Zavedení
Konec produktuview
The Renogy DCC12 Series DC to DC Charger is designed to efficiently charge your auxiliary or house batteries from your vehicle's alternator or starter battery. This multi-stage smart charger is compatible with various battery types, including AGM, Flooded, Gel, and Lithium deep cycle batteries, ensuring optimal and automatic charging. It incorporates multiple electronic protections for enhanced safety and isolates input from output to prevent incorrect voltage transmission. Its compact and robust design makes it suitable for a wide range of applications, including RVs, commercial vehicles, boats, and yachts.
Klíčové vlastnosti
- Compatible Multiple Battery Types: Compatible with a multitude of alternator types, the Renogy 12V DC to DC charger offers correct charging for AGM, Flooded, Gel, and Lithium batteries.
- Inteligentní Multi-Stage Nabíjení: The 60A DC to DC smart charger will charge your house batteries from the starter battery by 3-stage charging (Bulk, Boost, and Float), to make sure it optimally and automatically charges to 100%.
- Various Protections For Ultra Safety: The Renogy on-board battery charger with high-quality offers Over-voltage Protection, Over-temperature Protection, and Reverse Polarity Protection to ensure the operation safety. It also isolates the input and output to prevent voltage transmission errors and interfere with house battery charging.
- Protect Your Starter Battery: The DC-DC battery charger is capable of identifying whether the generator is started, to prevent over-discharge of the starting battery and protect the generator.
- Reliable Quality & Easy Installation: The compact and robust design of the dc to dc charger makes it suitable for all conditions, and also resolves your concern about the limited room in your vehicle.
Co je v krabici
- 1 x Renogy 12V 60A DC to DC Battery Charger (Charge Controller)
Konec produktuview
Nastavení a instalace
Připojení vodičů
The Renogy DC to DC Charger requires proper wiring to function correctly. Ensure all connections are secure and follow polarity guidelines.
Required Cables (Not Included)
- 4-gauge cables for connecting the starter battery and deep cycle battery to the charger.
- 16-gauge wire for the D+ signal cable.
Připojení nabíječky
Connect the positive and negative terminals of your starter battery to the corresponding input terminals on the DC to DC charger. Similarly, connect the positive and negative terminals of your deep cycle (house) battery to the output terminals of the charger. Ensure all connections are tightened securely.
D+ Signal Connection
The D+ signal input is crucial for activating the charger. This input should be wired to a 12V source that becomes active when the vehicle's engine is running (e.g., ignition switch). This ensures the charger only operates when the alternator is providing power.
Volitelný snímač teploty
An optional temperature sensor (sold separately) can be connected to the RJ11 port. This sensor allows the charger to continuously adjust the charging voltage based on the battery temperature, optimizing charging efficiency and battery lifespan.
Battery Type Selection (DIP Switches)
The charger features DIP switches to select the appropriate battery type for your deep cycle battery. Refer to the table below for the correct switch settings based on your battery chemistry.
| Typ baterie | Přepínač DIP 1 | Přepínač DIP 2 | Přepínač DIP 3 | Přepínač DIP 4 | Přepínač DIP 5 |
|---|---|---|---|---|---|
| Lithium (LiFePO4) | ON | ON | VYPNUTO | VYPNUTO | VYPNUTO |
| AGM | VYPNUTO | ON | VYPNUTO | VYPNUTO | VYPNUTO |
| Gel | ON | VYPNUTO | VYPNUTO | VYPNUTO | VYPNUTO |
| Zatopeno | VYPNUTO | VYPNUTO | VYPNUTO | VYPNUTO | VYPNUTO |
Ensure the correct battery type is selected to prevent damage to your battery and ensure optimal charging performance.
Návod k obsluze
Once the charger is correctly installed and the battery type is set, the unit is ready for operation.
Automatické nabíjení
The Renogy DC to DC Charger automatically begins charging the deep cycle battery when the vehicle's engine is running and the D+ signal is active. The power indicator LED on the charger will illuminate green, indicating that the charger is on and actively charging.
Multi-Stage Nabíjení
Nabíječka využívá 3-stage charging algorithm (Bulk, Boost, and Float) to ensure your deep cycle battery is charged optimally and automatically to 100% capacity, prolonging its lifespan.
Ochranné funkce
The charger is equipped with various protection features for safe operation, including Over-voltage Protection, Over-temperature Protection, and Reverse Polarity Protection. These features safeguard both the charger and your batteries.
Údržba
Regular maintenance ensures the longevity and optimal performance of your Renogy DC to DC Charger.
- Pravidelně kontrolujte všechna kabelová spojení, abyste se ujistili, že jsou bezpečná a bez koroze.
- Keep the charger's ventilation fans and grilles clear of dust and debris to ensure proper airflow and prevent overheating.
- Clean the exterior of the charger with a dry, soft cloth. Do not use harsh chemicals or abrasive cleaners.
- If an optional temperature sensor is used, ensure it remains securely attached to the battery and is not damaged.
- Store the charger in a dry, well-ventilated area when not in use for extended periods.
Odstraňování problémů
This section addresses common issues you might encounter with your Renogy DC to DC Charger.
| Problém | Možná příčina | Řešení |
|---|---|---|
| Charger not turning on (Power LED off) | No D+ signal; Loose wiring; Blown fuse; Low starter battery voltage. | Check D+ signal connection to ensure it's active when the engine is running. Verify all wiring connections are secure. Check inline fuses on both input and output lines. Ensure starter battery voltage je nad minimální provozní prahovou hodnotou. |
| Svítí poruchová LED dioda | Over-temperature; Over-voltage; Reverse polarity. | Check for obstructions around ventilation fans. Allow unit to cool down. Verify input/output voltages are within specifications. Recheck wiring for correct polarity. |
| Battery not charging optimally | Incorrect battery type setting; Faulty temperature sensor (if used); Undersized cables. | Verify DIP switch settings match your battery type. Check temperature sensor connection and function. Ensure cable gauge is sufficient for the current draw. |
If the issue persists after attempting these solutions, please contact Renogy customer support.
Specifikace
| Funkce | Detail |
|---|---|
| Číslo modelu | 60A |
| Rozměry produktu | 12.2 x 6.9 x 2.7 palce (311 x 175 x 68 mm) |
| Hmotnost položky | 5.29 libry (2.4 kg) |
| Výstupní objemtage | 12 V (DC) |
| Kompatibilní typy baterií | AGM, Flooded, Gel, Lithium (LiFePO4) |
| Nabíjení Stages | 3-Stage (Bulk, Boost, Float) |
| Bezpečnostní ochrany | Voltage, Over-temperature, Reverse Polarity |
Záruka a podpora
Informace o záruce
Renogy products are designed for reliability and performance. For detailed warranty information regarding your DC to DC Charger, please refer to the warranty card included with your product or visit the official Renogy webmísto.
Zákaznická podpora
Should you require technical assistance, troubleshooting, or have any questions about your Renogy DC to DC Charger, please contact Renogy Customer Support. Contact details can be found on the official Renogy webna webu nebo v obalu vašeho produktu.
