Batavia 7062678

Návod k obsluze čisticího kartáče a čističe teras Batavia Maxxbrush 1020W

Model: 7062678

1. Úvod

Welcome to the Batavia Maxxbrush 1020W electric cleaning brush. This powerful tool is designed for efficient removal of weeds, moss, algae, sand, and other stubborn dirt from various outdoor surfaces. It is also suitable for smoothing and combing artificial turf. Please read this instruction manual carefully before operating the device to ensure safe and effective use.

Batavia Maxxbrush 1020W electric cleaning brush

Konecview of the Batavia Maxxbrush 1020W electric cleaning brush, showcasing its design with the telescopic handle and brush head.

2. Bezpečnostní pokyny

Always observe the following safety precautions when using electrical tools to reduce the risk of electric shock, fire, and serious injury.

  • Přečtěte si celý manuál: Seznamte se s ovládacími prvky a správným používáním zařízení.
  • Používejte vhodné osobní ochranné prostředky (OOP): To zahrnuje ochranné brýle, rukavice a pevnou obuv.
  • Udržujte děti a přihlížející v dostatečné vzdálenosti: Nedovolte dětem nebo neproškoleným osobám obsluhovat zařízení.
  • Ensure proper power connection: Connect the device to a properly grounded outlet. Do not modify the plug.
  • Vyhněte se vlhkým podmínkám: Do not operate the device in rain or damp environments. Keep the power cord away from water.
  • Před použitím zkontrolujte: Check for damaged parts, loose connections, or any other condition that may affect operation.
  • Odpojte, když se nepoužívá: Always disconnect the power supply before cleaning, performing maintenance, or storing the device.

3. Zahrnuté komponenty

The Batavia Maxxbrush 1020W package typically includes the following items:

  • Batavia Maxxbrush main unit
  • Telescopic handle (2 parts)
  • Green nylon spiral brush
  • Napájecí kabel
Batavia Maxxbrush with interchangeable brushes

The Batavia Maxxbrush standing upright, demonstrating its compact design and the availability of different brush types for various cleaning tasks.

4. Nastavení a montáž

Follow these steps to assemble your Maxxbrush:

  1. Attach the telescopic handle: Connect the two parts of the telescopic handle securely. Then, attach the assembled handle to the main unit of the Maxxbrush. Ensure it clicks into place or is tightened according to the instructions on the device.
  2. Install the brush head: Align the green nylon spiral brush with the brush mounting mechanism on the main unit. Push and secure the brush until it is firmly seated.
  3. Připojte k napájení: Plug the power cable into the device and then into a suitable electrical outlet. Ensure the power cord is routed safely to avoid tripping hazards.

5. Návod k obsluze

Before starting, ensure all safety precautions are followed and the device is properly assembled.

5.1 Zapnutí/vypnutí

  • To turn on the Maxxbrush, press the power switch located on the handle.
  • To turn off, release or press the power switch again, depending on the switch type.

5.2 Adjusting Brush Speed

The Maxxbrush features a rotary dial to adjust the brush head speed. Turn the dial to increase or decrease the speed according to the surface and the type of dirt being removed. Lower speeds are suitable for lighter cleaning or delicate surfaces, while higher speeds provide more aggressive cleaning.

5.3 Techniky čištění

  • For Patios and Paved Surfaces: Guide the Maxxbrush slowly and steadily over the surface. Apply light pressure. The rotating brush will dislodge dirt, moss, and weeds. Be aware that the brush may splash dirt forward and backward, especially on heavily soiled surfaces.
  • For Wooden Decks: Use a moderate speed setting. Move the brush along the grain of the wood to avoid damage.
  • For Artificial Turf: Use a lower speed setting to gently comb and smooth the artificial grass fibers. This helps to restore the turf's appearance.
User operating Batavia Maxxbrush on a paved path

A user operating the Batavia Maxxbrush on a paved outdoor path, illustrating the ergonomic handling and effective cleaning action.

Close-up of Batavia Maxxbrush cleaning a wet patio surface

Detailní záběr view of the Maxxbrush in action, effectively cleaning a wet patio surface and removing accumulated dirt.

6. Údržba

Regular maintenance ensures the longevity and optimal performance of your Maxxbrush.

  • Čištění hlavice kartáčku: After each use, remove any debris, weeds, or dirt accumulated on the brush bristles. If necessary, rinse the brush head with water, ensuring no water enters the motor housing. Allow it to dry completely before storage.
  • Čištění hlavní jednotky: Otřete hlavní jednotku reklamouamp tkanina. Nepoužívejte agresivní chemikálie nebo abrazivní čisticí prostředky.
  • Skladování: The 2-part telescopic handle allows for compact storage. Disassemble the handle if desired and store the Maxxbrush in a dry, secure location, away from direct sunlight and extreme temperatures.

7. Řešení problémů

If you encounter issues with your Maxxbrush, refer to the following common problems and solutions:

ProblémMožná příčinaŘešení
Zařízení se nespustíNo power supply; Power switch off; Damaged cableCheck power connection; Ensure switch is on; Inspect cable for damage and replace if necessary
Špatný čisticí výkonBrush worn out; Incorrect brush type for surface; Insufficient speedReplace brush; Use appropriate brush for the task; Adjust speed setting
Nadměrné vibrace nebo hlukBrush unbalanced or damaged; Debris caught in brush mechanismInspect and clean brush; Replace brush if damaged

Pokud problém přetrvává i po vyzkoušení těchto řešení, kontaktujte zákaznickou podporu.

8. Technické specifikace

FunkceSpecifikace
ZnačkaBatavia
Číslo modelu7062678
Moc1020 W
Rozměry produktu (D x Š x V)22 x 139 x 38 cm
Hmotnost položky7.51 kg
Materiál rukojetiPlastic (Durable, corrosion-resistant, easy-care)
Materiál štětinyNylon
Doporučené použití produktuČištění podlah
Doporučení pro povrchHard surfaces, artificial turf
Zahrnuté komponenty1 piece (main unit with brush)

9. Informace o záruce

Tento produkt je dodáván se standardní zárukou výrobce. Konkrétní podmínky a dobu trvání záruky naleznete v záruční kartě, která je součástí balení produktu. Uschovejte si doklad o koupi pro případné reklamace.

10. Zákaznická podpora

For further assistance, technical support, or spare parts inquiries, please contact Batavia customer service. Contact details can typically be found on the official Batavia webwebu nebo na obalu vašeho produktu.

Webmísto: www.batavia.eu (Napřampodkaz, prosím ověřte oficiální webweb)
