1. Konec produktuview
The Godox V480 TTL Flash is a high-performance camera flash designed for professional and enthusiast photographers. It features a powerful GN50 output, rapid recycle time, and extensive battery life, making it suitable for various shooting scenarios. This manual provides detailed instructions for setting up, operating, and maintaining your V480 flash.
Klíčové vlastnosti:
- GN50 output for brilliant illumination.
- Ultra-fast 1.7-second recycle time.
- Up to 650 full-power flashes per charge.
- High-Speed Sync (HSS) up to 1/8000s.
- Built-in Godox 2.4GHz X System for 100-meter remote control.
- Full TTL flash capabilities for effortless exposure.
- Smart Distance Readout for real-time effective range.
- Intuitive 2.0-inch color touchscreen with tactile button backup.
- Lightweight design (282 grams).
- Flexible bounce head (tilts -7° to 120°, swivels 330°).
- 10-level adjustable 2W LED modeling lamp (5300 tis.).
- Built-in slide-out catchlight panel and snap-on wide-angle diffuser.
- Powered by a high-capacity 7.2V/2200mAh rechargeable Li-ion battery.
- USB-C port for charging and firmware updates.
2. Co je v krabici
Upon opening your Godox V480 package, please verify that all the following components are included:
- Godox V480 TTL Flash Unit
- 7.2V/2200mAh Rechargeable Li-ion Battery
- Nabíjecí kabel USB-C
- Mini stojan
- Ochranné pouzdro
- Návod k použití
- 10-level LED modeling lamp (integrovaný)
- Built-in slide-out catchlight panel (integrated)
- Snap-on wide-angle diffuser
Image: Godox V480 TTL Flash with its complete set of accessories, including the flash unit, battery, charging cable, mini stand, protective case, and diffuser.
3. Průvodce nastavením
3.1 Nabíjení baterie
- Insert the provided 7.2V/2200mAh Li-ion battery into the battery compartment at the base of the flash unit. Ensure it clicks securely into place.
- Connect the USB-C charging cable to the USB-C port on the side of the flash unit.
- Zapojte druhý konec kabelu USB-C do kompatibilního napájecího adaptéru USB (není součástí balení) nebo do portu USB počítače.
- The charging indicator on the flash will show the charging status. A full charge typically takes approximately 2 hours.
3.2 Připojení k fotoaparátu
- Ujistěte se, že je fotoaparát vypnutý.
- Slide the V480 flash's hot shoe into your camera's hot shoe mount.
- Rotate the locking ring on the flash unit clockwise until it is securely tightened. This ensures a stable connection.
Image: The Godox V480 flash securely mounted on a DSLR camera, ready for use.
4. Návod k obsluze
4.1 Zapnutí/vypnutí
To power on the flash, long-press the power button located on the front panel. To power off, long-press the same button.
4.2 Navigace v rozhraní dotykové obrazovky
The V480 features an intuitive 2.0-inch color touchscreen. You can tap, swipe, and use the physical dial to adjust settings. The touchscreen allows for quick adjustments to flash power, modes, and other parameters.
Video: Demonstrates the intuitive touchscreen interface of the Godox V480 flash, showing how to adjust settings with ease.
4.3 režimů blesku
The Godox V480 supports various flash modes to suit different photographic needs:
- TTL (Skrz objektiv): Automatic flash exposure based on camera metering.
- Manuál (M): Allows you to manually set the flash power output.
- Multi (stroboskopický): Fires a series of rapid flashes to capture multiple movements in one image.
- Vysokorychlostní synchronizace (HSS): Enables flash synchronization at shutter speeds faster than the camera's native sync speed, up to 1/8000s.
4.4 Wireless Operation (2.4GHz X System)
The V480 has a built-in Godox 2.4GHz X System, allowing it to function as both a master and slave unit. This enables remote control and multi-flash setups.
- To use as a slave unit, set the flash to slave mode via the touchscreen.
- To use as a master unit, attach it to your camera's hot shoe and set it to master mode. You can then control other Godox X System flashes wirelessly.
Image: Diagram illustrating the Godox V480's 2.4GHz wireless system, showing its capability to communicate with other Godox X System devices.
