Zavedení
Thank you for choosing the ADE Professional Wireless Digital Weather Station, Model WS1703. This device combines a precise weather forecast station, indoor and outdoor thermometer, hygrometer, and barometer, all housed in a stylish genuine bamboo and high-quality ABS plastic casing. This manual provides detailed instructions for setup, operation, and maintenance to ensure optimal performance and longevity of your weather station.
Obrázek 1: ADE Professional Wireless Digital Weather Station main unit and outdoor sensor.
This image shows the main weather station unit with its large color display and a separate white outdoor sensor. The main unit features a bamboo frame, displaying various weather parameters like outdoor and indoor temperature, humidity, moon phase, and barometric pressure.
Obsah balení
Pečlivě zkontrolujte obsah balení. Pokud některé položky chybí nebo jsou poškozené, obraťte se na prodejce.
- ADE Professional Wireless Digital Weather Station (Main Unit)
- Bezdrátový venkovní snímač
- Napájecí adaptér
- 4 x AAA Batteries (for main unit and sensor)
- Uživatelská příručka (tento dokument)
Nastavení
1. Zapnutí hlavní jednotky
The main unit can be powered by either the included AC power adapter for continuous display illumination or by batteries for portable use.
- Napájení střídavým proudem: Connect the AC power adapter to the DC input port on the back of the main unit, then plug the adapter into a standard wall outlet. The display will light up immediately.
- Napájení baterie: Open the battery compartment on the back of the main unit. Insert 2 x AAA batteries (included), observing the correct polarity (+/-). Close the compartment. The display will illuminate for 15 seconds when a button is pressed.
2. Vložení baterií do venkovního senzoru
The outdoor sensor requires batteries for operation.
- Open the battery compartment on the back of the outdoor sensor.
- Insert 2 x AAA batteries (included), observing the correct polarity (+/-).
- Přihrádku bezpečně uzavřete.
Obrázek 2: Powering the main unit and outdoor sensor. This image illustrates the options for powering the weather station: either via an AC adapter for continuous operation or with batteries for portable use. It also shows the battery installation for the outdoor sensor.
3. Sensor Placement and Synchronization
Place the outdoor sensor in a shaded, dry location away from direct sunlight and precipitation to ensure accurate readings. The sensor has a range of up to 60 meters (200 feet) from the main unit.
- Ensure the main unit and outdoor sensor are within effective range of each other.
- The main unit will automatically attempt to connect with the outdoor sensor upon power-up. This may take a few minutes.
- Once connected, the outdoor temperature and humidity will appear on the main unit's display. If connection fails, try repositioning the sensor or pressing the 'Sensor' button on the main unit (if available) to initiate a manual search.
Návod k obsluze
Zobrazit přesview
The large LED color display provides a comprehensive overview of all weather data and time information.
Obrázek 3: Key functions and display areas. This image highlights various sections of the weather station's display, including outdoor temperature, indoor temperature, humidity, barometric pressure, moon phases, date, time, and animated weather forecasts.
- Venkovní teplota a vlhkost: Displays current readings from the wireless sensor. Includes Min/Max memory.
- Vnitřní teplota a vlhkost: Displays current readings from the main unit's internal sensors. Includes Min/Max memory.
- Animated Weather Forecast: Icons indicate sunny, partly cloudy, cloudy, rain, heavy rain/thunderstorm, heavy snowfall. Includes a trend indicator.
- Barometrický tlak: Shows current atmospheric pressure and a 12-hour history graph.
- Čas a datum: Radio-controlled clock (DCF) with perpetual calendar, day of the week (in 8 languages), and moon phases.
- Frost Alarm: An indicator for potential frost conditions.
Nastavení času a data
The weather station features a radio-controlled clock (DCF) that automatically synchronizes the time and date. Manual adjustment is also possible.
Obrázek 4: Radio-controlled clock and manual settings. This image illustrates the radio-controlled time synchronization feature and highlights the snooze button and adjustable backlight.
- Upon initial power-up, the unit will attempt to receive the DCF signal. This may take several minutes or hours depending on your location.
- If the signal is weak or unavailable, you can manually set the time, date, and language using the buttons on the back of the unit (refer to the detailed manual for specific button functions).
Funkce Alarm a Snooze
The weather station includes an alarm clock with a snooze feature.
- Press the 'ALARM' button (or similar, refer to detailed manual) to set the alarm time.
- When the alarm sounds, press the 'SNOOZE' button to temporarily silence it for a few minutes.
- To turn off the alarm, press any other button or let it sound for a set duration.
Teplotní alarmy
You can set programmable upper and lower limits for outdoor temperature alarms.
- Consult the detailed manual for instructions on setting temperature alarm thresholds.
- An audible alert will sound if the outdoor temperature exceeds or falls below your set limits.
Podsvícení displeje
The display backlight behavior depends on the power source.
- Napájení střídavým proudem: The display backlight is permanently on with 3 adjustable brightness levels (full, low, off).
- Napájení baterie: The backlight illuminates for 15 seconds when any button is pressed to conserve battery life.
Údržba
- Čištění: Wipe the main unit and sensor with a soft, damp tkanina. Nepoužívejte abrazivní čisticí prostředky nebo rozpouštědla.
- Výměna baterie: Replace batteries in both the main unit and outdoor sensor when the low battery indicator appears on the display, or if performance degrades. Always replace all batteries at the same time with new ones of the same type.
- Péče o senzor: Ensure the outdoor sensor's ventilation openings are clear of dust and debris. Periodically check its placement to ensure it remains protected from direct weather elements.
Odstraňování problémů
| Problém | Možná příčina | Řešení |
|---|---|---|
| Žádné údaje o venkovní teplotě/vlhkosti. |
|
|
| Nesprávný čas/datum. |
|
|
| Display is dim or blank (on battery power). |
|
|
Specifikace
Obrázek 5: Main unit dimensions and sensor range. This image shows the dimensions of the main weather station unit and highlights the outdoor sensor's 60m range and splash-proof design.
- Model: WS1703
- Main Unit Dimensions (L x W x H): 16.5 x 22 x 5.3 cm (6.5 x 8.7 x 2.1 palce)
- Hmotnost: 300 gramu (přibližně)
- Materiál: Genuine Bamboo and ABS Plastic
- Zdroj napájení (hlavní jednotka): AC Power Adapter (included) or 2 x AAA Batteries (included)
- Zdroj napájení (venkovní senzor): 2 x AAA baterie (součástí balení)
- Outdoor Sensor Range: Až 60 metrů (200 stop) v otevřeném prostoru
- Zobrazení teploty: ° C / ° F
- Rozsah vlhkosti: 20 % - 95 % relativní vlhkosti
- Speciální vlastnosti: Animated Weather Forecast, 12-hour Barometric Pressure History, Min/Max Temperature & Humidity Memory, Radio-Controlled Clock (DCF), Alarm with Snooze, Perpetual Calendar, Moon Phases, Frost Alarm, Adjustable Backlight.
Záruka a podpora
Informace o záruce: This product is covered by a manufacturer's warranty. Please refer to the warranty card or documentation included with your purchase for specific terms and conditions. Retain your proof of purchase for warranty claims.
Zákaznická podpora: For technical assistance, troubleshooting, or inquiries regarding your ADE Professional Wireless Digital Weather Station, please contact the retailer where you purchased the product or visit the official ADE webmísto pro zdroje podpory.
While this manual provides comprehensive guidance, additional support may be available through online FAQs or direct contact with the manufacturer.
