1. Bezpečnostní pokyny
Read all safety warnings and instructions before using the pressure washer. Failure to follow the warnings and instructions may result in electric shock, fire, and/or serious injury.
- Always wear appropriate personal protective equipment (PPE) such as safety glasses and hearing protection.
- Nikdy nesměrujte proud vody na lidi, zvířata ani elektrická zařízení.
- Ujistěte se, že napájecí zdroj odpovídá specifikacím uvedeným na štítku produktu.
- Do not operate the pressure washer in explosive atmospheres.
- Udržujte děti a přihlížející mimo provozní oblast.
- Disconnect from power supply before cleaning, adjusting, or servicing.
2. Konec produktuview
The KINZO 52520 is a mobile high-pressure cleaner designed for various cleaning tasks around the home and garden. It features an aluminum pump head and comes with a comprehensive accessory package.
Image 1: KINZO 52520 Pressure Washer with its included accessories, including the surface cleaner, dirt blaster, and various nozzles. The unit is yellow and black, featuring wheels for mobility and a hose reel.
2.1 Komponenty
- Pressure Washer Unit (Main body with motor and pump)
- High-Pressure Hose with Hose Reel
- Stříkací pistole
- Nastavitelná tryska
- Dirt Blaster Nozzle
- Surface Cleaner (Slider)
- Nádrž na prací prostředek
- Konektor přívodu vody
- Wheels and Handle for Mobility
3. Nastavení
3.1 Montáž
- Attach the wheels and handle to the main unit as per the diagrams in the separate assembly guide.
- Connect the high-pressure hose to the outlet on the pressure washer and to the spray gun. Ensure connections are secure.
- Attach the desired nozzle (e.g., adjustable nozzle or dirt blaster) to the spray gun.
3.2 Připojení vody
- Connect a garden hose (not supplied) to the water inlet connector on the pressure washer.
- Druhý konec zahradní hadice připojte k vodovodnímu kohoutku.
- Turn on the water supply fully.
- Before turning on the pressure washer, squeeze the trigger on the spray gun to purge air from the system until a steady stream of water emerges. This prevents damage to the pump.
3.3 Elektrické připojení
- Ensure your power outlet is suitable for the pressure washer's power requirements (1850W).
- Zapojte napájecí kabel do uzemněné elektrické zásuvky.
4. Návod k obsluze
4.1 Spuštění tlakového čističe
- Ensure water supply is on and air is purged from the system.
- Otočte vypínač do polohy „ON“. Motor se spustí.
- Squeeze the trigger on the spray gun to begin spraying. Release the trigger to stop the water flow.
4.2 Použití čisticího prostředku
- Fill the detergent tank with a suitable pressure washer detergent.
- Attach the detergent nozzle (if applicable) or ensure the adjustable nozzle is set to the low-pressure/detergent setting.
- The pressure washer will draw detergent automatically when operating at low pressure.
- After applying detergent, switch back to high pressure and rinse the surface thoroughly.
4.3 Using the Surface Cleaner
- Connect the surface cleaner (Slider) to the spray gun.
- Ensure the surface cleaner is flat on the surface to be cleaned.
- Turn on the pressure washer and squeeze the trigger. Move the surface cleaner slowly and evenly over the area.
4.4 Vypnutí
- Otočte vypínač ZAP/VYP do polohy „VYP“.
- Vypněte přívod vody.
- Stiskněte spoušť na stříkací pistoli, abyste uvolnili zbývající tlak v systému.
- Disconnect the power cord and water hose.
5. Údržba
5.1 Čištění trysek
- If nozzles become clogged, use the supplied nozzle cleaning tool (if included) or a thin wire to clear debris.
- Rinse nozzles with clean water after cleaning.
5.2 Filtr přívodu vody
- Pravidelně kontrolujte a čistěte filtr přívodu vody, abyste zabránili vniknutí nečistot do čerpadla.
- Remove the filter, rinse it under running water, and reinsert it.
5.3 Skladování
- Drain all water from the pump, hose, and spray gun before storing, especially in freezing temperatures.
- Store the pressure washer in a dry, frost-free location.
- Wind the high-pressure hose neatly onto the hose reel.
6. Řešení problémů
| Problém | Možná příčina | Řešení |
|---|---|---|
| Motor se nespustí | No power supply; ON/OFF switch is OFF; Thermal overload activated. | Check power connection; Turn switch ON; Allow motor to cool down. |
| Žádný tlak vody | Water supply off; Inlet filter clogged; Air in pump; Nozzle clogged. | Turn on water; Clean filter; Purge air from system; Clean nozzle. |
| Pulzující tlak | Air in pump; Water supply restricted; Nozzle partially clogged. | Purge air; Check water flow; Clean nozzle. |
| Nedávkuje mycí prostředek | Detergent tank empty; Nozzle not set to low pressure; Detergent hose clogged. | Refill tank; Adjust nozzle; Clean detergent hose. |
7. Specifikace
- Model: KINZO 52520
- Moc: 1850 Wattů
- Max. Tlak: 135 bar
- Max. Průtok: 426 litrů za hodinu
- Hlava čerpadla: Hliník
- Hmotnost: 8.64 kg
- certifikace: CE, CSA
- Zdroj energie: Elektrický kabel
8. Záruka a podpora
For warranty information and customer support, please refer to the separate warranty card included with your product or visit the official Kinzo webwebu. Uschovejte si účtenku jako doklad o koupi.
Note: This manual provides general instructions. Specific details may vary. Always refer to the latest official documentation from the manufacturer.
