Profile Design FC25 Aero Hydration Bottle with Bite Valve Instruction Manual

Konec produktuview

Profile Design FC25 Aero Hydration Bottle is engineered to enhance your cycling performance by providing a streamlined hydration solution. Its low-profile design integrates seamlessly between your arms, improving bike handling and aerodynamics.

Image: Profile Design FC25 Aero Hydration Bottle in Black. This image displays the complete hydration system, including the bottle, straw, and bite valve.

Klíčové vlastnosti:

• No-Splash Refill Port: Features a patent-pending refill port designed to prevent splash-back during refills.
• Dual Straw Positioning: Offers strategic flexibility to position the straw on either the right or left side of the bottle by turning a dial.
• Convertible Straw: The straw can be swapped with a gap cap, allowing placement at the front or rear of the bottle.
• Updated Bite Valve: Equipped with a new, improved bite valve for efficient hydration.
• Universal Aerodrink Bracket Compatibility: Designed to be compatible with the Universal Aerodrink Bracket for secure mounting.

Pokyny pro nastavení

1. Rozbalte komponenty: Carefully remove all parts from the packaging. Ensure you have the bottle, straw, bite valve, and any mounting hardware (if included with your specific kit).
2. Attach Bite Valve: Securely attach the bite valve to the end of the straw. Ensure a snug fit to prevent leaks.
3. Insert Straw: Insert the straw into the designated opening on the top of the bottle. The dual straw positioning feature allows you to rotate the dial to orient the straw to your preferred side (right or left).
4. Upevnění na jízdní kolo: If using with a compatible Aerodrink Bracket (sold separately), follow the bracket's instructions to securely mount the FC25 bottle between your aerobars. Ensure the bottle is stable and does not obstruct your view nebo ovládání.
5. Počáteční čištění: Before first use, hand wash all components with mild soap and water. Rinse thoroughly.

Image: A hand filling the Profile Design FC25 Hydration Bottle with a liquid. The no-splash refill port is visible at the top of the bottle.

Návod k obsluze

1. Plnění lahve: Open the no-splash refill port located on the top of the bottle. Pour your preferred hydration liquid into the bottle. Close the port securely to prevent spills.
2. Pití: Position the straw to your desired side. Gently bite down on the bite valve and suck to draw liquid through the straw. Release the bite valve to stop the flow.
3. Adjusting Straw Position: If you need to change the straw's orientation, gently turn the dial on the bottle's top to move the straw to the right or left.
4. Using Convertible Straw: To change the straw's front/rear position, remove the straw and bite valve assembly. Replace the standard cap with the gap cap (if applicable) and reinsert the straw as desired.

Údržba

Čištění:

• Pouze ruční mytí: All components of the FC25 Aero Hydration Bottle should be hand washed. Do not use a dishwasher.
• Demontáž: For thorough cleaning, disassemble the bottle, straw, and bite valve.
• Mytí: Use warm water and a mild dish soap. A bottle brush may be helpful for cleaning the interior of the bottle. Clean the straw and bite valve carefully to remove any residue.
• Máchání: Všechny součásti důkladně opláchněte čistou vodou, abyste odstranili všechny zbytky mýdla.
• Sušení: Allow all parts to air dry completely before reassembling or storing to prevent mold or mildew growth.

Odstraňování problémů

• Leaking from Refill Port: Ensure the refill port cap is securely closed and properly seated. Check for any debris or damage to the seal.
• Difficulty Drawing Liquid: Check if the bite valve is properly attached and not obstructed. Ensure the straw is fully inserted and not kinked. Verify that the bottle is not empty.
• Bottle Not Securely Mounted: Re-check the mounting instructions for your specific Aerodrink Bracket. Ensure all straps or clamps are tightened according to the bracket's manual.

Specifikace
