Uživatelská příručka k bezdrátovému dvoupásmovému Wireless-AC1300 Wi-Fi adaptéru ASUS USB-AC56

1. Úvod

This manual provides instructions for the installation, operation, and maintenance of the ASUS USB-AC56 Dual-Band Wireless-AC1300 USB 3.0 Wi-Fi Adapter. This device is designed to provide high-speed wireless networking capabilities to desktop or notebook PCs, supporting both 2.4 GHz and 5 GHz frequency bands.

2. Obsah balení

Ověřte, zda jsou v balení produktu přítomny všechny položky:

• ASUS USB-AC56 Dual-Band Wireless-AC1300 USB Adapter
• USB Cradle with a three-foot cable
• External High-Gain Antenna
• Driver CD Utility
• Manuál

3. Konec produktuview

The ASUS USB-AC56 adapter integrates 802.11ac Wi-Fi technology, offering data rates up to 300 Mbps at 2.4 GHz and 867 Mbps at 5 GHz. It features a USB 3.0 interface for optimal performance and includes a dual internal antenna design for wireless coverage. An attachable high-gain antenna is provided to enhance signal reception.

Obrázek 3.1: ASUS USB-AC56 Wi-Fi Adapter. This image shows the main unit of the ASUS USB-AC56 adapter, highlighting its compact design.

Klíčové vlastnosti:

• 802.11ac Wi-Fi: Supports the latest Wi-Fi standard for improved speed and efficiency.
• Dvoupásmový provoz: Operates on both 2.4 GHz and 5 GHz bands for flexibility and compatibility.
• Připojení USB 3.0: Utilizes USB 3.0 for high-performance data transfer, ensuring the adapter can achieve its maximum wireless speeds.
• AiRadar Technology: Provides directional signal amplification for extended coverage and enhanced stability.
• External High-Gain Antenna: An attachable antenna is included to boost Wi-Fi signal strength and range.
• Desktop Cradle: A USB 3.0 cradle with a three-foot cable is provided for flexible positioning of the adapter, which can help optimize signal strength.

Obrázek 3.2: ASUS USB-AC56 adapter with its protective cap removed, revealing the blue USB 3.0 connector. This illustrates the adapter's direct USB plug design.

Obrázek 3.3: ASUS USB-AC56 adapter shown with the external high-gain antenna attached. This configuration is used to improve signal reception and range.

4. Nastavení

4.1. Instalace ovladače

1. Počáteční připojení: Connect the ASUS USB-AC56 adapter to an available USB 3.0 port on your computer. You may use the included USB cradle for flexible positioning.
2. Automatická instalace ovladačů: For most modern operating systems (e.g., Windows 7, 8, 10, Mac OS), the system may automatically detect the device and install a basic driver. Allow this process to complete.
3. Manual Driver Update (if necessary): If the adapter does not function correctly or if you wish to ensure you have the latest features and stability, download the most recent drivers from the official ASUS support webmísto. Návštěva Podpora ASUS, locate your model (USB-AC56), and download the appropriate driver for your operating system.
4. Install Downloaded Driver: Pokud je staženo file is compressed, extract its contents. Go to Device Manager (Windows) or System Information (Mac), find the ASUS wireless adapter, and choose to update the driver, pointing to the extracted driver folder.

4.2. Fyzické připojení

The adapter can be connected directly to a USB 3.0 port or via the included USB cradle. The cradle allows for better placement to optimize signal reception, especially if your computer's USB ports are in a confined area.

• Ensure the USB 3.0 port is available (often identified by a blue interior).
• For enhanced signal, attach the external high-gain antenna to the adapter before connecting it to your computer or cradle.

5. Provoz

5.1. Připojení k síti Wi-Fi

Once the drivers are installed, the adapter will appear as a wireless network device in your operating system.

1. Access your computer's network settings or Wi-Fi icon in the system tray/menu bar.
2. Scan for available wireless networks.
3. Select your desired network (SSID) and enter the network security key (password) if prompted.

5.2. Provoz ve dvou pásmech

The USB-AC56 supports both 2.4 GHz and 5 GHz frequency bands. Your router must also support dual-band operation to utilize both.

• Pásmo 2.4 GHz: Offers wider coverage and better penetration through walls, suitable for general internet use and devices further from the router.
• Pásmo 5 GHz: Provides higher speeds and less interference, ideal for streaming high-definition video and online gaming, typically over shorter distances.
• You may see two network names (SSIDs) from your router, one for each band (e.g., "MyWiFi_2.4GHz" and "MyWiFi_5GHz"). Choose the band that best suits your needs.

6. Údržba

• Aktualizace ovladačů: Pravidelně kontrolujte podporu ASUS webweb s aktualizovanými ovladači pro zajištění optimálního výkonu a kompatibility.
• Fyzikální péče: Keep the adapter clean and free from dust. Avoid exposing it to extreme temperatures or moisture.
• Zabezpečené připojení: Ensure the adapter is firmly seated in the USB port or cradle.

7. Řešení problémů

7.1. Unstable Connection or Disconnects

• Aktualizovat ovladače: Ensure you have the latest drivers installed from the ASUS website. Outdated drivers are a common cause of instability.
• USB port: Try connecting the adapter to a different USB 3.0 port on your computer. Sometimes, specific ports may have issues.
• USB kolébka: If using the cradle, try connecting the adapter directly to the computer, or vice-versa, to rule out the cradle as a source of the problem.
• Rušení: Other wireless devices (e.g., Bluetooth, cordless phones, microwaves) can cause interference. Try moving the adapter or other devices.
• Restartovat: A simple computer reboot can often resolve temporary connectivity issues.

7.2. Adaptér nebyl rozpoznán

• Re-plug: Unplug the adapter and plug it back into the USB port.
• Instalace ovladače: Revisit Section 4.1 to ensure drivers are correctly installed.
• Different USB Port: Test with another USB port to confirm the port is functional.

7.3. Pomalé rychlosti

• Router Distance/Obstacles: Move closer to your wireless router or ensure there are minimal obstructions (walls, large metal objects).
• Pásmo 5 GHz: Connect to the 5 GHz band if available, as it generally offers higher speeds with less interference.
• Nastavení routeru: Ensure your router is configured for optimal performance (e.g., latest firmware, correct channel settings).

8. Specifikace

9. Záruka a podpora

This ASUS product is covered by a limited warranty. For detailed warranty information, please refer to the warranty card included in your product package or visit the official ASUS support website. For technical assistance, driver downloads, or further inquiries, please contact ASUS customer support through their official channels.

Podpora ASUS Webmísto: https://www.asus.com/support/
