Timex Intelligent Quartz Compass Chronograph Watch TW2T76500 User Manual

1. Konec produktuview

This manual provides instructions for the Timex Intelligent Quartz Compass Chronograph Analog Watch, model TW2T76500. This timepiece features an analog display with Intelligent Quartz technology, integrating a compass and chronograph function. It is designed for durability with a stainless steel case, mineral dial glass, and a fabric band.

Figure 1.1: Timex Intelligent Quartz Compass Chronograph Watch (Model TW2T76500) on a wrist.

Figure 1.2: Close-up of the watch dial, showing chronograph subdials and compass markings.

2. Počáteční nastavení

Upon receiving your watch, perform the following steps to ensure proper function:

1. Rozbalení: Opatrně vyjměte hodinky z obalu. Zkontrolujte, zda nejsou viditelně poškozené.

Figure 2.1: The Timex watch is supplied in a protective box.
2. Crown Protector: If present, remove any plastic crown protector.
3. Nastavení času: Pull the crown (the knob on the side of the watch) out to its outermost position. Rotate the crown to set the correct time. Push the crown back in completely to start the watch movement.
4. Date Setting (if applicable): If your watch includes a date function, pull the crown out to the middle position and rotate it to set the correct date. Push the crown back in completely.

3. Návod k obsluze

3.1. Nastavení času a data

1. Čas: Pull the crown to the outermost position. Rotate the crown clockwise or counter-clockwise to adjust the hour and minute hands. Once set, push the crown back to the normal operating position.
2. Datum: Pull the crown to the middle position. Rotate the crown to advance the date. Avoid setting the date between 9 PM and 3 AM to prevent damage to the movement. Once set, push the crown back to the normal operating position.

3.2. Použití funkce chronografu

Chronograf umožňuje přesné načasování událostí.

1. Start: Press the upper pusher (button) to start the chronograph. The chronograph second hand will begin to move.
2. Stop: Press the upper pusher again to stop the chronograph. The elapsed time will be displayed on the chronograph subdials.
3. Resetovat: After stopping, press the lower pusher to reset the chronograph hands to their zero positions.
4. Mezičas (pokud je to relevantní): Some chronographs allow for split time measurement. Consult the specific watch diagram for your model if this feature is present.

3.3. Using the Compass Function

The Intelligent Quartz compass feature provides directional guidance.

1. Aktivace kompasu: Typically, the compass function is activated by pressing a specific pusher (often the lower pusher) or by pulling the crown to a specific position. Refer to your watch's specific markings.
2. Kalibrace (pokud je to nutné): For accurate readings, the compass may require calibration. This usually involves rotating the watch in a figure-eight pattern or following on-screen prompts if a digital display is present.
3. Směr čtení: Hold the watch horizontally. The compass hand will point North. The bezel may be rotated to align with North for easier navigation.
4. Deaktivace kompasu: Press the pusher again or push the crown back to its normal position to return to timekeeping mode.

4. Údržba

4.1. Čištění

• Pouzdro a sklíčko hodinek otřete měkkým, suchým hadříkem.
• For fabric bands, a damp cloth with mild soap can be used, but ensure the band is thoroughly dry before wearing.
• Nepoužívejte agresivní chemikálie nebo abrazivní materiály, protože by mohly poškodit povrch hodinek.

4.2. Voděodolnost

This watch is water-resistant. Refer to the specifications for the exact water resistance level.

• Neovládejte korunku ani tlačítka, pokud jsou hodinky mokré nebo ponořené.
• Avoid exposing the watch to hot water, steam, or extreme temperature changes, as this can compromise the seals.
• Pokud hodinky přišly do styku se slanou vodou, opláchněte je sladkou vodou a důkladně osušte.

Figure 4.1: Illustration of water resistance, indicating care instructions.

4.3. Výměna baterie

When the watch stops or the second hand begins to jump in 2-second intervals, it indicates a low battery. Battery replacement should be performed by a qualified watch technician to ensure proper sealing and function. The watch uses a standard button cell battery.

5. Řešení problémů

6. Specifikace

7. Záruka a podpora

Your Timex watch comes with a 1-year manufacturer warranty from the date of purchase.

7.1. How to Avail Warranty

• To claim your warranty, you must present either the original bill copy/invoice or the warranty card at any authorized Timex service center.

7.2. Kontaktní informace

• For any service-related inquiries or feedback, please contact Timex India toll-free number: 1800 419 2727.
• Operating hours: Monday to Sunday, 10:00 AM to 7:00 PM (except government holidays).
• You may also send an email to: custservice@timexindia.com or feedback@timexindia.com.
