1. Úvod
Thank you for choosing the CASARIA Vanamo Extending Wooden Garden Dining Table. This table is crafted from FSC-certified eucalyptus wood, designed to be a durable and versatile addition to your outdoor living space. Its extendable butterfly system allows for flexible seating arrangements, accommodating 6 to 8 people comfortably. This manual provides detailed instructions for assembly, operation, maintenance, and troubleshooting to ensure long-lasting enjoyment of your product.
Image 1.1: The CASARIA Vanamo Extending Wooden Garden Dining Table, showcasing its robust design and natural wood finish.
2. Důležitá bezpečnostní varování
Varování: The maximum load capacity for this table is 80 kg. Exceeding this limit may result in damage to the table or personal injury. Ensure the table is installed carefully and correctly before its first use to guarantee a stable stand. Always distribute weight evenly across the tabletop.
3. Seznam dílů
Before beginning assembly, please ensure all parts are present and undamaged. Unpack all components and lay them out on a soft, clean surface to prevent scratches. While specific part labels may not be present on all components, refer to the diagrams in the assembly section for identification.
- Tabletop sections (main and extension leaf)
- Nohy stolu (4 kusy)
- Cross braces / Support beams
- Extension mechanism components (slides, hinges)
- Hardware kit (screws, bolts, washers, Allen keys)
- Parasol hole insert (if applicable)
4. Montážní návod
Assembly of the Vanamo table requires careful attention. While the process is straightforward, some users have noted that the instructions can be challenging due to unlabeled parts and diagrams. We recommend setting aside ample time (approximately 2-5 hours) and having an electric screwdriver with appropriate bits ready, as manual assembly can be time-consuming.
- Příprava: Lay out all components and hardware. It is highly recommended to sort and identify all screws and bolts by size and type before starting. If possible, label them according to the assembly diagram.
- Assemble Leg Frames: Attach the cross braces to the table legs to form the two end frames. Pay close attention to the orientation of the legs and braces, as some pieces are handed and can be installed incorrectly. Ensure all connections are secure but do not overtighten screws until the entire frame is assembled.
- Připevnění sekcí stolní desky: Carefully align and attach the main tabletop sections to the assembled leg frames. Ensure the pre-drilled holes align perfectly. If holes feel too tight, gently re-drill them to the correct size to prevent stripping screws.
- Install Extension Mechanism: Integrate the butterfly extension mechanism into the center of the tabletop. This typically involves attaching slides and hinges that allow the central leaf to fold and unfold smoothly. Follow the diagram closely for correct placement.
- Konečné utažení: Once all components are in place and the table structure is complete, go back and securely tighten all screws and bolts. Do not overtighten, as this can damage the wood.
- Kontrola stability: Gently rock the table to ensure it is stable and all connections are firm. Adjust if necessary.
Obrázek 4.1: Rozměry nadview of the Vanamo table, useful for understanding component sizes during assembly.
5. Operating the Extension System
The CASARIA Vanamo table features a convenient butterfly extension system, allowing you to easily adjust its length from 150 cm to 200 cm. This mechanism is designed for smooth operation.
- Rozšíření tabulky:
- Gently pull the two main tabletop sections apart from the center.
- The hidden butterfly leaf will automatically unfold and rise into position.
- Push the main tabletop sections back together until they meet the extended leaf, locking it into place.
- To Retract the Table:
- Pull the two main tabletop sections apart slightly.
- Carefully fold the butterfly leaf down and back into its storage position beneath the table.
- Push the main tabletop sections back together until they are flush, returning the table to its compact size.
The table also includes a central bracket for a parasol, providing shade when needed.
Image 5.1: Visual guide to the table's extendable feature, showing the butterfly leaf in action.
6. Péče a údržba
To ensure the longevity and beauty of your FSC-certified eucalyptus wood table, regular maintenance is essential. Eucalyptus is a natural product and will benefit from proper care.
- Pravidelný úklid: Wipe the table regularly with a damp cloth to remove dust and dirt. For more stubborn stains, use a mild soap solution and rinse thoroughly. Avoid harsh chemicals or abrasive cleaners.
- Olejování: The table comes factory pre-treated with care oils. To maintain its rich color and protect the wood from weathering, it is recommended to re-oil the table at regular intervals, typically once or twice a year depending on exposure to elements. Use a suitable hardwood oil. Apply evenly with a cloth and wipe off any excess.
- Ochrana proti počasí: While the table is weather-resistant, prolonged exposure to extreme weather conditions (heavy rain, direct sunlight, frost) can affect its appearance and lifespan. Consider using a protective cover during harsh weather or storing the table indoors during winter months.
- Addressing Discoloration: Over time, natural wood may develop a silvery-grey patina. This is a natural process and does not affect the wood's integrity. If you prefer to restore the original color, clean the wood thoroughly and apply a fresh coat of wood oil.
Image 6.1: The water-resistant surface of the eucalyptus wood, demonstrating its protective qualities.
Image 6.2: The FSC®-Certified Eucalyptus Wood logo, indicating sustainable sourcing.
7. Řešení problémů
| Problém | Možná příčina | Řešení |
|---|---|---|
| Obtížnost při montáži | Unlabeled parts, unclear diagrams, tight pre-drilled holes. | Sort and identify all hardware before starting. Refer to diagrams carefully. If holes are too tight, gently re-drill them to the correct size. Consider using an electric screwdriver. |
| Table feels wobbly after assembly | Screws not fully tightened, incorrect part orientation. | Ensure all screws and bolts are securely tightened. Double-check that all legs and braces are installed in the correct orientation as per the assembly diagram. |
| Wood color fading or turning grey | Natural weathering, lack of oiling. | This is a natural process for hardwood. To restore color, clean the table thoroughly and apply a fresh coat of suitable hardwood oil. Regular oiling will help maintain the original hue. |
| Extension mechanism is stiff | Dirt accumulation, lack of lubrication. | Clean the tracks and moving parts of the extension mechanism. Apply a silicone-based lubricant (avoid oil-based lubricants on wood) to the slides if necessary. |
8. Specifikace produktu
| Funkce | Detail |
|---|---|
| Značka | Deuba |
| Číslo modelu | 991044 |
| Barva | Hnědý |
| Rozměry produktu (rozložené) | 200 x 100 x 74 cm (délka x šířka x výška) |
| Rozměry produktu (zasunuté) | 150 x 100 x 74 cm (délka x šířka x výška) |
| Hmotnost položky | 13.8 kg |
| Materiál | FSC®-Certified Eucalyptus Wood |
| Speciální funkce | Adjustable Height (via extension), Weather Resistant, Foldable (extension leaf) |
| Maximální nosnost | 80 kg |
9. Záruka a podpora
For any warranty claims, technical support, or inquiries regarding your CASARIA Vanamo Extending Wooden Garden Dining Table, please contact the manufacturer, Deuba, directly through their official customer service channels. Retain your proof of purchase for warranty validation.
Výrobce: Deuba
Please refer to the product packaging or the retailer's website for the most up-to-date contact information and warranty terms.
