Car Immobilizer System User Manual

1. Konec produktuview

The Car Immobilizer System (Model: 29682) is designed to enhance vehicle security by providing keyless access, anti-theft, and anti-hijacking functionalities. This system intelligently controls the engine and oil circuits to prevent unauthorized operation and theft. It is suitable for most 12V vehicles.

Klíčové vlastnosti:

• Bezklíčový přístup: Automatic car door unlocking/locking when approaching/leaving the vehicle within 1.5 meters with the key fob.
• Anti-Hijacking: Intelligent engine and oil circuit cut-off to prevent theft during forced removal from the vehicle.
• Ochrana proti krádeži: Protects the vehicle when parked by disabling the engine.
• Skrytá instalace: Designed for hidden installation to deter illegal startup.
• Univerzální kompatibilita: Fits most 12V vehicles.

2. Obsah balení

Před instalací se prosím ujistěte, že jsou přítomny všechny komponenty:

• 1 x hostitelská jednotka
• 1 x Host Connection Line
• 1 x LED Indicator Line
• 1 x Emergency Release Switch
• 2x Dálkové ovladače
• 1 x Návod k použití

3. Specifikace

4. Instalace

Important Safety Note: Installation should ideally be performed by a qualified automotive technician. Incorrect installation can lead to vehicle damage or system malfunction.

1. Umístění hlavní jednotky: Install the main unit inside the vehicle in a location that is not visible and away from any moving parts. This concealed installation helps prevent illegal startup.
2. LED indikátor: The LED Indicator must be hidden and not visible to unauthorized individuals.
3. Nouzové tlačítko: The emergency release switch must also be hidden.
4. Wiring - Red/Black Cable:
   • Connect the red/black cable to terminal 86 at the relay.
   • Connect terminal 85 to the positive charge, together with terminal 30.
   • Connect terminal 87A to the destiny cable (the circuit you intend to cut, e.g., ignition or fuel pump).
5. Wiring - Black/White Cable:
   • Connect the black/white cable to terminal 86 at the relay.
   • Connect terminal 85 to the original cut (the other end of the circuit you intend to cut), together with terminal 30.
   • Connect terminal 87A to the destiny cable.

The system functions by controlling the engine circuit and oil circuit, effectively acting as an engine anti-theft device.

5. Návod k obsluze

The system operates automatically based on the proximity of the key fob.

• Automatické odemykání: When you approach your vehicle within approximately 1.5 meters with the key fob, the car doors will automatically unlock.
• Automatic Locking/Immobilization: When you move away from your vehicle, the system will automatically lock the car doors and activate the immobilizer. Upon installation, you can select an automatic vehicle shutoff time of either 1.5 minutes or 3 minutes after exiting your vehicle. This feature ensures the car is secured even if you forget to manually lock it.
• Anti-Hijacking Function: In the event of a forced removal from your vehicle, the system will engage its anti-hijacking protocol, controlling the engine and oil circuits to prevent the vehicle from being stolen.

6. Údržba

To ensure optimal performance and longevity of your immobilizer system:

• Baterie do dálkového ovládání: Replace the remote control batteries as needed. Reduced range or intermittent operation may indicate low battery power.
• Kontrola systému: Periodically test the system's locking and unlocking functions to ensure proper operation.
• Integrita kabeláže: Vyhněte se tampering with the installed wiring. If any issues arise, consult a professional technician.
• Udržujte v suchu: Protect the host unit and remote controls from moisture and extreme temperatures.

7. Řešení problémů

If you encounter issues with your Car Immobilizer System, refer to the following common problems and solutions:

• System Not Activating/Deactivating:
  • Ujistěte se, že baterie dálkového ovladače není vybitá.
  • Verify you are within the 1.5-meter proximity range for automatic functions.
  • Check for any obstructions or strong electromagnetic interference that might affect the signal.
• Difficulty with Installation/Setup:
  • Double-check all wiring connections according to the installation notes. Ensure terminals 86, 85, 30, and 87A are correctly connected to the vehicle's circuits.
  • Confirm that the main unit, LED indicator, and emergency button are installed in their designated hidden locations.
  • If issues persist, it is highly recommended to seek assistance from a professional automotive electrician.
• Unexpected Engine Shut-off:
  • This could indicate an issue with the system's power supply or a faulty connection. Review zapojení.
  • Ensure the remote control is always with you when operating the vehicle to prevent accidental immobilization.

8. Uživatelské tipy

• Doporučená profesionální instalace: Several users have noted difficulties with installation. For best results and to avoid potential damage, consider having the system installed by a professional automotive technician.
• Test po instalaci: After installation, thoroughly test all functions (locking, unlocking, engine cut-off) in a safe environment before relying on the system for security.
• Keep Remotes Secure: Always keep your remote controls in a secure place, as they are essential for disarming the immobilizer.

9. Záruka a podpora

Pro informace o záruce, technickou podporu nebo servisní dotazy se prosím obraťte na kontaktní údaje poskytnuté vaším prodejcem nebo oficiálním zástupcem výrobce. webwebu. Uschovejte si účtenku jako doklad o koupi.
