiple ports (HDMI, USB, VGA, AV, Audio) for connection to TV Box, Amazon Fire Stick TV, Chromecast, PC, laptop, tablet, external speakers, USB stick, iPad, iPhone, and Android smartphones.
• HIFI Stereo Sound & Latest Advanced Cooling System: Built-in 3W dual stereo speakers with SRS sound. Advanced silent cooling system with 3 fans. SmarEco technology extends lamp životnost až 100,000 XNUMX hodin.
• Three-Year & Lifetime Professional Support: Enjoy comprehensive support for your product.

Co je v krabici

• Napájecí kabel
• HDMI kabel
• AV kabel
• Krytka objektivu projektoru
• Čisticí sada
• Dálkové ovládání
• Uživatelská příručka

Image: YABER Y61 Projector and its accessories, including cables, remote, and cleaning kit.

Konec produktuview

Přední View

Image: The front of the YABER Y61 projector, showing the projection lens.

The front of the projector features the projection lens and the infrared receiver.

Nahoru View

Image: The top panel of the YABER Y61 projector, displaying control buttons for navigation and power.

The top panel includes control buttons for navigation, power, and source selection.

Zadní View

Image: The rear panel of the YABER Y61 projector, showing various input/output ports.

The rear panel houses various input/output ports: 2x USB, 2x HDMI, AV, Audio Out, and IR receiver.

Dno View

Image: The bottom of the YABER Y61 projector, showing mounting points and an adjustable foot.

The bottom of the projector includes mounting points for tripods and an adjustable foot for angle correction.

Nastavení

Základní nastavení

1. Připojení napájení: Připojte napájecí kabel k projektoru a do elektrické zásuvky.
2. Umístění: Place the projector on a stable, flat surface or mount it using a compatible tripod. Ensure the projection path is clear.
3. Zapnutí: Stisknutím tlačítka napájení na projektoru nebo dálkovém ovladači jej zapněte.
4. Nastavení zaostření: Otáčejte zaostřovacím kroužkem na objektivu projektoru, dokud nebude obraz jasný a ostrý.
5. Korekce lichoběžníkového zkreslení: Use the keystone correction feature (manual or automatic, if available) to adjust the image shape if it appears distorted (trapezoidal).

Image: YABER Y61 projector illustrating focus and keystone correction adjustments.

Konektivita

Wireless Connection (Screen Mirroring)

The Y61 supports wireless screen mirroring for iOS and Android devices.

Image: Diagram showing wireless screen mirroring from a mobile device to the YABER Y61 projector.

1. Ujistěte se, že je projektor a mobilní zařízení připojeno ke stejné síti Wi-Fi.
2. On the projector's main menu, select "iOS Cast" for iOS devices or "Miracast" for Android devices.
3. Follow the on-screen instructions to enable screen mirroring on your mobile device and select the projector from the list of available devices.

Drátové připojení

The projector offers multiple wired input options for various devices.

• HDMI: Connect your device (e.g., TV Box, Amazon Fire Stick TV, PC, laptop, PS4) to the projector's HDMI port using an HDMI cable. Select the corresponding HDMI input from the projector's source menu.
• USB: Insert a USB stick into the USB port to play media files přímo.
• AV: Use the provided AV cable to connect older devices (e.g., DVD player) to the AV port.
• Audio výstup: Connect external speakers or headphones to the Audio Out port for enhanced sound.

Návod k obsluze

Funkce zvětšení

The projector features a zoom function that allows you to adjust the image size from 100% to 75% using the remote control without moving the projector.

Zvuk

The Y61 LED projector has built-in 3W dual stereo speakers with SRS sound system. For a more immersive experience, external speakers can be connected via the Audio Out port.

Údržba

Čištění

Regularly clean the projector lens and vents to ensure optimal performance and longevity. Use the provided cleaning kit for the lens.

Lamp Život

Image: Illustration of the YABER Y61's advanced LED light source and its 100,000-hour lamp život.

Projektor využívá technologii SmarEco k minimalizaciamp power consumption, extending the useful life of the lamp to a maximum of 100,000 hours.

Odstraňování problémů

• Žádný obraz/signál: Check all cable connections (HDMI, AV, Power). Ensure the correct input source is selected on the projector. For wireless mirroring, confirm both devices are on the same Wi-Fi network.
• Rozmazaný obrázek: Adjust the focus ring on the lens. Ensure the projector is placed at an optimal distance from the screen.
• Zkreslený obraz (lichoběžník): Pro úpravu tvaru obrazu použijte funkci korekce lichoběžníkového zkreslení.
• Žádný zvuk: Zkontrolujte nastavení hlasitosti na projektoru i na připojeném zařízení. Pokud používáte externí reproduktory, ujistěte se, že jsou správně připojeny a zapnuté.
• Black Spot on Screen: Refer to the provided support information or contact customer service for assistance.

Specifikace

Záruka a podpora

YABER provides a 6-month return policy and 3-year repair warranty. Lifetime professional technical support is also available. For any issues, please contact YABER customer service.