4.5 Flexible Bounce Head
The flash head can be tilted from -7° to 120° and swiveled 330° (180° left, 150° right). This flexibility allows for bouncing flash off ceilings or walls to create softer, more natural lighting.
Image: The Godox V480 flash head tilted upwards, demonstrating its flexible bounce capability.
4.6 Modelování Lamp
The integrated 10-level adjustable 2W LED modeling lamp (5300K) assists in previewing your shot's lighting. It helps in achieving focus in low-light conditions and visualizing the light spread.
Image: Close-up of the Godox V480 showing its integrated LED modeling lamp osvětlené.
4.7 Light Shapers
The V480 includes a built-in slide-out catchlight panel for adding sparkle to eyes and a snap-on wide-angle diffuser for broader, softer light. These can be deployed as needed for creative lighting effects.
Image: The Godox V480 flash with the snap-on wide-angle diffuser attached, demonstrating its light shaping capabilities.
5. Údržba a péče
- Keep the flash unit dry. Do not expose it to rain or moisture.
- Clean the flash head and body with a soft, dry cloth. Avoid using solvents or harsh chemicals.
- Store the flash in its protective case when not in use to prevent dust and scratches.
- Regularly check the battery contacts for cleanliness.
- For long-term storage, charge the Li-ion battery to approximately 50% and store it in a cool, dry place. Recharge every 3-6 months to maintain battery health.
6. Řešení problémů
| Problém | Možná příčina | Řešení |
|---|---|---|
| Blesk se neaktivuje | Slabá baterie; Nesprávný režim; Uvolněné připojení sáněk pro blesk; Nastavení fotoaparátu. | Charge battery; Select appropriate flash mode (TTL/M); Securely attach flash to hot shoe; Check camera flash settings. |
| Flash output too weak/strong | Incorrect flash power setting; ISO/aperture mismatch; Distance to subject. | Adjust flash power in Manual mode; Verify camera ISO/aperture; Adjust distance or use bounce/diffuser. |
| Wireless not working | Incorrect channel/group; Obstructions; Out of range. | Ensure matching channel/group settings on all units; Remove obstructions; Reduce distance between units. |
| Dotykový displej nereaguje | Dočasná softwarová závada; Extrémní teplota. | Restart the flash unit; Allow unit to return to normal operating temperature. |
7. Specifikace
- Směrné číslo (GN): 50 (při ISO 100, 105 mm)
- Doba recyklace: Přibližně 1.7 sekundy (plný výkon)
- Plný výkon bliká: Cca. 650
- Doba trvání blesku: 1/300 až 1/20000 sekund
- Pokrytí bleskem: 24 až 105 mm (automatický/manuální zoom)
- Úhel odrazu: -7° to 120° (vertical), 0° to 330° (horizontal)
- Exposure Control System: TTL Autoflash, Manual Flash, Multi Flash
- Kompenzace expozice blesku (FEC): ±3 stops in 1/3 stop increments
- Režim synchronizace: High-Speed Sync (up to 1/8000s), First-Curtain Sync, Second-Curtain Sync
- Bezdrátový blesk: 2.4GHz wireless transmission (Master/Slave)
- Bezdrátový dosah: Cca. 100 metrů
- kanály: 32 (1-32)
- Skupiny: 5 (A, B, C, D, E)
- Modelování L.amp: 2W LED, 5300K, 10 levels
- Zdroj napájení: Li-ion baterie 7.2 V/2200 XNUMX mAh
- Rozměry: 2.81 x 2.99 x 8.07 palce (7.14 x 7.59 x 20.5 cm)
- Hmotnost (s baterií): Cca. 1.72 liber (0.78 kg)
8. Záruka a podpora
The Godox V480 TTL Flash comes with a standard manufacturer's warranty. Please refer to the warranty card included in your product packaging for specific terms and conditions, including warranty period and coverage details.
For technical support, troubleshooting assistance, or service inquiries, please contact Godox customer support through their official webnebo prodejce, od kterého jste produkt zakoupili. Uschovejte si doklad o koupi pro případ reklamace.
Regular firmware updates may be released to improve performance and add new features. You can download the latest firmware and update instructions from the official Godox website via the USB-C port on your flash unit.
