Uživatelská příručka k masážnímu polštáři BEPER 40.501

Zavedení

The BEPER 40.501 Massage Cushion is designed to provide a deep, rhythmic massage for various body parts, including the back, neck, shoulders, abdomen, calves, thighs, and feet. It features four rotating massage nodes that operate in both clockwise and counter-clockwise directions, promoting blood circulation and muscle relaxation. This versatile massage cushion can be used at home or in a car, thanks to the included adapters.

The device is equipped with an automatic shut-off function after 15 minutes of use to prevent overheating and ensure user safety.

Bezpečnostní informace

For your safety, please observe the following guidelines:

• The massage cushion features an automatic shut-off safety mechanism that activates after 15 minutes of continuous use. This is designed to prevent overheating of the device.
• Only use the massage cushion with the certified power adapters provided by the manufacturer. Using uncertified adapters may pose a safety risk and void the warranty.

Nastavení

The BEPER 40.501 Massage Cushion is designed for convenient use in various settings. Follow these steps for initial setup:

1. Rozbalení: Carefully remove the massage cushion and all accessories from the packaging. Ensure all components are present: the massage cushion, home power adapter, and car power adapter.
2. Připojení napájení:
   • Pro domácí použití: Connect the home power adapter to the massage cushion's power input. Plug the adapter into a standard 110V or 220V AC electrical outlet.
   • Pro použití v autě: Connect the car power adapter to the massage cushion's power input. Plug the car adapter into your vehicle's 12V DC cigarette lighter socket.
3. Umístění: The cushion features an adjustable elastic band. Use this band to securely attach the massage cushion to a chair, car seat, or any suitable support for optimal positioning during use.

Image: The BEPER 40.501 Massage Cushion showing its components, including the home adapter, car adapter, ON/OFF button, and elastic band for fixing.

Image: The massage cushion securely attached to a car seat, highlighting its features like four massage knots, dual power adapters, and the 15-minute auto shut-off function.

Návod k obsluze

To use your BEPER 40.501 Massage Cushion, follow these simple steps:

1. Zapnutí: Once the cushion is connected to a power source (home or car adapter), press the ON/OFF button located on the side of the cushion. The massage nodes will begin to rotate.
2. Směr masáže: The massage nodes rotate in both clockwise and counter-clockwise directions. Each press of the ON/OFF button will cycle through different modes, typically alternating the rotation direction or activating a heat function if available. Refer to the specific button functionality for your model.
3. Positioning for Massage: Place the massage cushion against the desired body area (neck, back, shoulders, etc.). The ergonomic design allows it to conform to various body contours.
4. Automatické vypnutí: The device will automatically turn off after approximately 15 minutes of continuous operation. This is a safety feature to prevent overheating. If you wish to continue the massage, simply press the ON/OFF button again to restart the cycle.
5. Vypnout: To manually turn off the massage cushion, press and hold the ON/OFF button until the device stops operating. Always disconnect the power adapter from the electrical outlet or car socket when not in use.

Image: A close-up of the massage cushion's surface, illustrating the four illuminated massage nodes and the control button.

Image: A user demonstrating the massage cushion placed under the neck for targeted relief.

Image: An illustration indicating the versatility of the massage cushion for different body areas, including neck, arms, waist, legs, and ankles, promoting blood circulation and muscle relaxation.

Údržba

To ensure the longevity and proper functioning of your BEPER 40.501 Massage Cushion, follow these maintenance guidelines:

• Čištění: Disconnect the device from the power source before cleaning. Wipe the surface of the massage cushion with a soft, slightly damp hadříkem. Nepoužívejte abrazivní čisticí prostředky, rozpouštědla ani neponořujte zařízení do vody.
• Skladování: When not in use, store the massage cushion in a cool, dry place, away from direct sunlight and extreme temperatures. Keep it out of reach of children.
• Inspekce: Periodically inspect the power cords and adapters for any signs of damage. If any damage is observed, discontinue use and contact customer support.

Odstraňování problémů

If you encounter any issues with your BEPER 40.501 Massage Cushion, please refer to the following common troubleshooting steps:

• Zařízení se nezapíná:
  • Ensure the power adapter is securely connected to both the massage cushion and the power outlet/car socket.
  • Verify that the power outlet/car socket is functional. Try plugging in another device to confirm.
  • Check if the power adapter or cord is damaged. If so, discontinue use and seek a replacement.
• Massage Nodes Not Rotating:
  • Potvrďte, že je zařízení zapnuté.
  • If the device recently shut off, it might be due to the 15-minute auto-shutoff safety feature. Press the ON/OFF button again to restart.
• Neobvyklé zvuky nebo pachy:
  • Immediately turn off the device and disconnect it from the power source.
  • Nepokoušejte se opravit zařízení sami. Požádejte o pomoc zákaznickou podporu.

If the problem persists after following these steps, please contact BEPER customer support for further assistance.

Specifikace

Záruka a podpora

Specific warranty details and direct customer support contact information are not provided in the available product description. For warranty claims or technical assistance, please refer to the documentation included with your purchase or visit the official Beper website for regional support contacts.
