TecTake 2-in-1 Cordless Grass Shear and Hedge Trimmer

Zavedení

Thank you for choosing the TecTake 2-in-1 Cordless Grass Shear and Hedge Trimmer. This versatile tool is designed for efficient and comfortable maintenance of your lawn edges and hedges. Featuring interchangeable blades, a lightweight design, and a telescopic handle, it provides flexibility and ease of use for various gardening tasks. Please read this manual carefully before operation to ensure safe and optimal performance of your device.

Důležité bezpečnostní pokyny

Při používání elektrických spotřebičů vždy dodržujte základní bezpečnostní opatření, abyste snížili riziko požáru, úrazu elektrickým proudem a zranění osob.

• Před použitím spotřebiče si přečtěte všechny pokyny.
• Udržujte děti a domácí zvířata mimo pracovní oblast.
• Používejte vhodné osobní ochranné prostředky, včetně ochranných brýlí, rukavic a pevné obuvi.
• Nepoužívejte nářadí za mokra nebo deště.
• Před použitím se ujistěte, že je baterie plně nabitá.
• Always remove the battery before cleaning, maintenance, or changing blades.
• Use only original TecTake replacement parts and accessories.
• The tool is equipped with an ignition lock for enhanced safety. Always engage the lock when not in use.

Konec produktuview a obsah balení

Familiarize yourself with the components of your TecTake 2-in-1 Cordless Grass Shear and Hedge Trimmer.

Obrázek: Overview of the TecTake 2-in-1 Cordless Grass Shear and Hedge Trimmer, showing the main unit, grass shear blade, hedge trimmer blade, telescopic handle with wheels, and charger.

Obrázek: Podrobný view of the main unit highlighting the LED battery indicator, ergonomic Softgrip handle, and the interchangeable blade system. Also shows the charging cable and blade covers.

Obsah balení:

• 1 x Cordless Grass Shear / Hedge Trimmer Main Unit (with integrated battery)
• 1 x Grass Shear Blade (approx. 8 cm cutting width)
• 1 x Hedge Trimmer Blade (approx. 13 cm cutting length)
• 1 x Telescopic Handle with 2 Wheels
• 2 x ochranné kryty čepelí
• 1 x Charging Cable / Power Adapter
• 1 x Uživatelská příručka

Nastavení a první použití

1. Nabíjení baterie:

Before first use, fully charge the integrated Lithium-Ion battery. Connect the charging cable to the charging port on the main unit and plug the adapter into a standard power outlet. The LED indicator will show the charging status. A full charge takes approximately 5 hours and provides about 40 minutes of continuous operation.

Image: Close-up showing the charging port and the three-level LED battery indicator on the main unit.

2. Attaching/Changing Blades:

Ensure the device is switched off and the ignition lock is engaged before changing blades.

1. Locate the blade release mechanism on the main unit.
2. Press the release button/lever and carefully slide off the currently attached blade.
3. Align the desired blade (grass shear or hedge trimmer) with the slots on the main unit.
4. Slide the blade into place until it clicks securely. Ensure it is firmly attached before use.

Image: The two interchangeable blades (grass shear and hedge trimmer) and the main unit, illustrating how they connect.

3. Assembling the Telescopic Handle:

The telescopic handle allows for comfortable operation without bending. It is ideal for trimming lawn edges.

1. Attach the main unit (with the grass shear blade installed) to the designated connector on the telescopic handle. Ensure it clicks into place.
2. Adjust the height of the telescopic handle by loosening the locking mechanism, extending or retracting the pole, and then securing the lock. The handle is continuously adjustable from approximately 60 cm to 90 cm.
3. The two integrated wheels on the handle facilitate smooth movement along lawn edges.

Image: A person demonstrating the use of the TecTake grass shear with the adjustable telescopic handle, highlighting its ergonomic benefits.

Návod k obsluze

Obecný provoz:

To start the tool, first disengage the ignition lock (safety switch), then press the power button. The tool will only operate when both are engaged. Release the power button to stop the tool. The LED indicator shows the battery charge level (three levels).

Using as a Grass Shear:

Attach the grass shear blade. For precise lawn edge trimming, use the telescopic handle with wheels. Guide the tool along the edge, allowing the wheels to support its movement. For smaller areas or detailed work, the main unit can be used handheld.

Image: The TecTake tool in action, demonstrating its use as a hedge trimmer on a bush and as a precise grass shear for lawn edges.

Using as a Hedge Trimmer:

Attach the hedge trimmer blade. Hold the main unit firmly with the Softgrip handle. Guide the blade smoothly through hedges and shrubs. The lightweight design and ergonomic handle ensure comfortable and precise trimming, even during extended use.

Poznámka: Always ensure the area is clear of obstacles and wear appropriate safety gear when operating the tool.

Údržba a péče

Pravidelná údržba zajistí dlouhou životnost a optimální výkon vašeho nástroje.

• Čištění: After each use, remove the blade and clean it thoroughly with a brush to remove sap, leaves, and debris. Wipe the main unit with a damp hadříkem. Nepoužívejte abrazivní čisticí prostředky ani neponořujte jednotku do vody.
• Péče o čepel: Apply a light coat of machine oil to the blades after cleaning to prevent rust and ensure smooth operation. Store blades with their protective covers.
• Skladování: Store the tool and its accessories in a dry, secure place, out of reach of children. Ensure the battery is partially charged (not fully depleted or fully charged) if storing for extended periods.
• Baterie: The Lithium-Ion battery is integrated. Do not attempt to replace it yourself. If battery performance significantly degrades, contact customer support.

Odstraňování problémů

If the problem persists after trying these solutions, please contact TecTake customer support.

Technické specifikace

Image: Diagram illustrating the dimensions and key technical specifications of the TecTake 2-in-1 Cordless Grass Shear and Hedge Trimmer.

• Model: 401542
• Zdroj napájení: Napájení baterií (Lithium-Ion)
• Baterie Voltage: 7.2 V
• Kapacita baterie: 1300 XNUMX mAh
• Rychlost naprázdno: 1100 ot./min
• Doba nabíjení: Přibl. 5 hodin
• Provozní doba: Přibl. 40 minut
• Grass Shear Blade Width: Approx. 8 cm (75 mm)
• Hedge Trimmer Blade Length: Přibl. 13 cm
• Telescopic Handle Adjustment: Přibližně 60 - 90 cm
• Hmotnost (hlavní jednotka): Přibl. 0.7 kg
• Weight (with Telescopic Handle): Přibl. 1 kg
• Materiály: Metal, Plastic (ABS), High-carbon steel blades
• Rozměry produktu (hlavní jednotka): Přibl. 36 x 8 x 11 cm (d x š x v)
• Barva: Zelený
• Mezinárodní kód zboží (EAN): 04260397659717

Záruka a podpora

TecTake products are manufactured with care and undergo strict quality controls. For information regarding warranty terms and conditions, please refer to the documentation provided at the time of purchase or visit the official TecTake website. For technical support, spare parts inquiries (note: information on spare parts availability is currently unavailable), or service, please contact your retailer or TecTake customer service directly. Please have your model number (401542) and purchase details ready when contacting support.

Výrobce: TecTake

Webmísto: www.tectake.de (nebo příslušné regionální webweb)
