LUOWAN Android 10 Touch Screen Infotainment System User Manual

1. Úvod

This manual provides detailed instructions for the installation, operation, and maintenance of your LUOWAN Android 10 Touch Screen Infotainment System. This system is designed to upgrade the in-car experience for Mercedes Benz GLE (2016-2019) and GLS (2017-2019) models equipped with NTG 5.0. It integrates advanced features while retaining the functionality of your original car system.

2. Bezpečnostní informace

• Always ensure the vehicle is parked safely before operating the touch screen or making any adjustments.
• Do not attempt to install or repair the unit if you are not qualified. Improper installation can lead to damage or injury.
• Udržujte obrazovku čistou a bez překážek, abyste zajistili dobrou viditelnost.
• Vyhněte se dlouhodobému vystavení přímému slunečnímu záření nebo extrémním teplotám.
• Refer to your vehicle's owner's manual for additional safety guidelines.

3. Obsah balení

Ověřte, zda jsou v balení obsaženy všechny níže uvedené položky:

Obrázek 3.1: Obsah baleníview

• 1x LUOWAN 12.5-inch Android 10 Touch Screen Unit
• 1x Main Power Cable Harness
• 1x GPS anténa
• 1x USB kabel
• 1x Camera CVBS Cable
• 1x LVDS Cable
• Other necessary accessories and mounting hardware (as shown in Figure 3.1)

4. Instalační příručka

Důrazně se doporučuje profesionální instalace. Před zahájením instalace se ujistěte, že je vozidlo odpojeno od napájení.

4.1. Pre-Installation Overview

Obrázek 4.1: Před a po instalaci

Figure 4.1 illustrates the visual transformation of your dashboard after installing the LUOWAN infotainment system. The new 12.5-inch screen replaces the original display, integrating seamlessly into the vehicle's interior.

4.2. Schéma zapojení

Obrázek 4.2: Připojení kabelů

Refer to Figure 4.2 for the correct wiring connections. Ensure each cable is securely connected to its corresponding port. Key connections include:

1. USB kabel
2. CAMERA-CVBS
3. USB port
4. USB port
5. CCD 12V
6. LVDS
7. Connect to factory LVDS port
8. Connect ACC OUT
9. Napájecí kabel
10. Zvukový výstup
11. B kabel
12. A/B Cable
13. A Cable
14. A interface
15. DVR-V
16. DVD-V
17. DVD-R
18. DVD-L
19. IR
20. ACC-IN
21. Napájení kamery
22. ZVRÁTIT
23. ACC OUT

After connecting all wires, carefully mount the screen unit into the dashboard. Ensure no wires are pinched or exposed.

5. Nastavení a počáteční konfigurace

5.1. První zapnutí

Once installed, turn on your vehicle's ignition. The system will boot up to the Android interface. Follow any on-screen prompts for initial setup, such as language selection and time zone.

5.2. Network Connectivity (WiFi & 4G LTE)

Figure 5.1: 4G Connectivity and Split Screen View

The system supports both WiFi and 4G LTE connectivity. To connect to WiFi, navigate to Nastavení > Síť a internet > Wi-Fi and select your desired network. For 4G LTE, insert a compatible SIM card into the designated slot (refer to Figure 5.2 for SIM card slot location). This enables internet access for streaming, navigation, and app downloads.

Figure 5.2: SD Card and 4G SIM Card Slots

5.3. Párování Bluetooth

To pair your smartphone via Bluetooth, go to Nastavení > Připojená zařízení > Spárovat nové zařízení. Ensure your phone's Bluetooth is enabled and visible. Select your phone from the list on the screen and confirm the pairing code.

6. Návod k obsluze

6.1. Hlavní rozhraní a navigace

Figure 6.1: Android Main Interface

The main interface (Figure 6.1) provides quick access to key functions. Swipe left or right to navigate through different app screens. Tap on icons to launch applications.

6.2. Bezdrátové CarPlay a Android Auto

Obrázek 6.2: Bezdrátové rozhraní CarPlay

The system features built-in wireless CarPlay and Android Auto. Once your phone is paired via Bluetooth, launch the "AutoLink" or "CarPlay" app from the main menu. The system will automatically connect to your phone, displaying the CarPlay or Android Auto interface (Figure 6.2). This allows access to phone functions, navigation, music, and messaging directly from the touch screen.

Video 6.1 demonstrates how to access and use the wireless CarPlay feature, highlighting the seamless integration with your smartphone for navigation, music, and communication.

6.3. Retaining Original Car Features (NTG Mode)

This unit is designed to retain all original Mercedes Benz car features. To switch back to your original car's infotainment system (NTG mode), simply tap the "NTG Mode" icon on the main Android interface. This allows you to access your original radio, CD player, and iDrive system.

Video 6.2 illustrates how to switch between the Android system and the original NTG mode, ensuring full functionality of your Mercedes Benz's native features.

6.4. Instalace a používání aplikace

The Android 10 system supports third-party applications. You can download and install apps like YouTube, Spotify, Google Maps, and more from the Google Play Store. Navigate to the "Apps" section on the main interface to access installed applications or the Play Store.

Video 6.3 demonstrates navigating through the app menu and launching YouTube, showcasing the system's capability to run various Android applications.

6.5. Zobrazení na palubní desce

Figure 6.3: Dashboard Icon on Main Interface

The "Dashboard" feature (Figure 6.3) provides real-time vehicle information, such as speed and mileage, directly on the screen. Tap the "Dashboard" icon to access this display.

Video 6.4 demonstrates the dashboard display, showing how it reflects real-time speed and other vehicle information.

6.6. Special Display Features

The unit features a unique clock display integrated into the air vent panel. This display can be customized to show a clock, car logo, or compass. This is a display, not a physical clock.

Video 6.5 highlights the customizable clock display feature, demonstrating how to change its appearance.

6.7. Další funkce

Figure 6.4: System Feature Overview

As shown in Figure 6.4, the system supports:

• Ovládání na volantu
• Ovládání pohonu
• Retention of original CD player functionality
• Retention of original car system
• Original and additional rear view Podpora fotoaparátu
• Original car audio sound

Figure 6.5: IPS Screen and Built-in DSP

The unit features an IPS screen for better color, clarity, and contrast compared to normal screens. It also includes a built-in Digital Sound Processor (DSP) for enhanced audio quality, allowing for precise sound adjustments (Figure 6.5).

Figure 6.6: Dual USB Interface

The system provides a dual USB interface (Figure 6.6) for connecting external devices, such as USB drives for media playback or charging smartphones.

7. Údržba

• Čištění obrazovky: Použijte měkký hadřík, který nepouští vlákna dampened with water or a screen cleaner. Do not use abrasive cleaners or solvents.
• Aktualizace softwaru: Periodically check for software updates through the system's settings to ensure optimal performance and access to new features.
• Obecná péče: Avoid placing heavy objects on the screen or exposing it to sharp objects that could cause scratches.

8. Řešení problémů

9. Specifikace

10. Záruka a podpora

Specific warranty information for this product is not provided in the available data. Please refer to the product packaging or contact the seller directly for warranty details and technical support.
