IINE Wireless Joypad Controller L749 User Manual

1. Úvod

Děkuji za nákupasing the IINE Wireless Joypad Controller L749. This manual provides detailed instructions for setting up, operating, and maintaining your new controller. Please read this manual carefully before use to ensure proper functionality and to maximize your gaming experience.

Image 1.1: The IINE Wireless Joypad Controller, designed for Nintendo Switch and Switch Lite consoles.

2. Konec produktuview

2.1 Klíčové vlastnosti

• Wireless connectivity for flexible gameplay.
• Wake-up function to quickly resume gaming.
• Precise Motion Control with 6-axis gyroscope.
• Auto-Fire (Turbo) function for enhanced gameplay.
• Dual Vibration for immersive feedback.
• Customizable RGB Joystick Ring Lights.
• Separate charging capability.

2.2 Součásti řídicí jednotky

The controller consists of a left and right joypad, each equipped with various buttons and features.

Obrázek 2.1: Konecview of controller functions including screenshot, upgrade support, 6-axis motion, one-click wake up, separate charging, and dual vibration.

3. Nastavení a připojení

The IINE Wireless Joypad Controller can be used in two primary modes: attached to the console or detached for separate play.

3.1 Attaching to the Console

1. Slide the left joypad down the left rail of your Nintendo Switch/Switch OLED console until it clicks into place.
2. Slide the right joypad down the right rail of your Nintendo Switch/Switch OLED console until it clicks into place.
3. The console will automatically detect the controllers.

3.2 Connecting Wirelessly (Detached Mode)

1. From the Nintendo Switch HOME Menu, select 'Controllers' > 'Change Grip/Order'.
2. On each joypad, press and hold the SYNC button (small round button on the side rail) for a few seconds until the player indicator lights begin to flash.
3. Once connected, the player indicator lights will remain lit.

Image 3.1: Illustration of the two gaming modes: playing with controllers detached or attached to the console.

4. Návod k obsluze

4.1 Základní funkce tlačítek

• Levý joypad: Left Analog Stick, D-Pad (Up, Down, Left, Right), L, ZL, Screenshot button, Minus (-) button.
• Pravý joypad: Right Analog Stick, A, B, X, Y buttons, R, ZR, Home button, Plus (+) button.

4.2 Wake-up Function

When the console is in sleep mode, press the Home button on the right joypad to wake up the Nintendo Switch/Switch OLED console.

4.3 Motion Control

The built-in 6-axis gyroscope allows for precise motion control in compatible games. Calibrate motion controls via the Switch system settings if accuracy issues occur.

4.4 Auto-Fire (Turbo) Function

To activate the Auto-Fire function for a button:

1. Press and hold the desired action button (e.g., A, B, X, Y, L, R, ZL, ZR).
2. While holding the action button, press the Turbo button (usually a dedicated button or a combination, refer to specific controller markings).
3. The button will now continuously register presses as long as it is held down.

To deactivate Auto-Fire, repeat the process.

4.5 RGB Joystick Ring Lights

The controller features customizable RGB lighting around the joysticks. Refer to the controller's specific button combinations (often involving a 'Light' or 'LED' button, or holding a specific button and pressing the analog stick) to cycle through colors or turn the lights on/off.

Image 4.1: The controller showcasing its RGB joystick ring lights, which can be customized for different colors.

5. Nabíjení

The IINE Wireless Joypad Controller is equipped with built-in lithium polymer batteries. Each joypad charges separately.

5.1 Způsob nabíjení

Connect a USB-C charging cable (not always included, check product packaging) to the charging port on each joypad. Connect the other end to a USB power source (e.g., Switch dock, USB wall adapter, computer USB port).

5.2 Indikátory nabíjení

During charging, indicator lights on the joypad will typically show charging status (e.g., blinking while charging, solid when fully charged). Refer to the controller's specific LED behavior for exact indications.

5.3 Životnost baterie

• Doba nabíjení: Přibližně 2 hodiny na plné nabití.
• Nepřetržitá pracovní doba: Až 15 hodin na plné nabití.
• Pohotovostní doba: Až 20 hodiny.

Image 5.1: Battery performance details, showing 2 hours charging time, 15 hours continuous working time, and 20 hours standby time.

6. Údržba

• Udržujte ovladač čistý otíráním měkkým, suchým hadříkem.
• Nevystavujte ovladač extrémním teplotám, vlhkosti nebo přímému slunečnímu záření.
• Do not disassemble the controller, as this may void the warranty and cause damage.
• Store the controller in a safe place when not in use to prevent accidental damage.

7. Řešení problémů

7.1 Řídicí jednotka se nepřipojuje

• Ensure the controllers are charged.
• Verify that the console's Bluetooth is enabled.
• Try re-pairing the controllers via 'Change Grip/Order' in the Switch HOME Menu.
• Restart the Nintendo Switch console.

7.2 Input Lag or Unresponsive Buttons

• Ujistěte se, že v blízkosti není žádné silné elektromagnetické rušení.
• Check for any available firmware updates for the controller (refer to IINE's official support channels).
• Ensure the controller is within range of the console.

7.3 Joystick Drift

If you experience unintended movement from the analog sticks:

• Calibrate the joysticks through the Nintendo Switch system settings: HOME Menu > System Settings > Controllers and Sensors > Calibrate Control Sticks.
• Ensure the controller's firmware is up to date.

8. Specifikace

9. Záruka a podpora

IINE products are designed for reliability and performance. For warranty information, please refer to the documentation included with your purchase or visit the official IINE website. For technical support or further assistance, please contact IINE customer service through their official channels.
