Uživatelská příručka

1. Konec produktuview

The Generic SC-4KBLT-IR is a true 4K high-definition waterproof bullet camera designed for a wide range of applications, from vehicle data recording to extreme sports like mountain climbing, skiing, cycling, parachuting, and diving. It features digital video recording, photo-shooting, and high-speed USB data transmission. Equipped with WiFi connectivity, H.265 video compression technology, and a 120-degree wide-angle lens, this camera provides full infrared spectrum capabilities for high-quality 4K video, even in pitch black conditions when paired with an IR illuminator. Please note that due to the removed daytime filter for IR capabilities, daytime colors may not be accurate.

Klíčové vlastnosti:

• 4K High Definition Video: Capture crisp, clear footage at 4K resolution.
• Full Spectrum IR Infrared: Record in low-light or no-light conditions with infrared capabilities.
• 120-Degree Wide Angle Lens: Nabízí rozsáhlé pole view.
• WiFi připojení: Connect to the device for live view a ovládání.
• IP66 voděodolný: Durable design for use in various environments.
• Komprese videa H.265: Efficient video encoding for smaller file velikosti.
• Video Recording While Charging: Allows continuous operation.
• Micro TF Card Support: Compatible with high-capacity Micro TF cards for extended storage.

2. Co je v krabici

Upon unboxing your SC-4KBLT-IR camera, please verify that all the following components are included:

• 1 x 4K IR Infrared waterproof bullet camera
• 1 x Helmet Mount with Velcro Loops
• 1 x Držák na řídítka
• 1 x Tripod Adapter Mount
• 1 x resetovací klíč
• 1 x USB nabíjecí kabel
• 1 x Uživatelská příručka (tento dokument)

3. Počáteční nastavení

3.1 Nabíjení baterie

Before first use, fully charge the camera's internal battery. Connect the supplied USB charging cable to the camera's USB port and the other end to a USB power adapter (not included) or a computer's USB port. The charging indicator light will illuminate during charging and turn off when fully charged.

3.2 Inserting a Micro TF Card

The camera requires a Micro TF (microSD) card for storing recordings and photos. Insert a high-capacity Micro TF card (Class 10 or higher recommended, up to 128GB) into the designated card slot until it clicks into place. Ensure the card is inserted in the correct orientation to avoid damage.

3.3 Zapnutí/vypnutí

• Zapnutí: Press and hold the Power button (usually marked with a power symbol) for a few seconds until the indicator lights illuminate.
• Vypnutí: Press and hold the Power button again until the indicator lights turn off.

4. Ovládání fotoaparátu

4.1 Nahrávání videa

Once powered on, the camera typically defaults to video recording mode. Press the Record/OK button to start recording. The recording indicator light will flash. Press the button again to stop recording. Videos are saved to the Micro TF card.

4.2 Fotografování

To switch to photo mode, press the Mode button. The camera's indicator will change to reflect photo mode. Press the Shutter/OK button to take a photo. Photos are saved to the Micro TF card.

4.3 Připojení k Wi-Fi

The camera features built-in WiFi for live view and remote control via a smartphone application. Refer to the specific app instructions (usually found in a separate quick start guide or app store description) for connecting your device. Typically, you will enable WiFi on the camera, then connect your phone to the camera's WiFi network, and finally open the app.

4.4 Infrared (IR) Operation

The SC-4KBLT-IR camera is designed with full spectrum infrared capabilities, allowing it to capture images and video in very low light or complete darkness. For optimal performance in pitch black conditions, it is highly recommended to use an external IR illuminator (not included). The camera's IR functionality is always active due to the removed daytime filter, which means daytime colors may appear altered or inaccurate.

5. Údržba a péče

• Čištění: K čištění těla fotoaparátu používejte měkký, suchý hadřík. Na objektiv použijte speciální hadřík a roztok na čištění objektivů. Nepoužívejte abrazivní materiály ani agresivní chemikálie.
• Vodotěsné těsnění: Ensure the waterproof seals and covers (e.g., for USB port, Micro TF card slot) are securely closed before exposing the camera to water. Regularly inspect seals for any damage.
• Skladování: Pokud fotoaparát nepoužíváte, skladujte jej na chladném a suchém místě mimo dosah přímého slunečního záření a extrémních teplot.
• Péče o baterie: For long-term storage, charge the battery to about 50% to prolong its lifespan. Avoid fully discharging the battery frequently.

6. Řešení problémů

7. Specifikace

8. Záruka a podpora

This product is covered by a standard manufacturer's warranty. For specific warranty terms and conditions, please refer to the documentation provided at the time of purchase or contact the manufacturer directly.

For technical support, troubleshooting assistance, or warranty claims, please contact StuntCams, the manufacturer of this product. Contact information can typically be found on their official webmístě nebo na obalu produktu.

Výrobce: StuntCams
